Maxigear SPGM Metric Screw Pitch Gauge, 0.25 - 6mm
Available
Maxigear screw pitch gauges are available in two thread forms: SPGM (metric, 0.25 - 6mm) and SPGBSP (BSP, 8 - 28). SPGM has 24 blades and SPGBSP has 6 blades.
These gauges quickly determine the pitch of various threads, with all leaves clearly marked with the size and a locking device at both ends to lock the leaves. The leaves are polished tool steel.
Where this product is used
- Determining the pitch of metric and BSP threads quickly
Features
- Metric (24 blades) and BSP (6 blades) versions
- All leaves clearly marked with the size
- Locking device at both ends to lock the leaves
- Polished tool steel
Key specifications
| Specification | Detail |
|---|---|
| Brand | Maxigear |
| Part numbers | SPGM and SPGBSP |
| Type | Screw pitch gauge |
| Thread forms | Metric and BSP |
| Material | Polished tool steel |
Choosing the right option
SPGM is the metric gauge (0.25 - 6mm) and SPGBSP the BSP gauge (8 - 28). For metric with BSW see the Metric/BSW 52 blade gauge and for BSW alone the BSW 28 blade gauge.
Other screw pitch gauges: Metric/BSW, BSW, UNC/UNF.
| Option | Part number | SKU |
|---|---|---|
| 0.25-6 | SPGM | A0112797 |
| 8-28 | SPGBSP | A0112794 |
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Maxigear Screw Pitch Gauge: 0.25-6
SKU: A0112797 | Model: SPGM
Maxigear SPGM: metric screw pitch gauge, 24 blades, range 0.25 - 6mm, polished tool steel.
