Seco Turning Insert CCMT Insert Style - F1 7° Grade TP1501: CCMT09T302-F1,TP1501

SKU: A0115763 | Model: 02960837

Seco Turning Insert C Shape Code 3.97 x 0.2 x 9.53mm T Insert Type - F1 7° Grade TP1501 ± 0.13/± 0.05mm CCMT09T302-F1 Pack of 10

Turning Insert C Shape Code T Insert Type - F1 7° Grade TP1501

C shape code.

T Insert Type.

7° insert side clearance angles.

TP1501 Insert Grade

CVD Coated.

Duratomic® grade. Highly heat and wear-resistant grade extremely well suited for the productive general turning of steels and a useful backup in other material groups.

Ti(C,N) + Al2O3 + Used Edge Detection (Chrome)

F1 Chipbreaker Programme

Chipbreaker for positive inserts. Positive geometry with a sharp cutting edge gives easy-cutting properties.

Suitable for high feed rates at fine depths of cut in precision forgings and castings.

Indicative machining range: f = 0,1-0,5 mm/rev, ap = 0,2-3,0 mm.

Machining in bar automatics, for instance: f = 0,08-0,25 mm/rev, ap = 1-3 mm.

About Seco Turning Insert

Anything is possible when it comes to our broad selection of general turning grades and chip breakers.

Supporting inserts of different shapes, sizes, and thicknesses, we developed each of these solutions with the same goal in mind.

to boost the productivity and tool life in your turning applications.

Covering all material groups, this comprehensive range allows you to achieve your goals in terms of material removal rates, tool life, and surface finish.
