Mitutoyo 530-100 Vernier Caliper, 100mm, 0.05mm

The Mitutoyo 530-100 is a compact 100mm metric vernier caliper for toolrooms, workshops and apprentices. It measures outside diameter, inside diameter, depth and steps. The main scale and vernier scale are satin chrome, so they are easy to read, and the sliding surfaces are raised.

It reads to 0.05mm and has an accuracy of ±0.05mm. Graduation is the smallest step on the scale. Accuracy is how close a reading is to the true size. They are different numbers, so check both. The depth bar is round, 1.9mm in diameter, and the lock screw holds the sliding jaw in place. A vernier caliper has no screen and no battery. You read the whole number from the main scale and the fine part from the sliding vernier scale. If you need a longer reach or a metric and inch dual scale, choose one of the 150mm, 200mm or 300mm models in the Series 530 range.

Where this product is used

• Checking small parts and short features at the bench
• Measuring outside diameters, inside diameters, depths and steps up to 100mm
• Apprentice and training use

Features

• Measures outside diameter, inside diameter, depth and steps
• Satin chrome main scale and vernier scale for easy reading
• Raised sliding surfaces
• Reads to 0.05mm with an accuracy of ±0.05mm
• Round depth bar, 1.9mm in diameter
• Lock screw holds the sliding jaw in position
• Mass of 128 g
• Optional depth base attachments are sold separately: 050083-10 and 050084-10

Key specifications

Supplied with

• Vernier caliper
• Not included: depth base attachment (optional, sold separately)
