Macnaught IBC Mounted Oil System Includes R300 Pump & Gun OS500G-01
Available
The Macnaught OS500G-01 is a ready-made oil dispensing system for mounting on a wall or an IBC. It has an R-Series air-operated oil pump, a Retracta oil hose reel with 1/2" x 15m of hose and an unmetered HG20R-01 dispense gun on a pre-drilled mounting plate, with all necessary fittings and hoses.
The pump is an R300S-01, a 3:1 R-series pump. It has a free flow of up to 23 L/min and is rated for oils up to SAE140, coolants, kerosene and diesel. R-series pumps have a heavy-duty aluminium and steel air motor with large exhaust ports to prevent icing. The ratio is how much the pump multiplies your air pressure at the oil outlet. A higher ratio gives more push for long hose runs and thick oil, but usually less oil per minute. A lower ratio usually moves more oil with less push. The OS500G is the same system as the OS400G, except that the OS400G has the T312 pump with a free flow of up to 13 L/min. Choose the OS500G for more oil per minute, or the OS400G for the T-series pump. In Macnaught part numbers, B means no gun, G means an unmetered gun, GE means a metered gun (the meter is built into the gun) and IM means an in-line meter (the meter is fitted in the hose line).
Where this product is used
- Pumping and dispensing oil from an IBC or bulk container
- Wall mounted oil dispensing with a gun on the reel
- Workshops that want more oil per minute from a ready-made IBC set
Features
- Wall or IBC mount oil system with an unmetered gun
- R300S-01 3:1 R-series air-operated pump, free flow up to 23 L/min
- Retracta oil hose reel with 1/2" x 15m hose
- HG20R-01 unmetered dispense gun with a latching trigger and non-drip nozzle
- Sturdy pre-drilled mounting plate for the pump, gun and reel
- All necessary fittings and hoses included
- How to choose: OS500G-01 has the R300 pump and a gun, OS500B-01 has no gun and OS400G-01 has the lower-flow T312 pump
Key specifications
| Specification | Detail |
|---|---|
| Brand | Macnaught |
| Model | OS500G-01 |
| Part number | OS500G-01 |
| Type | Wall or IBC mounted oil dispensing system with unmetered gun |
| Pump | R300S-01 3:1 R-series air-operated pump |
| Pump free flow | Up to 23 L/min |
| Hose reel | Retracta oil hose reel, 1/2" x 15m hose |
| Gun | HG20R-01 unmetered dispense gun |
| Mounting plate | Pre-drilled, for pump, gun and reel |
| Maximum air pressure | 10 bar (145 psi) |
| Suitable fluids (pump) | Oils to SAE140, coolants, kerosene, diesel |
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Macnaught IBC Mounted Oil System Includes R300 Pump & Gun OS500G-01
SKU: A0145953 | Model: OS500G-01
The OS500G-01 is Macnaught's wall or IBC mount oil system with the R300S-01 3:1 pump and an unmetered HG20R-01 gun. It includes a Retracta oil hose reel with 1/2" x 15m hose, a pre-drilled mounting plate and all necessary fittings and hoses.
