TechTop 415V Three Phase Aluminium Motor TA4B0754TAI

This is the TechTop 415V Three Phase Aluminium Motor (TA4B0754TAI).

TechTop is a leading global supplier of three phase and single phase electric motors, delivering IEC-frame general purpose motors for industrial drives, pumps, fans, and conveyors. TechTop motors are manufactured to IE2 and IE3 efficiency standards with IP55 protection and Class F insulation for reliable service in Australian industrial conditions.

TechTop three phase electric motors provide the efficiency, reliability, and IEC-standard dimensions required for direct replacement and new installation in industrial drive applications.

Where this product is used

Three phase motors are the standard prime mover for industrial pump, fan, compressor, and conveyor drive applications across Australian manufacturing and processing.

• Pump drives in water treatment, process, and HVAC applications
• Fan and blower drives in ventilation, combustion air, and process cooling
• Conveyor, compressor, and general industrial drive applications

Key specifications

Selecting the right option

Select the kW rating to match the driven load with an appropriate service factor. Choose pole count for the required synchronous speed — 2 pole (nominally 2900 RPM), 4 pole (1460 RPM), 6 pole (960 RPM) at 50 Hz. Frame size must match the coupling and mounting arrangement.

Product details
