Macnaught Drum Assembly - Suits Retracta Hose RP35-BLACKS

The Macnaught RP35-BLACKS is a replacement drum assembly for Retracta auto-rewind hose reels. The drum is the part the hose winds onto, and the rewind spring sits inside it. If the spring is damaged, a new drum assembly must be installed.

The WP100 reel uses a different drum assembly, RP43-Black. The drum is only one part of the reel, so the hose, swivel and side plates are separate items.

Where this product is used

• Replacing a drum assembly with a damaged rewind spring
• Rebuilding a Retracta auto-rewind reel that no longer rewinds
• Servicing the Retracta Oxy-LPG reel, where RP35-BLACKS is the drum assembly

Features

• Replacement drum assembly, the part the hose winds onto
• The WP100 reel uses a different drum assembly, RP43-Black
• Do not open the drum assembly for any reason. It is not repairable
• Fitting means removing the side plate, swivel and tension parts, separating the outer case halves and rejoining them with the steel mouth guard at the top
• Always use genuine Retracta spare parts
• Isolate the reel from the supply before maintenance, and test for leaks and correct operation afterwards

Key specifications

Supplied with

• Drum assembly
• Hose, swivel, side plates and outer case are separate items
