Metabo ASC 145 627381000 AIR COOLED Quick Charger
Available
The Metabo AIR COOLED charger range here covers the ASC 145 (order number 627381000) and the ASC 55 (order number 627047000). The sheets describe each as a charger for slide-on battery packs of all Volt classes (12 - 36V).
Both use the patented AIR COOLED charging technology, which cools the battery pack during the charging cycle. This gives short charging times. Output rating, charging current, charging times and weight differ between the two. Check the option table and the variant details for each order number.
Where this product is used
- Charging slide-on battery packs of all Volt classes (12 - 36V)
- Charging battery packs of the CAS brands
Features
- Patented AIR COOLED charging technology for short charging times, by cooling the battery pack during the charging cycle
- The battery packs are gently cooled to the required charging temperature and then kept at optimum temperature during charging
- It has a higher tool life of the battery packs and up to 30% shorter total charging time can be achieved
- Optimal communication between battery pack and charger for maximum service life of the battery packs
- 3-year warranty on all Metabo battery packs and chargers, irrespective of the number of charging cycles
- These chargers can charge all battery packs of the CAS brands
Key specifications
| Specification | Detail |
|---|---|
| Brand | Metabo |
| Models | ASC 145 and ASC 55 |
| Order numbers | 627381000 (ASC 145), 627047000 (ASC 55) |
| Battery voltage | 12 - 36V |
| Mains voltage | 220 - 240V |
| Mains frequency | 50 - 60Hz |
| Output rating, 627381000 (ASC 145) | 145W |
| Output rating, 627047000 (ASC 55) | 55W |
| Maximum charging current, 627381000 | 8A |
| Maximum charging current, 627047000 | 3 / 4A |
| Charging time for 18V/4.0Ah, 627381000 | 30 min |
| Charging time for 18V/4.0Ah, 627047000 | 80 min |
| Charging time for 18V/8.0Ah, 627381000 | 60 min |
| Charging time for 18V/8.0Ah, 627047000 | 160 min |
| Weight, 627381000 | 551g |
| Weight, 627047000 | 582g |
Choosing the right option
| Option | Part number | SKU |
|---|---|---|
| 551 g / 19.4 oz | 627381000 | A0174907 |
| 582 g / 20.5 oz | 627047000 | A0174906 |
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Metabo Air Cooled Charger: 551 g / 19.4 oz
SKU: A0174907 | Model: 627381000
The ASC 145 (627381000) is a quick charger with an output rating of 145W. Charging time is 30 min for an 18V/4.0Ah battery pack and 60 min for an 18V/8.0Ah battery pack.
