Pferd DS START segmented diamond cut-off wheel, 400mm (16")

The Pferd DS START is a general-purpose diamond cut-off wheel with a segmented rim for aggressive, fast cutting of building materials. The range has eight options from 100 to 450mm in diameter.

The DS START is a general-purpose segmented-rim tool for aggressive, fast cutting with high cutting performance and a good tool life. Key features are high-grade diamond, good cutting characteristics with short cutting times, and good ease of cutting with high economic efficiency.

Where this product is used

• Aggressive, fast cutting of concrete (medium-hard, reinforced and hard), aerated concrete, brick and asphalt (material guide for the DS type)
• It has Pferd diamond cut-off wheels for concrete, exposed aggregate concrete, clinker brick, hard stone, granite and other abrasive building materials

Features

• Segmented rim (shape DS) for fast cutting
• Diameters 100, 115, 125, 178, 230, 350, 400 and 450mm
• Maximum speed from 15,300rpm (100mm) down to 4,200rpm (450mm)
• Rim height (X) 7mm up to 230mm diameter, 8mm at 350mm and 10mm at 400 and 450mm
• Bore 20, 22.23 or 25.4mm, depending on the diameter

Key specifications

Choosing the right option

Cutting wet is preferred to dry where possible. Never exceed the maximum speed printed for the item. Pferd diamond tools conform to EN 13236 and carry the oSa mark, and its safety pictograms include wear eye protection, hearing protection and a dust mask, not permitted for face grinding, and do not use if damaged.

For tile cutting see: Pferd DG FL PSF Continuous Rim Diamond Cut-Off Wheel, Pferd DG START Turbo Diamond Cut-Off Wheel, Pferd DS AS Diamond Cut-Off Wheel.
