Seco 150.10-5N-12 TGP35 Parting Off Insert
The price shown is for the pack.
Available
Genuine Seco Turning 150.10 Parting Off Neutral Insert (TGP35 - 12 Chipbreaker).
Key Specifications
| Grade | TGP35 |
|---|---|
| Hand | Neutral |
| Chipbreaker | 12 |
| Additional Details | Inserts in neutral version N are first choice since they normally achieve increased tool life. Inserts in neutral version N better chip control, high surface quality and allow higher cutting data compared to the handed (R-/L-) version. Carbide CVD |
About the 12 Chipbreaker
First choice for steel at low feed rates. 24° positive cutting rake angle. Excellent chipbreaking.
All About Seco 150.10 Parting Off Insert
Optimized for parting-off applications, the Seco 150.10 consists of a high-speed steel blade that holds the insert and a holder that retains the blade. This setup provides maximum stability, while the hot strength of the high-speed steel ensures the insert will be securely retained especially when the blade is hot. 150.10 is also available in combination with Jetstream Tooling® Duo. A high-pressure cooling system that provides directed coolant to the cutting edge by two streams to rake and clearance surfaces.
Resources
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Seco TGP35 Parting Off Insert - Neutral 12 Chipbreaker: 150.10-5N-12 TGP35
SKU: A0113035 | Model: 02707136
Designation 150.10-5N-12 TGP35. Turning 150.10 Parting Off Neutral Insert (TGP35 - 12 Chipbreaker)
Inserts in neutral version N are first choice since they normally achieve increased tool life.
Inserts in neutral version N better chip control, high surface quality and allow higher cutting data compared to the handed (R-/L-) version.
Carbide CVD
12 Chipbreaker
First choice for steel at low feed rates.
24° positive cutting rake angle.
Excellent chipbreaking.
All About Seco 150.10 Parting Off Insert:
Optimized for parting-off applications, the Seco 150.10 consists of a high-speed steel blade that holds the insert and a holder that retains the blade.
This setup provides maximum stability, while the hot strength of the high-speed steel ensures the insert will be securely retained especially when the blade is hot.
150.10 is also available in combination with Jetstream Tooling® Duo.
A high-pressure cooling system that provides directed coolant to the cutting edge by two streams to rake and clearance surfaces.
