Macnaught Inlet Swivel Set - 3/4" BSP Spare Part HG421S
Available
The Macnaught HG421S is the BSP inlet swivel for the HG100 high flow oil control gun. The swivel is where the hose connects to the gun and lets the gun turn without twisting the hose.
It is the BSP version. The NPT version is HG422S.
Where this product is used
- Replacing a leaking or worn inlet swivel on an HG100 gun with a BSP hose connection
- Repairing an HG100 gun rather than replacing it
Features
- The NPT swivel is HG422S
- HG100 swivel inlet is 3/4" BSPT or 3/4" NPT, and the outlet is 3/4" NPT
- Suits HG100-01, HG100-01-11, HG100-02 and HG100B-01
- The swivel O-rings (BS113 x 2 and a green dot O-ring) are items in the HG100-1K overhaul kit
- The HG100 gun is rated to a maximum working pressure of 105 bar (10500 kPa, 1500 psi)
- Never exceed the pressure rating of any component, and never point the nozzle at yourself or anyone else
Key specifications
| Specification | Detail |
|---|---|
| Brand | Macnaught |
| Part number | HG421S |
| Part type | Inlet swivel (BSP) |
| Thread | BSP (the NPT swivel is HG422S) |
| Fits | HG100 oil control guns: HG100-01, HG100-01-11, HG100-02 and HG100B-01 |
| Maximum working pressure of the HG100 gun | 105 bar (10500 kPa, 1500 psi) |
Supplied with
- Inlet swivel only
- Hose, gun body and overhaul kit are separate items
Related Macnaught products
- Macnaught 3/4" Hi Flow Control Gun Without - Non Drip Nozzle HG100B-01: Suits this product
- Macnaught Oil Control Gun - High Volume HG100-01: Suits this product
- Macnaught Inlet Swivel Set - 3/4" NPT Spare Part HG422S: Same part, other version
