Koyo/JTEKT 62/22NR Deep Groove Ball Bearing w/ Snap Ring 22 x 50 x 14mm
Regular price
$33.92
Sale price
$33.92
Regular price
Inc. GST
Available
Koyo/JTEKT 62/22NR. Open: open bearing for low-friction high-speed duty. Koyo precision chrome steel races and balls. Standard clearance. Koyo/JTEKT 62/22NR Deep Groove Ball Bearing with Snap Ring 22 x 50 x 14mm is a service-grade replacement for industrial and automotive drive shafts.
Product Specifications. Bearing type: Deep groove ball bearing. Sealing: Open. Clearance: Standard. Material: Chrome bearing steel. Dimensions: 22 x 50 x 14mm.
Key Specifications
| Bearing Width B (mm) | 14 |
| Mass (kg) | 0.118 |
| 2RU) | 15000 |
| Mounting Dimension (mm) Rb Max. | 0.5 |
| Mounting Dimension (mm) Cy Max. | 3.33 |
| Bore Diameter x Outer Diameter x Width (mm) | 22 x 50 x 14 |
| Basic Load Rating (kN) Cr | 16 |
| Boundary Dimension (mm) r min. min. | 1 |
| Boundary Dimension (mm) r1 min. | 0.5 |
| Series | 60/22-63/32 Series |
| Dimension of snap ring groove (mm) b ±0.15 | 1.5 |
| Fatigue Load Limit (kN) Cu | 0.51 |
| Type | Deep-Groove Ball Bearings |
| Outside Diameter D (mm) | 50 |
| Dimension of snap ring groove (mm) D1 max. | 47.6 |
| Limiting Speed (min-1) Oil Lub. Open (Z) | 17000 |
| Basic Load Rating (kN) C0r | 6.65 |
| Bore Diameter d (mm) | 22 |
| Dimension of snap ring groove (mm) a max. | 2.46 |
| Mounting Dimension (mm) Ra Max. | 1 |
| Mounting Dimension (mm) Da Min. | 27 |
| Mounting Dimension (mm) Dx Min. | 56.5 |
| Dimension of snap ring groove (mm) rO | 0.4 |
| Factor F 0 | 13.2 |
| Dimension of locating snap ring (mm) D2 Max | 55.7 |
| Dimension of locating snap ring (mm) F ±0.05 | 1.07 |
| Mounting Dimension (mm) Da Max. | 45 |
Where This Is Used
- Automotive: Transmissions, electrical devices, truck, and trailer equipment.
- Off-Highway Vehicles: Construction equipment, agricultural equipment, railroad rolling equipment.
- Electrical Equipment: Standard motors, electric appliances for domestic use.
- Other: Measuring instruments, medical instruments, and miscellaneous industrial equipment.
Features
- Features Deep Groove Radial Bearing.
- Type: Open Type, Shielded/ sealed type, With locating snap ring, Maximum type, and Double-row.
- The most popular rolling bearing type used in a wide variety of industries and applications.
- The inner and outer rings have deep uninterrupted grooves.
- They can support radial loading and a certain degree of axial loading in either direction.
- High-speed capability.
- The Maximum style not to be used when axial loading or high speed is involved.
- Sealed and shielded types are filled with an appropriate volume of grease.
- Bearings with a locating snap ring aid axial positioning and eliminate the need for housing shoulder.
- Cages can be a pressed steel, machined copper alloy, molded polyamide, synthetic resin, pressed stainless sheet steel.
