Macnaught Latch Set SK133S
Available
The Macnaught SK133S is the latch set for Macnaught single pedestal metal hose reels. Replace the latch assembly when a reel will not latch because of a worn latch.
SK133s as one part suits the range, not split by model.
Where this product is used
- Replacing a worn latch on a single pedestal reel
- Workshop and site air, water, oil and grease reels
Features
- Latch set for single pedestal metal hose reels
- The reel latches after the first, second or third click, and a worn latch assembly means a reel will not latch
- Fitting a latch pawl repair means releasing tension and removing the drum, then re-tensioning with three full turns
- Do not attempt to remove the spring canister nuts
- Turn off and disconnect the supply line to the reel before maintenance
Key specifications
| Specification | Detail |
|---|---|
| Brand | Macnaught |
| Part number | SK133S |
| Part type | Latch set |
| Fits | Single pedestal reels MAS1020-01, MAS1220-01, MOS1220-01 and MGS0615-01 |
| Replaces | The reel latch set |
Supplied with
- Latch set
Resources
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Macnaught Latch Set SK133S
SKU: A0146027 | Model: SK133S
The SK133S is the latch set for Macnaught single pedestal metal hose reels MAS1020-01, MAS1220-01, MOS1220-01 and MGS0615-01. Fit it when a worn latch means the reel will not hold the hose.
