Macnaught Booster Gun Without Swivel (Grease Dispensing Gun Only) B2
Available
The Macnaught B2 is a booster gun for air-powered grease pumps, supplied without a swivel. It boosts the grease pressure at the nipple.
A booster gun is not a hand-filled grease gun. It has no barrel or cartridge. It connects by a hose to an air-powered grease pump and boosts the grease pressure at the nipple. When a nipple is seized and no grease flows, you pull the trigger several times and each squeeze boosts the pressure until grease flows. The inlet is 1/4" NPT(F), an American pipe thread (female). It suits grease up to NLGI 2. NLGI 2 is the common general-purpose grease grade. This is the gun only. The ZSB swivel is sold separately. Choose the B2 if you already have a swivel or are replacing the gun. Choose the B2-01 if you need the swivel as well.
Where this product is used
- Clearing seized or blocked grease nipples on plant fed by an air-powered grease pump
- Fitting to a P3 POWERLUBE, P6 or P8-11 MAXILUBE greasing system
- Mine site, fleet and heavy equipment greasing
Features
- Boosts the grease pressure from an air-powered pump to overcome line resistance or nipple blockages
- 1/4" NPT(F) inlet
- Fitted as standard to the P3 POWERLUBE, P6 and P8-11 MAXILUBE greasing systems
- Suits grease up to NLGI 2
- Each trigger squeeze boosts the pressure until grease flows
- Service kit B2-1K available
- The ZSB high-pressure grease swivel is an optional extra
- Keep your hands away from the nipple and coupler connection at all times
- Use away from heat, fire or explosive atmospheres, and disconnect the air supply before servicing
Key specifications
| Specification | Detail |
|---|---|
| Brand | Macnaught |
| Model | B2 |
| Part number | B2 |
| Gun type | Booster gun for air-powered grease pumps |
| Inlet | 1/4" NPT(F) |
| Maximum grease | NLGI 2 |
| Service kit | B2-1K |
| Swivel | Not included, sold separately |
Supplied with
- B2 booster gun
- Not included: ZSB high-pressure grease swivel (sold separately)
Related Macnaught products
- Macnaught Service Kit For B2-1K: Service kit for B2 and B3 guns
- Macnaught Inlet Body/Guard Set For B2-1SGK: Trigger guard kit and inlet body for the B2 booster gun
