Description
Description
Descriptions
- Sutton Tools Blue Bullet panel drills have been developed to drill holes for rivets in flat and curved panels and used in sheet metal fabrication
- The blue finish reduces chip build up on the cutting edge and is a better choice when drilling ferrous materials
Specifications
Specifications
- Designation: N
- Material: High Speed Steel
- Finish: Blue
- Shank Form: A
- X: als
- Point Tolerance: h8
- Point Angle: 135°
- Point Form: Standard
- Cutting Edges: ul
Applications
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.15 %C)- 125 HB
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.45 %C)- 190 HB
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.45 %C)- 250HB
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.75 %C)- 270 HB
- Optimal for Steel - Low alloy & cast < 5% of alloying elements- 180 HB
- Optimal for Steel - Low alloy & cast < 5% of alloying elements- 275 HB
- Optimal for Cast Iron, Grey (GG) – 180 HB
- Optimal for Cast Iron, Nodular (GGG) – 160 HB
Applications
Applications
Features & Benefits
Features & Benefits
- 135° self-centering point minimizes wandering when starting and ideal for thin materials
- Flute length designed for shallow hole drilling no deeper than 1.25mm x diameter
- Made from M2 High Speed Steel (HSS) offering the best combination of strength, heat & wear resistance
- Blue surface finish for ferrous applications. The steam oxide finish prevents chip build-up on the cutting edges and reduces cutting friction, especially in low carbon steels
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Sutton D124 Panel Drill Bit - Shortie - HSS
Sutton D124 Panel Drill Bit - Shortie - HSS
SKU: A0004252
Type: Panel Drill Bit
- Wide Range
- Reliable Services
- Proven Trust
Available
The Sutton D124 Panel Drill Bit by Sutton Tools is a Panel Drill Bit with Blue finish. It offers diameter 1/8 in and is suitable for Steel - Non-alloy, cast & free cutting (~ 0.15 %C)- 125 HB.
- FREE SHIPPING OVER $299*
- RETURN AND EXCHANGE POLICY
Resources
Couldn't load pickup availability
Description
Description
Descriptions
- Sutton Tools Blue Bullet panel drills have been developed to drill holes for rivets in flat and curved panels and used in sheet metal fabrication
- The blue finish reduces chip build up on the cutting edge and is a better choice when drilling ferrous materials
Specifications
Specifications
- Designation: N
- Material: High Speed Steel
- Finish: Blue
- Shank Form: A
- X: als
- Point Tolerance: h8
- Point Angle: 135°
- Point Form: Standard
- Cutting Edges: ul
Applications
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.15 %C)- 125 HB
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.45 %C)- 190 HB
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.45 %C)- 250HB
- Optimal for Steel - Non-alloy, cast & free cutting (~ 0.75 %C)- 270 HB
- Optimal for Steel - Low alloy & cast < 5% of alloying elements- 180 HB
- Optimal for Steel - Low alloy & cast < 5% of alloying elements- 275 HB
- Optimal for Cast Iron, Grey (GG) – 180 HB
- Optimal for Cast Iron, Nodular (GGG) – 160 HB
Applications
Applications
Features & Benefits
Features & Benefits
- 135° self-centering point minimizes wandering when starting and ideal for thin materials
- Flute length designed for shallow hole drilling no deeper than 1.25mm x diameter
- Made from M2 High Speed Steel (HSS) offering the best combination of strength, heat & wear resistance
- Blue surface finish for ferrous applications. The steam oxide finish prevents chip build-up on the cutting edges and reduces cutting friction, especially in low carbon steels
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
Sutton D124 Panel Drill Bit - Shortie - HSS
Customer Service
Mon-Fri, 08:00-05:00pm
Call Us
(02) 9773-0122
Talk to a Sales Engineer
sales@aimsindustrial.com.au
Warehouse Address
Milperra NSW 2214, Australia
Your cart
(0)
Your cart is currently empty.
Not sure where to start? Try these collections:
Order note
Estimate Shipping
Product Comparison
| Description |
| Price |
| Vendor |
| Type |
| Product variants |
|
| The Sutton D124 Panel Drill Bit by Sutton Tools is a Panel Drill Bit with Blue finish. It offers diameter 1/8 in and is suitable for Steel - Non-alloy, cast & free cutting (~ 0.15 %C)- 125 HB. |
Regular price
From $17.88
Sale price
From $17.88
Regular price
Unit price
/per
| Sutton Tools | Panel Drill Bit |
Thread Diameter (inch)
1/8,#11,#20,#30
Overall Length (inch)
2 1/8
|
Choose your option
Sutton D124 Panel Drill Bit - Shortie - HSS
Sutton D124 Panel Drill Bit - Shortie - HSS
SKU: A0004252
Type: Panel Drill Bit
Available
The Sutton D124 Panel Drill Bit by Sutton Tools is a Panel Drill Bit with Blue finish. It offers diameter 1/8 in and is suitable for Steel - Non-alloy, cast & free cutting (~ 0.15 %C)- 125 HB.
