Sutton E147 Metric 3-6 Flute Roughing Endmill - 8% Cobalt TiCN - Long

Sutton E147 Metric 3-6 Flute Roughing Endmill - 8% Cobalt TiCN - Long

SKU: A0008992

Type: Machining Tool

$106.02
$106.02 $151.46
Inc. GST
⚙Carbide Construction
⚙Sutton Metric 3-6 Flute
📐Multiple Sizes Available
🔩Precision Milling Operations
🏗Metalworking & Manufacturing
☑High Speed Operation Rated

Available

Product Highlights −

Descriptions

  • For roughing applications
  • NR geometry allows for heavy cuts

Resources

Specifications

  • Designation: WN
  • Material: High Speed Steel Cobalt-8
  • Finish: TiCN
  • Shank Form: A
  • Helix Angle: R30
  • Point Tolerance: js14
  • Shank Tolerance: h6
  • Point Form: 45¬∞ Corner Chamfer
  • Type: NR (normal roughing)
  • Standard: DIN 844L

Applications

  • Optimal for Steel - Non-alloy, cast & free cutting (~ 0.15 %C)- 125 HB
  • Optimal for Steel - Non-alloy, cast & free cutting (~ 0.45 %C)- 190 HB
  • Optimal for Steel - Low alloy & cast < 5% of alloying elements- 180 HB

Features

  • NR (normal) Rougher R30 WN
  • Suitable for materials up to 1000 N/mm2
  • TiCN for longer tool life
