Pferd Mounted Point INOX EDGE Cylindrical 50 x 8 mm, Grit 30, 6 mm Shank - Pack of 5 (31378613)
The price shown is for the pack.
Available
Item 31378613 is an INOX EDGE cylindrical mounted point with a 50 x 8mm head in grit 30 on a 6mm shank. It is supplied as a pack of 5.
The INOX EDGE type is used for weld dressing on fillet welds, removing burrs and grinding chamfers on high-temperature-resistant alloys and stainless steel components. The cylindrical shape ZY is suited to grinding bores, radii and contours. It has a resinoid bond for this type, a recommended cutting speed of 35 to 50 m/s, and for this item an optimum speed of 19,000rpm and a maximum speed of 19,000rpm.
Where this product is used
- Weld dressing on fillet welds and removing burrs on stainless steel components
- Grinding chamfers on high-temperature-resistant alloys
- Highly suited to stainless steel (INOX), austenitic and ferritic: edge grinding
- Suited to steels up to 1,200 N/mm²: edge grinding, cast steel: edge grinding, stainless steel: surface grinding, grey and white cast iron: surface and edge grinding
Features
- INOX EDGE type, cylindrical
- Head size 50 x 8mm, grit 30
- 6mm shank, 40mm shank length (L2)
- Optimum speed 19,000rpm, maximum speed 19,000rpm
- Cool grinding, particularly suitable for temperature-sensitive materials
- High grinding comfort due to low-vibration grinding and high dimensional stability on edges
Key specifications
| Specification | Detail |
|---|---|
| Brand | Pferd |
| Designation | ZY 5008 6 AN 30 N5B INOX EDGE |
| Type | INOX EDGE |
| Shape | Cylindrical (ZY) |
| Head size (D x T) | 50 x 8mm |
| Grit size | 30 |
| Shank diameter (Sd) | 6mm |
| Shank length (L2) | 40mm |
| Bond | Resinoid |
| Abrasive code | AN |
| Abrasive | Aluminium oxide |
| Optimum speed | 19,000rpm |
| Maximum speed | 19,000rpm |
| Pack quantity | 5 |
Choosing the right option
Check that the 6mm shank suits your collet. A higher grit number is a finer abrasive. Keep to the maximum speed printed for the item. All Pferd mounted points are approved for a maximum operating speed of 50 m/s, the maximum permitted rotational speeds for each shank length and shank diameter are defined in DIN 69170 based on EN 12413 to avoid buckling of the shank, and at least 10mm of the shank must be clamped. Wear eye protection, hearing protection, a dust mask and gloves.
Other Pferd INOX EDGE mounted points: Pferd INOX EDGE Tapered Mounted Point, 32 x 32mm, Grit 24, Pferd INOX EDGE A 11 Mounted Point, 22 x 50mm, Grit 30.
Dressing stone: Pferd SE 702212 CU Dressing Stone, 70 x 12 x 22mm.
