Technical Specifications

• Delivery pressure up to 68,900kPa (10,000psi)
• Flexible 230mm (9") high pressure extension hose
• KY SUPERGRIP™ 3 jaw high pressure coupler
• Up to 0.68g per shot
• Heavy-duty 1.6mm thick barrel
• Robust zinc pull handle
• Wetted parts - Aluminium, steel, nitrile rubber, cork and nylon
• Maximum viscosity - Up to NLGI 2
• Compatible with 450g cartridges for contamination free greasing

Features & Benefits

• Can be filled from a bulk supply of grease- Economical & contamination free greasing
• 9mm diameter hand operated Filler / Bleeder Outlet- For use with Macnaught J3 grease pump or any other 9mm bulk fill grease pump
• Reversible follower- For cartridge or bulk applications
• Lock the plunge rod into the follower- For easier bleeding
• Machined barrel thread- Makes it easier to screw the barrel to the head
• Stepped Barrel- For easy grip
• Heavy-duty design and construction- Reduces wear & facilitates effortless pressure building
• Short stroke facility- Ability to boost greasing pressure using shorter hand strokes to easily clear blocked grease nipples
• Screw fasteners- No rivets for easy servicing
• Pistol grip and unique piston and valve arrangement- For easy one handed operation
• Flexible high pressure extension hose- Easier to grease hard to reach nipples
• Fully repairable- Provides a much longer service life
• Supergrip KY coupler- Positive no leak connection ensures grease gets to the bearing.
