Seco CCMT09T304W-MF2,CP500 Turning Insert
The price shown is for the pack.
Available
Genuine Seco 80° rhombic (diamond) turning insert, Grade CP500 with MF2 chipbreaker. This is the CCMT insert style in grade CP500 (Carbide PVD), with the MF2 chipbreaker. It is used on CNC and manual lathes for turning. This page lists 4 options.
Key Specifications
| Grade | CP500 |
|---|---|
| Substrate / Coating | Carbide PVD |
| Insert Shape | 80° rhombic (diamond) (ISO shape code C) |
| Chipbreaker | MF2 |
| Insert Details | C shape code. T Insert Type. 7° insert side clearance angles. |
About Grade CP500
Carbide PVD. PVD Coated. Tough micrograin grade intended for finishing to medium-roughing of stainless steels but with wide applicability for example in steels and aluminium alloys. Especially suitable in intermittent cuts. (Ti,Al)N + TiN. W-
About the MF2 Chipbreaker
First choice for finishing with both positive and negative inserts. Chipbreaker suitable for finishing machining of steel, stainless steel and cast iron at high feed rates giving good surface finish. Indicative machining range: f = 0,05-0,60 mm/rev, ap = 0,5-4,0 mm.
About Seco Turning Inserts
Anything is possible when it comes to our broad selection of general turning grades and chipbreakers. Supporting inserts of different shapes, sizes, and thicknesses, we developed each of these solutions with the same goal in mind: to boost the productivity and tool life in your turning applications. Covering all material groups, this comprehensive range allows you to achieve your goals in terms of material removal rates, tool life, and surface finish.
Resources
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Seco Turning Insert CCMT Insert Style - MF2 7° Grade CP500: CCMT09T304W-MF2,CP500
SKU: A0115713 | Model: 02887216
Seco Turning Insert C Shape Code 3.97 x 0.4 x 9.53mm T Insert Type - W-MF2 7° Grade CP500 ± 0.13/± 0.05mm CCMT09T304W-MF2 Pack of 10
Turning Insert C Shape Code T Insert Type - W-MF2 7° Grade CP500
C shape code.
T Insert Type.
7° insert side clearance angles.
CP500 Insert Grade
PVD Coated.
Tough micrograin grade intended for finishing to medium-roughing of stainless steels but with wide applicability for example in steels and aluminium alloys.
Especially suitable in intermittent cuts.
(Ti,Al)N + TiN.
W-MF2 Chipbreaker Programme
First choice for finishing with both positive and negative inserts.
Chipbreaker suitable for finishing machining of steel, stainless steel and cast iron at high feed rates giving good surface finish.
Indicative machining range: f = 0,05-0,60 mm/rev, ap = 0,5-4,0 mm.
About Seco Turning Insert
Anything is possible when it comes to our broad selection of general turning grades and chip breakers.
Supporting inserts of different shapes, sizes, and thicknesses, we developed each of these solutions with the same goal in mind.
to boost the productivity and tool life in your turning applications.
Covering all material groups, this comprehensive range allows you to achieve your goals in terms of material removal rates, tool life, and surface finish.
