Product Guides
FAQs on Sqwincher Hydration Products
Customers have been asking us these questions about the brand. We’ve compiled the answers here.
Read moreProduct Guides
Industrial Pump Guide: Centrifugal, PD Types & Selection
Centrifugal vs positive displacement pumps explained — selection by flow, head, viscosity, NPSH and duty, with Australian industry context.
Read more
How to Make Resin Completely Clear Using Boston Gloss Spray
This guest post is written by Danny Le Roux, and the product recommendations and technical instructions reflect his own. If you’ve owned a resin 3D printer for a while, you’ve likely at some point wanted to print something that mimicked glass, ice, crystal or another transparent surface. If so, then you’ve likely figured out by now that it’s harder than it looks. Most people who pick up a traditional bottle of clear resin from one of the big manufacturers like Elegoo expect translucent results, but are instead met with the following common letdowns: Cloudiness Yellowing An end product that frankly isn’t very clear There’s an easy trick to fix all that, and it only adds one extra step to your post-processing line-up to get the results you see in the image above. In this article, we discuss these simple steps: Print your model Clean and cure Colour your model with resin dyes (optional) Spray on a coat of Boston Gloss Spray (Clear) to make it instantly translucent Keep model out of direct sunlight What we used: Boston Gloss Spray (Clear) We used Elegoo transparent resin for the above, but this should work on any similar resins. If you want to colour your model like we did, we’d also recommend you pick up some resin dyes. The Process Step 1: Print your model The printing process goes as per usual – with the only caveat being that if you typically include resin dyes at this stage of the process, you’re going to want to hold off on that until post-processing stages. Step 2: Clean and cure Once you’ve printed your clear prints and removed them from the print bed, it’s business as usual. You can clean them in alcohol and cure them similarly to how you normally would, with the following notes: Alcohol: While 3D printer resin often comes off the bed sticky enough, clear resin is especially viscous. You’ll want to gently but properly scrub the models, then dab them dry with paper towels. Curing: It is a good rule of thumb to limit UV light exposure during curing to only what is necessary. UV light yellows transparent resin models. 2-3 minutes for either side of the model should be sufficient in most cases. If you do overcure your model, sometimes applying some more liquid clear resin to the outside of the model can reduce the impact. Just be aware that this can mar details. Step 3: Colour your model with resin dyes (optional) This step is optional, for if you’d like to add colour to your model while still keeping them translucent. Consider the shades you’re trying to achieve and try to settle on between 2 to 3 resin dye hues. For example, for a fiery effect, you might choose a dark red and a light orange, and for ice you may choose a dark blue and a very light blue. Apply these one at a time using a paintbrush, with a basic rule for lighting being to apply the darker shades to the lower extremities and the lighter shades to the upper body. With a paintbrush, you can carefully wetblend these together to achieve a striking ombré effect. If you do accidentally apply resin dye in excess, you can easily lighten it up with a bit of isopropyl alcohol or acetone. Step 4: Spray on a coat of Boston Gloss Spray (Clear) to make it instantly translucent For the main event, we applied Boston Gloss Spray to the outside of the model. The effects were instantaneous. Your model should appear translucent with just a few thin coatings, at about a 10 to 20 cm spray distance. The concept of using a clear gloss spray to render resin truly transparent has been a tried and tested trick among hobbyists, since before the dawn of 3D printing hardware. That said, it’s still a classic. Make sure you spray the gloss outdoors, in a well-ventilated area. This goes for all hobby aerosols. And one last tip going forward … Keep model out of direct sunlight This is akin to overcuring, given sunlight is just more UV light. It’s best to keep your prints out of direct sunlight, or consider applying an extra coat of UV-resistant varnish to protect them. AIMS’ Note on Buying Industrial Supplies Breadth and depth of brands and categories: Go with a supplier that offers a wide range of reputable brands across multiple categories and sub-categories. Bulk purchase discounts: For large orders, check if you can take advantage of volume leverage. Some suppliers offer business accounts* that give you access to special pricing (volume discounts), preferential support and even credit eligibility (subject to supplier approval, terms and conditions). Product and service information: Evaluate the completeness and usefulness of data in their online product listings. Prudent suppliers will include as much useful information as possible to help you assess and compare products. In terms of service info, the supplier’s FAQs (if any) will give you a good idea of their standard policies*, processes and commitments. Promotions: Check for ongoing promotional campaigns so you can get the best prices. Many suppliers run regular discount-based promos. Some can point you to government-hosted rebate programmes like the SafeWork NSW $1000 Small Business Rebate. Safety compliance: Make sure the product in question meets Australian safety standards and regulations, especially if there are relevant compliance requirements or work health and safety (WHS) laws that apply to your business or state. Look for relevant certifications and markings where necessary. Supplier reliability: Choose reputable suppliers with a proven track record of delivering quality products and reliable customer service. Warranty and support: Check warranty terms and after-sales support* options, as this can be crucial in case of product defects or performance issues. Lead time and availability: Confirm product availability and estimated delivery times to avoid delays in your projects. Returns: Familiarise yourself with the suppliers returns and exchange policy in case you receive incorrect or damaged items. Delivery: Clarify delivery terms, including estimated delivery times, shipping costs and who handles insurance during transit (where applicable). *Need help with a purchase decision? Contact us directly via chat or send an email to sales@aimsindustrial.com.au. This blog's sub-topics
Read more
FAQs on Fire-Resistant Anti-Static (FRAS) Belts
What Are FRAS Belts? FRAS stands for Fire-Resistant Anti-Static — a class of V-belts engineered for use in flammable or explosive atmospheres such as underground coal mines, grain handling, petrochemical sites, and chemical manufacturing. FRAS belts pass two combined tests: they self-extinguish after the ignition source is removed (fire-resistance), and they dissipate static charge so frictional build-up cannot trigger a spark (anti-static). Anti-static V-belt electrical conductivity is most commonly tested to ISO 1813, with fire-resistance demonstrated through vendor declarations and supporting Australian mining test protocols. The full selection and compliance breakdown sits in the body below. What does FRAS stand for in mining? FRAS stands for Fire-Resistant Anti-Static. The term is most commonly used in Australian coal mining, where the NSW Resources Regulator's TRG 3608 (Non-metallic materials for use in underground coal mines and reclaim tunnels — which replaced the earlier MDG 3608) sets the test methods used to qualify power transmission belts for underground installation on conveyors, fans, and drives. When things get hot and materials are flammable, your everyday industrial belt won't cut it. That is where FRAS belts come in. In this article, we answer these questions: How are FRAS belts different from regular belts? What benefits do they offer over regular belts? What are the differences between anti-static, fire-resistant and FRAS belts? Are heat-resistant and oil-resistant belts just as good as FRAS belts? Which industries use FRAS belts? Are PIX FRAS belts good? How are FRAS belts different from regular belts? FRAS belts are much like your regular industrial belts in terms of construction and function, and both serve the same core purpose of transmitting power or moving materials. Nevertheless, here are what make FRAS belts different: Fire resistance: As the name implies, FRAS belts are made of compounds that resist ignition and, at least, limit the spread of fire if it ever does ignite from an external source. Anti-static properties: FRAS belts are engineered to dissipate static electricity to prevent dangerous sparks that could potentially ignite flammable materials. Materials: FRAS belts use specific compounds designed to resist ignition, slow fire spread and dissipate static electricity. These materials are not present in standard industrial belts. Applications: FRAS belts are designed for specific environments where fire hazards, flammable dust or vapors are present, such as in petrochemical and mining plants. Certifications: FRAS belts often carry safety certifications that regular belts don’t have. For instance, the PIX belts that we sell are ATEX-certified (for explosive atmospheres). Other brands have ISO1813 (fire resistance standards). FRAS belts are typically paired with Ex-rated motors in classified zones — see our hazardous area electric motors guide for the AS/NZS 60079 framework that governs the matched drive train. Cost: FRAS belts are generally more expensive due to specialised materials and manufacturing processes.Note: They are not necessarily better than regular and anti-static / static-conductive / static-dissipating belts. What benefits do they offer over regular belts? Insurance benefits: Using FRAS belts could potentially lower your premiums due to their reduced risk profile, thereby practically justifying (and offsetting) their higher price. Prevention of static-induced hazards: Because they are designed to significantly reduce static buildup, they prevent ignition of flammable substances in the surrounding area. Reduced fire risk: They are made by design to minimise the chance of a fire starting due to the belt itself. What are the differences between anti-static, fire-resistant and FRAS belts? Property Anti-static belt Fire-retardant belt FRAS belt Fire resistance No Yes Yes Static dissipation Yes No Yes Anti-static belts (aka static-conductive / static-dissipating belts) Primary function: They are designed specifically to prevent the buildup of static electricity, which is common in industrial settings where moving belts can generate a significant buildup of static charge. A static-conductive belt safely channels this electricity away, preventing sparks and potential hazards. Most Gates belts we sell are specified as static-conductive and ISO 1813-certified: Fire safety: They offer no inherent fire resistance, so they can still ignite and contribute to a fire if exposed to flame or high heat. Applications: They are useful in environments where static discharge could damage sensitive electronics or create sparks that ignite flammable vapors or dust, such as in (1) electronics manufacturing, where static electricity can damage sensitive components, and (2) packaging, where static can make materials cling and cause production / quality issues.Note: Anti-static belts that are not fire-resistant may still pose a hazard if they come into contact with flames or extreme heat, so do not use them in places strictly specified for FRAS belts. Fire-retardant belts Primary function: They are manufactured with materials that resist ignition, practically lowering the possibilities of catching fire and slowing down the spread of flames. Static protection: They don’t usually have any anti-static properties. Applications: They are suitable for environments where there is a risk of the belt itself catching fire but where static buildup is not a major concern.Note: All FRAS belts are fire-retardant, but not all fire-retardant belts are FRAS. If you need protection from both fire spread and static electricity hazards, FRAS is the way to go. Fire-Resistant Anti-Static (FRAS) Belts As discussed in earlier points, they combine the properties of both anti-static and fire-retardant belts, so they can both (1) resist fire spread and (2) dissipate static electricity, such as these PIX belts: Are heat-resistant and oil-resistant belts just as good as FRAS belts? They are inherently different, and they are not interchangeable in terms of application. Here they are side-by-side: Feature Heat-resistant belt Oil-resistant belt FRAS belt Primary purpose and ideal applications Transporting hot materials (eg furnaces) Transporting oily materials (eg food processing) Preventing ignition and static buildup in flammable environments (eg underground mines) Material focus High temperature resistance Oil resistance Fire resistance and anti-static properties Fire resistance No No Yes Static dissipation No No Yes Temperature resistance High resistance -- up to 250° C (depending on grade) Limited, often low or moderate Some are heat-resistant Oil resistance Limited, as some variants have basic resistance High resistance Some are oil-resistant FRAS properties No No Yes Which industries use FRAS belts? They are ideal for – and most of the time, needed for safety compliance in -- hazardous environments with both fire risks and potential for static electricity buildup, such as in: Mining where there are underground coal dust and potential methane and gas leaks Grain handling and woodworking where there could be explosive sawdust and similar flammable dust particles Chemical and petrochemical plants where even a tiny spark where flammable vapors are present could start fires. Any environment with flammable dust where it -- if accumulated or confined in surfaces -- could come into contact with a heat source or spark that can ignite and trigger combustion Are PIX FRAS belts good? Yes, they generally have a good reputation and are considered reliable for their intended purpose, thanks to their: Certifications: PIX FRAS belts comply with important safety standards, namely ATEX (specially designed for safe use in potentially explosive atmospheres, such as these FRAS v-belts), ISO 1813 (anti-static requirements to reduce the risk of sparks in flammable environments) and IS 2494 Part-II (fire resistance standards important in mining and other potentially hazardous settings). Specialised construction: They are manufactured with special rubber compounds formulated to resist fire and minimise static buildup and discharge. Range of options: PIX offers various FRAS belts (XC, XS, XR) catering to different applications, drive configurations and temperature requirements. Manufacturer reputation: PIX Transmissions is an established belt manufacturer with a global presence, known for quality products. Bottom line: The best type of belt depends on the specific hazards within your work environment. It is best to consult with a relevant, qualified engineer if you are unsure of what belt to specify. If the job involves fire hazards, err on the side of caution. Don't gamble with standard industrial belts and go with FRAS belts instead, as they provide the most comprehensive protection and offer a vital line of defense for those "just in case" moments. Need help? Please email us at sales@aimsindustrial.com.au. If a FRAS belt is showing problems — slipping, glazing, cracking, premature wear — work through the symptom-cause-fix diagnostic in our V-Belt Problems & Solutions Guide before fitting a replacement. AIMS' Note on Safe Use of Belt-Driven Systems Power down: Before any inspection, maintenance, or adjustment, make sure to completely shut down the power to the machine and apply a lockout/tagout (LOTO) device to prevent accidental restarts. Right belt for the system: Keep in mind that v-belts (especially cogged / notched / wrapped belts) are different from synchronous /timing / ‘toothed’ belts. Some mistake the cogs for teeth but remember that cogged belts run on V-shaped pulleys that do not have teeth. Are you operating where flammable substances are present? Maybe you need fire-resistant anti-static (FRAS) belts – or maybe heat-resistant and oil-resistant belts will do. We compared them in this FAQ. Safe attire: Avoid loose clothing, jewelry and long hair that could get caught in the moving parts. Ensure proper fit of workwear without compromising comfort, dexterity and protection. Tie back long hair and secure loose items. Safeguards in place: Never operate a belt-driven system with the guards removed or bypassed. These guards are there for your protection. Maintenance and replacement: Regularly inspect belts and pulleys for wear and tear. Maintain proper belt tension and alignment as specified by the manufacturer. When replacing the belt, make sure you get the proper fit and measurement of the system. These accessories and maintenance kits (eg alignment tools, belt measurers, pulley gauge sets, spacers, tensioners etc) come in handy. Cleanliness: Keep the area around belt drives free of debris and clutter that could get caught or cause a fire hazard. (Refer to our content library's sub-index of articles about belt-driven systems and electric motors for more information.) This blog's sub-topics Need a specific lubricant? The AIMS Lubrication range covers greases, oils, sprays and specialty products. Browse anti-vibration mounts at AIMS Industrial for application support and stock confirmation. Need gates? Browse the AIMS range at gates.
Read more
V-Belt Storage Guide: Temperature, Humidity & Shelf Life
Belts don't fail only on the drive. They fail in the storeroom too — slowly, invisibly, until you fit one and it cracks in a week. Heat, ozone, humidity, sunlight, and bad hanging habits all chip away at rubber and tensile cords long before installation. Get storage right and a quality belt will sit on the shelf for years and run for years more. Quick Reference — Belt Storage Conditions The fast version. Hold to these and you'll get the manufacturer's full shelf life out of every belt on your rack. Parameter Ideal range Why it matters Temperature 10–25°C (max 29°C) Heat accelerates rubber aging. Above 29°C, shelf life roughly halves for every 15°F (~8°C) rise. Relative humidity 50–70% RH Above 70% promotes mould/mildew; below ~40% accelerates rubber drying and cracking. Light No direct sunlight or UV UV degrades rubber and polyurethane. Sun through a workshop window is enough to damage exposed belts. Ozone Away from motors, welders, ozone generators Ozone is the single fastest rubber aging accelerator. Causes surface cracking on flex points. Position Hung straight on wide pegs OR laid flat No kinks, no folds, no compression. Bent storage deforms the tensile cord and prints a memory the belt won't shake off. Stock rotation FIFO (first in, first out) Belts have a real shelf life. Rotate by date code so the oldest stock fits first. Why Storage Matters A new V-belt or synchronous belt is a precision-engineered composite — rubber compound, tensile cords (polyester, aramid, or steel), fabric jacket, and on synchronous belts, polyurethane teeth. Every one of those materials degrades when stored wrong. The failure modes you'll see in a poorly stored stock: Surface cracking — ozone and UV attack on the belt back. Hairline cracks turn into chunks under flex. Rubber hardening — heat exposure cures the rubber further until it loses flexibility. The belt rides high in the groove and slips. Mildew and mould — high humidity. Cosmetic on rubber, but on fabric-jacketed belts it weakens the jacket. Tensile cord damage — folding, kinking, or coiling tighter than the minimum bend radius. Cords break in invisible spots; the belt fails under load. Deformation memory — long-term storage under tension or compressed under stacked stock. The belt runs untrue, vibrates, and wears the pulleys. Tooth shear (synchronous belts) — UV degradation of polyurethane plus deformation. Teeth shear off during start-up. None of this shows up in a casual visual check. A belt that's been stored badly for two years will look fine until you fit it. Temperature The Gates Industrial Power Transmission Preventive Maintenance + Safety guide gives the cleanest published figures, and they're consistent with what Optibelt, Continental, and Carlisle publish. Cited in many manufacturer manuals:. Ideal: 10–25°C. A normal climate-controlled warehouse or store room. Acceptable: up to 29°C (85°F). Beyond this, the manufacturer-rated shelf life starts to drop. Marginal: 29–46°C. Shelf life roughly halves for every 8°C above 29°C. A belt rated for 5 years at 25°C will be down to ~2.5 years at 33°C, ~1.25 years at 41°C. Do not store: above 46°C (115°F). Cured rubber starts permanent degradation. Australian context: a colorbond shed in Mt Isa, Karratha or the Pilbara summer easily sits above 40°C internal temperature. Spare belts kept on a top shelf in that environment will not last their rated life. Ground-floor, internal-wall, climate-buffered storage is the difference between a 5-year belt and an 18-month belt. Humidity Belts tolerate a wider humidity band than temperature, but both extremes cause problems. Ideal: 50–70% RH. Too dry (below ~40% RH): rubber loses plasticisers over time, becomes brittle. Risk in Mt Isa, Kalgoorlie, dry inland depots. Too humid (above 70% RH): fungus and mildew form on the belt surface. Mostly cosmetic on rubber, but fabric jackets weaken and adhesives can be affected. Risk in Cairns, Darwin, coastal NQ. If you store belts in a humid coastal warehouse, a sealed plastic tote with silica gel desiccant is cheap insurance for long-shelf-life items. UV & Light Ultraviolet light breaks down rubber polymer chains. The damage is cumulative and invisible until cracking starts. Worst: direct sunlight. A belt sitting in afternoon sun through a window can degrade visibly in 6–12 months. Bad: fluorescent and some LED tubes emit low-level UV. Long-term ambient lighting on a brightly lit rack still accumulates damage. Acceptable: dim or shaded storage. Original cardboard packaging is genuinely protective — keep belts in their boxes or bags until they're needed. Polyurethane synchronous belts (Gates Poly Chain GT Carbon and similar) are more UV-sensitive than rubber V-belts. Treat them as light-sensitive stock. Ozone Red flag. Ozone is the fastest rubber aging accelerator there is. A few ppm of ozone in a closed room will visibly crack belt rubber within months, even with everything else right. Sources of ozone in industrial workshops: Electric motors and generators — brush arcing produces ozone. A motor room with poor ventilation is one of the worst places to store belts. Arc welders — both stick and MIG welding generate ozone. Photocopiers and laser printers — small but constant ozone source. Ozone generators — used in some cleaning, food, and water treatment processes. High-voltage switchgear, transformers — corona discharge. Practical fix: separate belt storage from electrical and welding areas. A dedicated cool, dark cupboard on an external office wall is dramatically better than a top shelf in the workshop. If you have to share space, ventilation that exchanges air rather than recirculating it helps. Operating belt-driven equipment in hazardous-area environments raises related concerns — see our FAQ on electric motors in hazardous areas. Storage Position How you hang or stack the belt matters as much as the room it's in. Tensile cords have a permanent memory — bend a belt sharply on a small peg for six months and it'll never run true again. Method Use it? Notes Hung on a wide peg or "saddle" Yes — preferred for V-belts Peg diameter must be at least the minimum recommended pulley diameter for that belt. Wider is better. A narrow nail is worse than laying the belt flat. Laid flat on a shelf Yes — preferred for synchronous and variable-speed belts One belt deep ideally. Don't stack heavy items on top. Nested (synchronous belts up to ~3000 mm) Yes — manufacturer-recommended for shipping and shelf storage Lay one belt on its side on a flat surface, nest smaller belts inside. Stack nests up to 8 high if needed. Coiled (V-belts only, large sizes) Sparingly Coil to the natural bend direction. Coil diameter must be no smaller than minimum recommended pulley diameter for that belt. See the coiling table below. Folded or kinked Never Permanently damages the tensile cord. Bin the belt. Tied with rope or wire Never Bites into the cord at the tie point. Common storeroom shortcut, always wrong. Stacked on the floor Never Water leaks, foot traffic, forklift damage, dust ingress, compressed bottom belts. Under tension on a machine in storage Never (long term) If equipment is stored more than 6 months, relax belt tension or remove the belts. Bend Radius & Coiling Every belt has a minimum bend radius — the tightest circle it can be bent around without damaging the tensile cord. As a rule of thumb, the minimum bend radius equals the minimum recommended pulley diameter for that belt section. For V-belts being stored on pegs or coiled: Z/SPZ section: minimum bend ~63 mm diameter A/SPA section: minimum bend ~80 mm diameter B/SPB section: minimum bend ~125 mm diameter C/SPC section: minimum bend ~200 mm diameter D section: minimum bend ~315 mm diameter If you coil a V-belt for storage, coil it in the natural bend direction (the way it ran on the drive). One coil produces three loops; two coils produces five loops; and so on. Coiled belt diameter must stay above the minimum bend. For synchronous belts: coiling is generally not recommended for belts under 3000 mm. Longer belts can be rolled for shipping, but the bend radius must stay above the minimum recommended pulley size. Use a cardboard tube of the right diameter at the bend point if the roll has to be tight. Shelf Life Properly stored, belts have a real shelf life — but it's longer than most people assume. Belt type Typical shelf life (at 25°C, 50–70% RH, dark) Classical V-belt (A, B, C, D) ~6 years Narrow wedge V-belt (SPZ, SPA, SPB, SPC) ~5–6 years Cogged / raw-edge V-belt ~5 years Banded (joined) V-belt ~5 years Variable-speed belt ~3–4 years (more storage-sensitive) Synchronous timing belt (rubber) ~5–7 years Polyurethane synchronous belt (Poly Chain, etc.) ~7–10 years FRAS belts ~5 years (don't compromise the FRAS rating with bad storage) — see our FRAS belt FAQ Above 29°C, halve those figures for every ~8°C of additional temperature. Rotate stock FIFO (first in, first out). The simplest system is a date label on each box at receipt — when you pull a belt to fit, take the oldest dated one first. Date Code Decoding Most premium belts carry a date code printed on the back or the inside of the belt. Decoding it tells you what's been sitting in stock the longest. Brand Date code pattern Example & reading Gates 4 digits: day of year (1–365) + last digit of year. May appear with a preceding letter for plant code. 1547 = day 154 of a year ending in 7 (i.e. 3 June 2017 or 2027 — confirm from context) Optibelt 2-digit week + 2-digit year (week/year). 2624 = week 26 of 2024 Continental ContiTech Variable — often week/year or Julian + year. — Carlisle / Timken Belts Variable batch code. — If the code is illegible, treat the belt as undated and rotate it out next. If a belt has no code at all and came from an unknown supplier, treat with caution — date codes are a quality signal. Pre-Installation Inspection Before you fit a belt from stock, run a one-minute visual and tactile check. The Gold Standard checklist: Date code — within shelf life? If borderline, use it on a low-load drive first rather than a critical one. Belt back — any surface cracks, crazing, or hairline cracking? That's ozone or UV damage. Bin the belt. Sidewalls (V-belts) — clean, intact, no fraying or fabric exposure? Wedge section should be square. Teeth (synchronous belts) — full, undamaged, no shear lines at the base of teeth. Tensile cord — no visible cord at the surface, no kinks, no folded creases. Smell — fresh rubber smell good; sour, chemical, or musty smells = contamination or mould. Flexibility — bend the belt to its normal running curve. Should flex smoothly without crackling or stiffness. Length and section match — verify against the part number on the box and the belt's printed code. Numbers must match exactly. If anything's off, set the belt aside and pick another. The cost of a replacement belt is less than the cost of an unplanned shutdown a week after install. For diagnosing belts that have failed in service, see our V-belt problems and solutions guide. Handling Don'ts Storeroom habits that quietly ruin belts: Don't drag belts across the floor. Picks up grit, oils, and scuff damage on the back. Don't drop boxes from height. Sudden impact can fracture aramid or steel cords in heavy belts. Don't use belts as straps — to tie loads, hold doors, lift gear. Common in shed culture; always wrong. Don't expose to oils, solvents, fuels, adhesives, acids, alkalis. Any of these soften or chemically attack the rubber. Even brief contact during handling can leave a soft spot. Don't store with sharp tools or fasteners loose in the same bin. Cuts and punctures are killers. Don't pack tight in cartons. Belts compress and deform under load. Original packaging is sized to avoid this. Don't write on belts with permanent marker or paint pen. Solvents in the ink may locally degrade the rubber. Mark the box, not the belt. Returning Belts to Stock A belt that's been pulled out of stock, taken to the job, then not used — can it go back on the shelf? Yes, if: still in original packaging, undamaged, no signs of stress, contamination, or sunlight exposure during the trip. No, if: it's been fitted to a pulley (even briefly), tensioned, contaminated with oil/grease/solvent, dropped, kinked, or left in direct sun in a vehicle. Never: a used belt. Even if a belt was on a machine for an hour, the tensile cord has been load-cycled. It's no longer new stock. When in doubt, label it "field-returned, second pick" and use it on a non-critical drive before reaching for a fresh belt. Setting Up a Belt Store A workshop belt store doesn't need to be elaborate, but the geometry pays off. The minimum useful setup: Location: internal wall, away from workshop heat and welding. Office side of a partition is ideal. Climate-buffered, dim, draft-free. Storage racks: wide pegs (50 mm+ diameter for medium belts, 100 mm+ for large) or shelving with belt-sized compartments. No nails, no thin rods. Original packaging on shelves: store synchronous and variable-speed belts flat in their original boxes. FIFO bins for fasteners on the same rack: oldest stock at the front, newest behind. Same principle applies to belts. Ventilation: air exchange with the outside (or a non-motor part of the building) keeps ozone levels low. Temperature monitoring: a min/max thermometer in the belt store is a $20 item that tells you whether your storage is doing its job. Lighting: dim and shielded. LED downlights are fine if not directly on the belts. Inventory list with date codes: simple spreadsheet or even a clipboard on the door. Track what's there, what's oldest, what needs ordering. For matching belts to the right drive, check our V-belt size chart and the how to measure a V-belt guide before ordering. AIMS' Note on Belt Procurement The other side of storage strategy is procurement strategy. Some thoughts from our side of the counter: Stock what fails fast, JIT what fails slow. If a belt drives critical production and a 24-hour delay costs you thousands, keep two spares. If it's a low-load drive on a non-critical machine, order on demand. Standardise where you can. Fewer belt section types across your fleet = simpler storage = lower obsolescence risk. Talk to maintenance about consolidating to common sections at the next drive redesign. Buy from a stocking distributor. AIMS holds Gates, Optibelt, and other premium belt brands in Sydney. Same-week delivery across most of Australia means you can hold less and rotate faster. Don't cheap out. A no-name belt at 40% of the price of a Gates Predator will rarely give 40% of the service life. The total cost of a premature belt failure — downtime, labour to refit, potential damage — dwarfs the saving. Review stockholding annually. Date-coded belts older than half their rated shelf life should either be used or written off. Ageing stock is wasted shelf space. Browse our full range: all power transmission belts, industrial V-belts, synchronous/timing belts, banded V-belts, pulleys, and drive accessories. Gates is our flagship brand — see the full Gates power transmission range. Choosing between belt and chain drives for a new install? Our Belt vs Chain Drives comparison walks the trade-offs across efficiency, torque, environment and lifecycle cost. Storing ride-on mower belts off-season? The same temperature, humidity and bend-radius rules apply — see our Ride-On Mower Belt Guide for the mower-specific notes. Frequently Asked Questions How long can I store a V-belt before it goes off? Stored properly (cool, dry, dark, no ozone, no kinks), a classical V-belt has a shelf life of around 6 years and a narrow wedge V-belt around 5–6 years. Above 29°C the shelf life roughly halves for every 8°C of additional temperature, so a belt sitting in a 40°C shed might only last 2 years on the rack. What's the ideal temperature for belt storage? 10–25°C is ideal. Up to 29°C is acceptable. Storage above 46°C is not recommended at all — the rubber starts to undergo permanent degradation. Can I store belts in a shipping container or shed? Only if internal temperatures stay below 29°C. In most of Australia, an uninsulated shed or container hits 40°C+ in summer. Either insulate and ventilate the space, or move the belt store inside an office or climate-buffered area. How does humidity affect belts? Above 70% RH, mould and mildew form on belt surfaces — mostly cosmetic on rubber, but it weakens fabric jackets. Below 40% RH, rubber slowly dries out and loses flexibility. Aim for 50–70% RH. Why is ozone such a big deal? Ozone attacks rubber polymer chains at a molecular level, causing visible cracking on flex points. Electric motors, arc welders, photocopiers, and high-voltage gear all generate ozone in small quantities. In a confined motor room with poor ventilation, the concentration is enough to age belts noticeably within months. Keep belt storage separate from electrical and welding areas. Can I hang belts on a nail? No. The nail bends the belt around too small a radius, deforming the tensile cord. Use a wide peg or "saddle" — diameter equal to or larger than the minimum recommended pulley diameter for that belt section. Can I coil a V-belt for storage? Yes, sparingly, and only V-belts. Coil in the natural bend direction (the way it ran). Coil diameter must stay above the minimum recommended pulley diameter for that belt section. Synchronous belts under 3000 mm should not be coiled — store them nested flat or laid on a shelf. How do I read a Gates belt date code? Gates date codes are typically a 4-digit number on the back of the belt: the first three digits are the day of the year (1–365) and the fourth digit is the last digit of the year. So 1547 could mean day 154 of a year ending in 7 — confirm the decade from invoice or supplier context. What's FIFO and why does it matter for belts? FIFO is "first in, first out" — use the oldest stock first. Belts have a real shelf life, so a belt sitting at the back of the rack for 4 years is closer to end-of-life than the new arrival behind it. Date-label every box at receipt and pull from the oldest end. Can I store belts under tension on a machine that's not running? Not long term. If equipment is shelved for more than 6 months, either relax belt tension or remove the belts entirely and store them on the shelf. Belts under load develop deformation memory and run untrue when the machine restarts. What's the difference between storage life of a rubber V-belt and a polyurethane synchronous belt? Polyurethane synchronous belts (Gates Poly Chain GT Carbon, etc.) typically have a longer shelf life — 7–10 years — than rubber V-belts (5–6 years). But polyurethane is more UV-sensitive, so they need genuinely dark storage to hit that figure. Are FRAS belts more storage-sensitive than standard belts? Not significantly more sensitive in storage, but poor storage that damages the rubber can compromise the FRAS (fire-resistant anti-static) rating. If a FRAS belt has been heat-aged or UV-degraded, don't trust the FRAS performance for a hazardous-area drive. More on FRAS belts here. Can I return a belt to stock if it was taken out but not fitted? Yes, if it's still in the original packaging, undamaged, and hasn't been exposed to sun, oil, or heat during the trip. No, if it's been on a pulley even briefly, tensioned, contaminated, or kinked. Mark field-returned belts with a sticker and use them on non-critical drives first. What's the worst place I could store belts? An uninsulated tin shed in summer, on a top shelf under a skylight, next to the workshop's main electric motor, on a thin nail. That combination ticks every accelerator: heat, UV, ozone, deformation. Avoid all four. How much stock should I hold of each belt? Depends on criticality and lead time. For a critical drive with 24-hour lead time and high downtime cost, hold 1–2 spares. For non-critical drives with same-week supply from a stocking distributor, hold zero or order on demand. Review annually — ageing stock is wasted shelf space, and a date-coded belt past half its shelf life should be used or written off. Can I store belts outdoors under cover? No. Even under cover, outdoor storage exposes belts to wide temperature swings, humidity extremes, UV-reflected light, and potential moisture. Belt storage belongs indoors, climate-buffered, and away from sun. People Also Ask — V-Belt Storage and Handling Q: How should V-belts be stored to prevent premature deterioration? V-belts should be stored in a cool, dry location away from direct sunlight, ozone sources such as electric motors and welding equipment, heat, and solvents. Belts should be kept in their original packaging or hung on proper belt racks without sharp bends, kinks or being coiled too tightly, as deforming the belt cross-section can cause cracking and reduce service life. Q: What is the maximum recommended storage period for V-belts? Under correct storage conditions, most manufacturers recommend using V-belts within three to five years of manufacture. The manufacture date is typically encoded in the belt markings. Belts stored beyond this period should be inspected carefully for surface cracking, hardening or tackiness before installation. Q: Why should V-belts never be rolled or folded for storage? Folding or tightly coiling a V-belt causes permanent set in the rubber compound and can crack the tension cords running through the belt. Once the internal cords are damaged the belt will exhibit premature fatigue, reduced power transmission capacity, and shortened service life even if the damage is not visible externally. Q: What is the correct way to install a V-belt without damaging it? V-belts should always be installed by reducing the centre distance between pulleys until the belt can be seated by hand, never by using a lever or screwdriver to force the belt over the pulley rim. Forcing a belt over a pulley can fracture the tension cords and cause immediate or early failure.
Read more
Hazardous Area Motors: Ex Protection & AS/NZS 60079
Selecting motors for hazardous areas is a compliance and safety task — not a procurement one. A plain-English guide to AS/NZS 60079, zone classification, EPLs, Ex protection types, and how to read an Ex marking.
Read more
Tap Magic Cutting Fluid Guide: Selection by Material
Tap Magic is a US-made cutting fluid brand (Steco Corporation) used worldwide for tapping, threading, drilling and reaming. The range covers steel, stainless, aluminium, food-grade work and water-mix machining. This guide pulls together which Tap Magic variant suits which job, the safety side of using it, and where it sits against the wider cutting fluid market AIMS stocks. Tap Magic isn't always the right choice — for high-volume CNC flood work you may want a soluble or synthetic coolant, and on cast iron most workshops still run dry. We cover those calls honestly below. Tap Magic Quick Reference — Variant by Material Pick a Tap Magic variant by the metal you're cutting. Detail and trade-offs are in the sections below. Material Recommended Tap Magic Variant Key Property Mild & carbon steel Tap Magic EP-Xtra Chlorine-free extreme-pressure formula Stainless 304 / 316 Tap Magic EP-Xtra Extreme pressure, chlorine-free for food/medical context Alloy & tool steel Tap Magic EP-Xtra Handles hardened material, reduces tap breakage Aluminium Tap Magic Aluminium Sulphur-free, prevents galling on alu Brass & copper Tap Magic Aluminium Sulphur-free — no staining on yellow metals Food / medical / pharma Tap Magic Eco-Oil Food Grade NSF-compatible base oil Production / flood / mist Tap Magic H2OX Semi-Synthetic Water-miscible, suits flood or MQL Heavy tapping / Xtra Thick jobs Tap Magic Xtra Thick Cling formula — vertical tapping, large diameters What Is Tap Magic? Tap Magic is a line of cutting and tapping fluids manufactured by The Steco Corporation, founded in 1953 and based in Little Rock, Arkansas. The brand has been a workshop staple in the US and exported globally for decades. The bottles you see in Australian workshops — the small 4 oz bottle with the brush-cap, the 16 oz pour bottle, the 12 oz, and the larger 5 L and 25 L drums — are Steco product imported under Tap Magic's own labelling. The brand's reputation rests on two things: a thicker-than-typical formula that clings to the tap or drill while it cuts, and a chlorine-free EP (extreme-pressure) chemistry that gives clean threads without the environmental and skin-contact baggage of older chlorinated fluids. AIMS stocks the core Tap Magic range — see /collections/tap-magic for the live SKUs. Tap Magic Product Range Tap Magic EP-Xtra EP-Xtra is the flagship cutting and tapping fluid in the AIMS range. Chlorine-free, extreme-pressure formula. Suits all ferrous metals (mild steel, alloy steel, stainless 304/316, tool steel) plus titanium and exotic alloys. This is the variant to reach for on tapping jobs in stainless where you want the EP additive but don't want chlorinated chemistry near food-grade or medical-grade work. Sizes at AIMS: 4 oz, 12 oz, 16 oz, 5 L, 25 L (SKU range A0112721, A0112722, A0145193, A0145194, A0145195). Tap Magic Aluminium Sulphur-free and chlorine-free formula specifically for aluminium, brass, copper and other non-ferrous metals. Sulphur stains yellow metals (brass and copper go dark within minutes); chlorine isn't needed on alu and adds environmental cost. Tap Magic Aluminium also suits magnesium and zinc die-castings (confirmed for the neat-oil formulation; do NOT use the water-based Tap Magic Aqueous on magnesium — different chemistry). Sizes at AIMS: 4 oz, 16 oz, 5 L (SKU range A0112725, A0112726, A0112727). Tap Magic Xtra Thick Cutting Fluid Same EP-Xtra base chemistry in a heavier-bodied formula that clings to the cutter on vertical tapping, overhead drilling and larger-diameter holes where standard fluid runs off before doing the work. Good pick for hand-tapping deep blind holes in steel. Size at AIMS: 16 oz bottle (SKU A0112728). Tap Magic Eco-Oil Food Grade Food-grade base oil cutting fluid for tapping and threading work in food-processing, pharmaceutical, dairy and medical environments where incidental contact with the product is possible. Tap Magic Eco-Oil is NSF H1 registered — confirm current registration status against Steco's product data sheet before quoting to a food-processing customer. Size at AIMS: 16 oz bottle (SKU A0124471). Tap Magic H2OX Semi-Synthetic Water-miscible semi-synthetic for production machining — flood coolant, mist application and MQL (minimum quantity lubrication) systems. Bridges the gap between Tap Magic's neat oil lineup and the soluble/synthetic coolants used in CNC. Mixed with water at 5–10% for general machining (confirm exact ratio on the current Steco SDS for your operation). Sizes at AIMS: 5 L, 18.9 L (SKU A0145196, A0145197). Tap Magic Corrosion Inhibitor (Aerosol) Aerosol corrosion-protective spray for finished parts, tooling and machine ways. Not a cutting fluid — it's a post-process rust preventative. Goes on as a thin film and protects in-storage parts and tooling. Size at AIMS: 20 oz aerosol (SKU A0112729). Tap Magic Multi-Purpose Cleaner / Degreaser (Aerosol) Aerosol degreaser for cleaning machines, tooling and finished parts before painting, plating or assembly. Also clears cutting fluid residue off threads before measurement. Size at AIMS: 20 oz aerosol (SKU A0112730). When to Use Tap Magic Cutting fluid does three things at the cutter edge: lubricates so the chip can shear cleanly, cools the cutter so it doesn't lose hardness, and flushes the chip out of the flute so it doesn't re-cut. Tap Magic neat fluids excel at the first two — they're built for the lubrication-dominant operations. Hand tapping — the flagship application. Brush-on cling formula keeps fluid where it's needed. Cuts tap breakage dramatically. Machine tapping — drip-feed or manual application before each cycle. Reaming — improves surface finish, extends reamer life. Drilling small to medium holes — particularly in stainless or alloy steel where heat is the killer. Threading with a die — hand-cut external threads benefit massively. Light milling and turning — manual machines, low to moderate metal removal rate. Where Tap Magic is the wrong tool: high-volume CNC with flood coolant, heavy turning at high feed rates, and grinding. Those operations want a soluble or synthetic coolant on a recirculating system. Cast iron is also covered separately below. Material-Specific Selection Mild & Carbon Steel EP-Xtra is the default. Most general workshop tapping in mild steel — M4 through M20, brackets, fabrications, repair work — runs well on EP-Xtra brushed on the tap. Xtra Thick for vertical or overhead. Stainless Steel (304 / 316) EP-Xtra. Stainless work-hardens rapidly if the tap rubs instead of cuts, so the EP additive earns its keep here. The chlorine-free chemistry matters when the part is destined for food, pharma or medical service. (Note: the older view that chlorinated fluids attack 304/316 stainless and cause stress-corrosion cracking is now mostly debunked for brief cutting-fluid contact — the chloride attack concern applies to long-term in-service exposure, not the cut itself. But for food-grade or nuclear work, chlorine-free is still the call.) Alloy & Tool Steel EP-Xtra. Hardness and chip thickness make EP additives essential. Hardened Steel (above ~45 HRC) Tapping hardened steel is a tap-killer regardless of fluid. EP-Xtra helps but you may need to switch to cobalt or carbide taps and reduce RPM significantly. See our cobalt drill bit guide for similar logic on drilling hardened material. Aluminium & Aluminium Alloys Tap Magic Aluminium. Sulphur-free is the rule — aluminium galls badly when sulphur is present, and the chip welds itself to the cutter. The chlorine-free spec also avoids the environmental issue. Brass & Copper Tap Magic Aluminium. Same logic as alu — sulphur stains yellow metals. Some workshops tap brass dry; for any deep or critical thread, the fluid is worth it. Cast Iron Cast iron is the exception. Most experienced machinists run cast iron dry. The graphite in the cast iron acts as its own lubricant, and any fluid mixes with the fine graphite chip to create an abrasive paste that's a nuisance to clean off the machine and the part. If you do use fluid on cast iron, use it sparingly — brush-on Tap Magic for a difficult tap rather than flood coolant for general machining. Titanium & Exotic Alloys EP-Xtra. Titanium needs extreme pressure additives and the right RPM/feed combination. Application Methods Brush-On (Most Common) The 4 oz Tap Magic bottle ships with a brush cap built in. Dip and dab onto the tap or drill before each cut. Best for hand operations and one-off jobs. Uses minimal fluid, no mess, no special equipment. Drip Feed For machine tapping or repetitive operations, a small drip can be set up over the work to keep fluid on the cutter. Suits production drill presses and manual mills. Flood Coolant Tap Magic neat fluids can be used in flood-coolant systems, but the H2OX semi-synthetic is the better pick if you're filling a sump. Neat oils in a flood system get expensive fast and create more mist than water-mix products. Mist / MQL (Minimum Quantity Lubrication) H2OX semi-synthetic is the variant designed for MQL systems. Tiny quantities of fluid atomised into the cut zone — gives the lubrication without the cleanup of flood. Increasingly common in CNC machining. Tap Magic vs Alternatives Product Type When It Wins When Tap Magic Wins Straight cutting oil (e.g. neat sulphurised oil) Heavy turning, broaching, gear cutting Tapping and threading — Tap Magic clings better Soluble (water-mix) coolant High-volume production, flood-cooled CNC Hand tapping, small batch, blind-hole work Synthetic coolant Hard turning, grinding, very high speed Hand operations, lubrication-dominant cutting Trefolex / Rocol RTD Comparable competitor — both are workshop-trusted brush-on fluids Personal preference; Tap Magic chlorine-free is a key differentiator WD-40 or general lubricant Never — these are penetrants, not cutting fluids Always — purpose-built fluid cuts cleaner threads and saves taps Dry cutting Cast iron, very light alu work, plastics Steel, stainless, deep holes, hand tapping For the wider cutting fluid picture across all brands AIMS stocks (Rocol RTD, CRC Tapmatic, Loctite cutting fluids, etc.) see our cutting fluids and oils guide. Health & Safety Safety call-out: All cutting fluids — including the chlorine-free Tap Magic range — can cause skin dermatitis on prolonged contact. Always wear chemical-resistant gloves (nitrile is fine for these fluids) and safety glasses. Ventilate enclosed workshops when running mist or aerosol applications. Skin Contact Repeated skin contact is the most common health issue with workshop cutting fluids. Symptoms range from mild irritation through to occupational dermatitis. Wear gloves. Wash hands properly at the end of every shift — not just a rinse. Don't wipe greasy hands on overalls and then wear those overalls all week. Mist Inhalation When cutting fluid atomises (mist, aerosol, high-RPM CNC) it becomes a respiratory hazard. Australia's Safe Work workplace exposure standard for oil mist (refined mineral) is 5 mg/m³ TWA (current 2024 WES schedule). Mist extraction or general ventilation is essential in any enclosed workshop running flood or MQL. Chlorinated vs Chlorine-Free Older cutting fluids relied on chlorinated paraffins as the EP additive. These work well but carry environmental and disposal concerns — chlorinated waste oil is more expensive to dispose of than non-chlorinated. The entire Tap Magic EP-Xtra and Aluminium range is chlorine-free, which is one reason workshops standardise on the brand. PPE Checklist Chemical-resistant gloves — nitrile or neoprene Safety glasses or face shield (mandatory for any spinning operation) Long sleeves or apron — keeps fluid off skin Closed-toe safety footwear Respirator (P2 minimum) only if working in poorly ventilated space with mist or aerosol SDS Always have the current Safety Data Sheet on file for any cutting fluid you stock. Steco/Tap Magic SDS documents are available through AIMS — contact our team for the current PDFs against the specific Tap Magic variant you're using. Common Mistakes Wrong fluid for the metal. Sulphurised cutting oil on brass stains it black. EP-Xtra on a food-contact part fails a customer audit. Match the fluid to the metal and the application. Too little fluid. A single dab on a deep blind-hole tap isn't enough. Re-apply every few turns. Contaminated fluid. Brush-cap bottles pick up chips and grit from the workbench. Wipe the cap clean. Don't dip a chip-coated tap straight back into the bottle. Mixing variants. EP-Xtra and Aluminium use different chemistries. Don't pour leftover bottles together to "save" fluid — you compromise both. Using WD-40 as cutting fluid. WD-40 is a penetrant, not a cutting fluid. It doesn't have the EP additive and doesn't cling. Fine for unsticking a seized fastener; useless for cutting a thread. Storing in direct sunlight. UV degrades the fluid's additive package over time. Store bottles in a closed cabinet or away from windows. AIMS' Note on Threading & Tapping Safety Cutting fluid is one part of safe tapping work. The other parts: Secure the work. A vice, clamp or jig — never hand-hold a part while tapping. A broken tap with a hand-held part causes injury. Right tap for the job. Spiral-point taps clear chips through the hole — use them on through-holes. Spiral-flute taps pull chips backward — use them on blind holes. See our tap types guide for the full picture. Correct tap drill size. Wrong drill size is the #1 cause of tap breakage. Cross-check on our tap drill size chart. Hand-tap progression. Taper (No.1), plug (No.2), bottoming (No.3). For a tough material or a critical thread, work through the set rather than going straight to plug. Power-tap risk. Power tapping in a hand drill is high-risk — tap breakage is sudden and the broken end is sharp. If you're power tapping, use a tapping head on a drill press at low RPM. Eye protection. Tap fragments fly when they break. Frequently Asked Questions Is Tap Magic Australian made? No. Tap Magic is manufactured by The Steco Corporation in Little Rock, Arkansas, USA. The product is imported to Australia and distributed through industrial supply channels including AIMS. Is Tap Magic EP-Xtra chlorine-free? Yes. The EP-Xtra formula is chlorine-free, using non-chlorinated extreme-pressure additives. This was a deliberate reformulation by Steco to address environmental and disposal concerns with older chlorinated cutting fluids. Can I use Tap Magic EP-Xtra on aluminium? You can, but Tap Magic Aluminium is the proper pick. EP-Xtra is engineered for ferrous metals; the dedicated Aluminium variant is sulphur-free and chlorine-free, which prevents galling on alu and staining on brass and copper. Can I use Tap Magic on stainless steel for food-grade work? For the cutting operation itself, EP-Xtra is fine — it's chlorine-free. For parts that will contact food, pharmaceutical or medical product, use Tap Magic Eco-Oil Food Grade and verify the current NSF registration against Steco's published data sheet for your customer's audit requirements. What's the difference between Tap Magic EP-Xtra and Xtra Thick? Same EP-Xtra chemistry. Xtra Thick has a heavier viscosity so it clings to the tap on vertical, overhead and large-diameter work where the standard fluid would drip off before doing its job. Can Tap Magic be used in a flood coolant system? Neat Tap Magic (EP-Xtra, Aluminium, Xtra Thick) can be used neat in a flood system but the H2OX semi-synthetic is the variant designed for water-mix flood and MQL. Neat oil in flood sumps gets expensive and creates more mist than water-mix coolants. How do I dispose of used Tap Magic? As waste cutting oil through a licensed waste oil contractor. Chlorine-free oils are generally cheaper to dispose of than chlorinated waste. Check your local council or EPA requirements — disposal rules vary by state in Australia. Does Tap Magic work on titanium? EP-Xtra is the variant for titanium. Titanium needs the EP additive and a correctly controlled RPM/feed combination. The fluid is one piece — cutter geometry, speeds and feeds matter just as much. What size should I buy for a home workshop? The 4 oz bottle with the brush cap is the right starting point for a home or hobby workshop. It lasts a long time at hand-tap volumes. Step up to 12 oz or 16 oz once you're running regular work. Is there a Tap Magic equivalent for grinding? No. Grinding wants a water-soluble or synthetic coolant on a recirculating system, not a neat cutting fluid. Tap Magic isn't formulated for grinding work. Can I mix Tap Magic with WD-40 or motor oil to make it last longer? No. Diluting the fluid removes the EP additive package and you lose the benefit you paid for. Use Tap Magic as supplied. Why is Tap Magic thicker than other cutting fluids? By design. The cling property is what makes it work on hand tapping — fluid that runs straight off the tap doesn't lubricate the cut. Thicker viscosity = better adhesion on vertical or overhead work. Does Tap Magic expire? Sealed bottles have a long shelf life if stored away from sunlight and extreme temperature. Once opened and exposed to workshop dust and contamination, quality degrades. As a rule of thumb, replace any bottle that's been on the bench for more than 12 months or shows visible contamination. Can I use Tap Magic on plastics? Generally no — most plastics machine dry or with compressed air for chip clearance. Cutting fluid on plastics can stain the part and isn't needed for the cut itself. What's better, Tap Magic or Rocol RTD? Both are workshop-standard brush-on cutting fluids with comparable performance. Rocol RTD has been the UK/Australian default for decades; Tap Magic is the US-standard equivalent. The key differentiator: Tap Magic's range includes the dedicated chlorine-free Aluminium variant and the food-grade Eco-Oil. Choose by which range covers your application set best. Where can I buy Tap Magic in Australia? AIMS Industrial stocks the core Tap Magic range — EP-Xtra, Aluminium, Xtra Thick, Eco-Oil Food Grade and H2OX. Browse the live range at aimsindustrial.com.au/collections/tap-magic or call our Sydney team on (02) 9773 0122 for stock availability and trade pricing. Related Content Cutting Fluids & Cutting Oils Guide — wider category guide covering all cutting fluid types and brands. Tap Types Explained — taper, plug, bottoming, spiral point and spiral flute taps. Tap Drill Size Chart — metric and imperial tap drill sizes. Tap & Die Guide — how to cut threads with hand taps and dies. Cobalt Drill Bit Guide — M35 vs M42 cobalt drills for stainless and hardened material. Need Help Picking the Right Tap Magic Variant? Call our Sydney trade desk on (02) 9773 0122, email sales@aimsindustrial.com.au, or browse the live range at /collections/tap-magic. Same-day quote turnaround on bulk trade orders. We stock the wider cutting lubricants range alongside Tap Magic — Rocol, CRC, Loctite and others — so we can match the fluid to your actual job rather than push one brand. People Also Ask — Tap Magic Cutting Fluids Q: What is the difference between oil-based and water-based cutting fluids? Oil-based cutting fluids provide superior lubrication and are better suited to heavy-duty operations such as tapping, threading, and gear cutting. Water-based cutting fluids — including water-miscible concentrates and semi-synthetics — offer better heat dissipation and are preferred where cooling is the priority, such as high-speed grinding. Oil-based fluids leave an oily residue that protects metal surfaces from rust; water-based fluids clean up more easily but require monitoring of concentration and pH to prevent bacterial growth in sumps. The choice depends on the material being machined, the operation type, and workplace hygiene requirements. Q: Can you reuse cutting fluid, or should it be discarded after each operation? Oil-based cutting fluids such as Tap Magic can generally be reused — excess drains back to a sump or catch tray and is recirculated. Fluid should be discarded when it becomes heavily contaminated with swarf, discolours, develops an odour, or loses its cutting effectiveness. Water-miscible fluids require more careful management because bacteria can grow in the mix over time; monitoring concentration and pH helps extend service life. Contaminated fluid that is reused can introduce abrasive swarf particles into the cutting zone, accelerating tool wear rather than reducing it. Q: Does using cutting fluid affect the surface finish on machined parts? Yes — applying the correct cutting fluid typically improves surface finish by reducing the heat and friction that cause built-up edge on the cutting tool. Built-up edge is a common cause of poor surface finish, particularly in materials like aluminium and stainless steel. Flushing the cut zone with cutting fluid also clears chips away from the work, preventing re-cutting, which scores and roughens the machined surface. On some operations, such as honing and precision grinding, the fluid also acts as a carrier to wash away abrasive particles, maintaining a consistent cutting action. Q: How should Tap Magic cutting fluid be applied during hand tapping? When tapping by hand, apply a small amount of Tap Magic directly to the tap flutes and the tapping hole before starting. Re-apply fluid every few turns, particularly in blind holes where chips cannot escape freely and heat accumulates. On blind holes, periodically reverse the tap half a turn to break the chip and allow it to pack back into the flute before continuing forward. The fluid should coat the cutting edges without flooding the work — a small brush, dropper, or squeeze bottle allows accurate application. Over-applying fluid to small holes can create hydraulic lock in blind holes, which resists the tap’s forward advance. Q: How should Tap Magic cutting fluid be stored to maintain shelf life? Tap Magic products should be stored in their original sealed containers in a cool, dry location away from direct sunlight and heat sources. Extreme temperatures accelerate oxidation and degradation of oil-based cutting fluids. Containers should be resealed immediately after each use to prevent moisture ingress and contamination. Under correct storage conditions, Tap Magic products have a defined shelf life — checking the product label for the recommended use-by guidance ensures optimal performance. Discard fluid that has darkened significantly, developed sediment, or emits an unusual odour, as these are signs of degradation.
Read more
Overview of Basic Singular Wear Patterns in Machining
(Taken from this post by Seco. Republished with permission. Edited for point of view, recency and relevance.) For each of these wear patterns, some of the possible counter measures to undertake in order to avoid, or at least minimise, their impact on the machining process are provided. Flank wear Crater wear Built-up edges (BUE) Chipping wear Thermal cracks Plastic deformation Notch wear Chip hammering Cutting edge breakage Flank wear Flank wear is the most desirable wear condition because it is rather predictable and dependable, while offering a well-defined relation between flank wear and achievable tool life. However, flank wear that occurs too rapidly – resembling classic flank wear but develops in a very short time period – can be a problem. At lower cutting speeds, the main causes of flank wear are abrasion and erosion. Hard microscopic inclusions of carbides or strain hardened workpiece material particles cut into the cutting tool. Small pieces of coating then break off and cut into the tool face. The cobalt eventually wears out of the matrix. This reduces the adhesion of the carbide grains, causing them to break away as well. At higher cutting speeds, diffusion wear is the main cause of flank wear because higher cutting speeds generate higher temperatures on the cutting edge, creating favorable conditions for diffusion to take place. Flank wear resembles a relatively uniform abrasion along the tool’s cutting edge. Occasionally, metal from the workpiece smears over the cutting edge and can exaggerate the apparent size of the wear scar. Flank wear happens in all materials, and a cutting edge will normally fail due to flank wear if it doesn’t fail by other types of wear first. Some corrective actions to minimise flank wear are to reduce the cutting speed (in some cases increasing the feed rate can also help), select a more wear resistant, harder carbide grade and to correctly apply coolant. Crater wear Crater wear is a combination of diffusion and decomposition (higher cutting speeds) and abrasive wear (lower cutting speeds). The heat from the workpiece chips decomposes the tungsten carbide grains in the substrate and carbon leeches into the chips (diffusion), wearing a ‘crater ‘on the rake face of the insert. The crater will eventually grow large enough to cause the insert flank to chip or may cause rapid flank wear. Crater wear takes the shape/appearance of a crater or pits on the rake face of inserts. Crater wear will be visible mostly when machining abrasive workpiece materials or materials with a hard surface. To minimise crater wear, it is best to use coatings containing thick layers of aluminium oxide, apply coolant, use a free cutting geometry that reduces heat and to lower cutting speeds and feeds. Built-up edges Built-up edges (BUE) are caused by adhesion of workpiece material that is pressure welded to the cutting edge. This occurs when there is chemical affinity, high pressure and sufficient temperature in the cutting zone. Eventually, the built-up edge breaks off and takes pieces of the cutting edge with it, leading to chipping and rapid flank wear. Built-up edges look like shiny material parts on the top or flank of the cutting edge and lead to small pits or craters on the rake face of the tool and ultimately to cutting edge chipping. Built-up edges typically occur in gummy materials such as non-ferrous materials, super-alloys and stainless steels and during operations involving slower cutting speeds and feeds. To prevent built-up edge wear, increase the cutting speed and or feed rate, select an insert with a sharper geometry and a smoother rake face and correctly apply coolant at an increased concentration. Chipping wear Chipping is caused by mechanical instability or cracks in the cutting material. Chipping of the cutting edge is often a result of vibrations in the workpiece or machine tool or the tool itself. Hard inclusions in the surface of the workpiece material and interrupted cuts result in concentrations of localised stress that can cause cracks and chipping. Chipping looks like small bits broken out of the cutting edge and is common in non-rigid situations. Workpiece materials with hard particles (eg. precipitation hardening workpiece materials) will also cause cutting edge chipping. Corrective actions include proper machine tool setup and minimising deflection, using a tougher carbide grade and stronger cutting edge geometry, reducing the feed (especially at the entrance or exit of the cut) and increasing the cutting speed. (See also corrective actions for built-up edge.) Thermal cracks A combination of thermal cycling (changing temperatures in the cutting edge), thermal loads (temperature differences between warm and cold zones in the cutting edge) and mechanical shocks causes thermal cracks. Stress cracks form along the cutting edge, eventually causing sections of carbide to pull out and the edge to chip. Thermal cracks can be observed mostly in milling and interrupted cut turning, and intermittent coolant flow can also lead to thermal cracks. Some corrective actions are to apply coolant correctly, select a tougher carbide grade, reduce the cutting speed and the feed, use a free cutting geometry that reduces heat and to consider a different machining method (ratio time in cut/time out of cut). Plastic deformation Thermal overloading is the main cause of plastic deformation. Excessive heat causes the carbide binder (cobalt) to soften. Then, due to mechanical overloading, pressure on the cutting edge makes it deform or sag at its tip, eventually breaking off or leading to rapid flank wear. Plastic deformation looks like a deformed cutting edge. Careful observation is needed because plastic deformation can look very similar to flank wear on a cutting edge. Expect plastic deformation when cutting temperatures are high (high cutting speeds and feeds) and when the workpiece material is high strength in nature (hard steels or strain hardened surfaces and superalloys). Some corrective actions are properly applied coolant, reduced cutting speeds and feeds, using an insert with a larger nose radius and opting for a harder, more wear resistant carbide grade. Notch wear Notch wear happens when the surface of a workpiece is harder or more abrasive than its underlying material. This can be due to surface hardening during previous cuts (strain hardening materials like stainless steels and super-alloys) or originate from forged or cast surfaces with a surface scale, all of which causes the cutting edge to wear more rapidly at the point where the cutting edge contacts the hard layer. This localised concentrated stress can also lead to notch wear. What happens is that compressive stress develops along the cutting edge that’s in contact with workpiece material, while it doesn’t occur where the cutting edge is not in contact. This causes high stress on the cutting edge at the point where the two are in direct contact (depth of cut line). Impact of any sort, such as hard micro inclusions in the workpiece material or slight interruptions can also cause notch wear. Some corrective actions include reducing feed rate and varying the depth of cut when using multiple passes, increasing cutting speeds if machining a high temp alloy (this will give more flank wear), selecting a tougher carbide grade and using a chip breaking geometry for high feeds needed to prevent built-up edges, especially in stainless and heat resistant alloys. Chip hammering Chip hammering is a phenomenon caused by chips curling back and hitting the unused part of a cutting edge. Breakage of a cutting edge (or part of a cutting edge) that is not in cut will be the result. The risk that this happens is greater with operations involving high feeds and deep depths of cut combinations. To correct for chip hammering, change the feed rate and the cutting depth, select a different cutting edge angle, use a different chip breaking geometry and go with a tougher carbide grade. Cutting edge breakage Any overview of basic wear patterns must also include cutting edge breakage. Catastrophic breakage of the cutting edge is not a wear pattern, but an unwanted and dangerous phenomenon caused by using tools incorrectly. When a cutting edge breaks, it means that the selection of the cutting conditions is such that the mechanical loads acting on the cutting edge are so great that they cannot withstand them. Start with lower values for the cutting conditions (mainly depth of cut and feed) or choose a stronger cutting edge (tougher carbide grade or stronger geometry). It could also be that one of the previous mentioned wear patterns expanded and weakened the cutting edge so much that it could no longer withstand the loads acting upon it. In these instances, changing to a new cutting edge earlier will prevent breakage. Wear descriptions concentrate on the visual aspect of tool wear. In addition to them, there are other phenomena that can be observed when the cutting edge is wearing. These can indicate that the tool is wearing out and is perhaps ready to be replaced. Sudden breakage of the cutting tool. This is a very unpleasant way of signalling that the cutting tool is due for replacement. There are so many elements influencing how a cutting edge deteriorates that it is not always feasible to take all into account, and that can lead to breakage of a cutting edge in some cases. If tool breakage happens in a systematic way, the operation needs to be stopped and fully evaluated. Systematic tool breakage indicates that there is an unbalance between the loads acting on the cutting edge and the load bearing capacity of the tool. Cutting forces should be lowered or a stronger cutting edge should be selected. The fingernail test is one of the simplest tests to evaluate the status of the cutting edge. The presence of built-up edges or micro chipping of the cutting edge may not be visible to the naked eye, but they can definitely be felt with a fingernail. Built-up edge and chipping should be minimised during the operation. Changes in the noise level during machining can indicate that a tool is wearing out. Sharp, high frequency noises indicate poor cutting conditions. Chips that change form, shape or color during machining are yet another indication that the shape of the cutting edge is changing, e.g. due to tool wear progressing. When the surface roughness of a machined surface degrades, that could also signal that it is time to change the cutting edge (reaching end of tool life). Increasing power consumption or vibration tendency. Conclusion Tool deterioration is the process by which the condition of a cutting tool becomes increasingly worse and gradually causes the tool to lose its ability to perform in line with expectations. Tool deterioration comes as aging-wear, sudden impact phenomena like breakage and as chemical interactions between workpiece material and cutting material. Aging-wear is a process of progressive surface damage leading to removal of material from one or both of two solid surfaces in solid state contact, occurring when these two solid surfaces are in sliding or rolling motion contact in environmental conditions of pressure and temperature. This overview of basic, singular wear patterns gives basic remedies to take care of tool wear that is for the machinist unacceptable in form or in pace of development. AIMS' note on managing chips Tool geometry: Choose cutting tools with chipbreakers designed for the material you're machining. These chip-breakers introduce interruptions or curves into the cutting edge, forcing the chips to curl and break into smaller, more manageable pieces. Also, selecting the correct nose radius for your insert can help control chip formation. Cutting parameters: Adjust your feed rate and cutting speed. Increasing feed rates often helps break chips, while higher cutting speeds can produce thinner and more manageable chips. However, be careful not to push speeds and feeds beyond the tool's capabilities, as this can lead to tool breakage or poor surface finish. Refer to recommended parameters from your tooling manufacturer as a starting point. Coolant: High-pressure coolant directed at the cutting zone can effectively break chips and flush them away, improving chip control. Ensure your coolant system is working optimally and use the correct coolant type for the job. Machine rigidity: A rigid machine setup helps reduce vibrations that can lead to unpredictable chip formation. Make sure your workpiece and tooling are clamped securely to minimise unwanted movement. AIMS' Note on Managing Chips Tool geometry: Choose cutting tools with chipbreakers designed for the material you're machining. These chip-breakers introduce interruptions or curves into the cutting edge, forcing the chips to curl and break into smaller, more manageable pieces. Also, selecting the correct nose radius for your insert can help control chip formation. Cutting parameters: Adjust your feed rate and cutting speed. Increasing feed rates often helps break chips, while higher cutting speeds can produce thinner and more manageable chips. However, be careful not to push speeds and feeds beyond the tool's capabilities, as this can lead to tool breakage or poor surface finish. Refer to recommended parameters from your tooling manufacturer as a starting point. Coolant: High-pressure coolant directed at the cutting zone can effectively break chips and flush them away, improving chip control. Ensure your coolant system is working optimally and use the correct coolant type for the job. Machine rigidity: A rigid machine setup helps reduce vibrations that can lead to unpredictable chip formation. Make sure your workpiece and tooling are clamped securely to minimise unwanted movement. Disposal: Dispose of used abrasives properly per local regulations. People Also Ask — Machining Wear Patterns Q: What do wear patterns on cutting tools indicate about machining conditions? Flank wear indicates normal progression and is the expected wear mode in most materials. Crater wear on the rake face suggests high cutting temperatures, typically from excessive cutting speed or inadequate cooling. Notch wear at the depth-of-cut line can indicate built-up edge or a hard work-hardened layer. Each pattern points to specific corrective actions involving cutting parameters, tool geometry or cooling. Q: What causes built-up edge on a cutting tool? Built-up edge forms when workpiece material welds to the cutting edge at low-to-medium cutting speeds in ductile materials such as mild steel, aluminium and stainless steel. Built-up edge temporarily protects the cutting edge but then breaks away unpredictably, tearing the workpiece surface and leaving a poor finish. Increasing cutting speed, improving coolant delivery or using a coated tool typically eliminates it. Q: How does workpiece material hardness affect tool wear rate? Harder workpiece materials accelerate abrasive wear because harder particles in the microstructure scratch and remove tool material at a higher rate. Interrupted cuts in hard materials also cause chipping and micro-fracture of the cutting edge due to mechanical impact. Selecting tool materials and coatings with higher hardness and toughness for the specific workpiece material is the primary control. Q: What is the difference between catastrophic failure and gradual wear in cutting tools? Gradual wear follows a predictable pattern of initial break-in, a long stable wear period, then accelerating wear as the tool approaches end of life, allowing tool changes at the optimal point. Catastrophic failure is sudden edge fracture or breakage, usually caused by incorrect cutting parameters, tool vibration, incorrect tool material for the workpiece, or using a worn tool beyond its usable life.
Read moreBand Saw Blade Guide: TPI, Blade Types & Material Selection
Picking the right band saw blade is half the job. Get the TPI, blade type and tooth set right for your material and your saw cuts straight, stays cool, and lasts. Get it wrong and you'll burn blades, snap teeth, or wander your cut. This guide covers blade selection for metal and wood bandsaws — TPI rules, blade construction, tooth geometry, set, dimensions, material-specific traps, fluid choices, troubleshooting, and Australian brand options. Band Saw Blade Quick Reference — TPI by Material Common starting points for bi-metal blades on metal-cutting bandsaws. Adjust based on stock thickness (3-tooth rule below). Material Stock thickness Recommended TPI Notes Mild steel (solid) 3-25 mm 10-14 TPI Bi-metal, raker set Mild steel (solid) 25-75 mm 6-10 TPI Drop to 4-6 TPI for heavy section Mild steel tube/RHS 2-5 mm wall 14-18 TPI Variable pitch reduces vibration Stainless 304/316 3-25 mm 10-14 TPI M42 cobalt preferred — work-hardens fast Aluminium (solid) Any 4-6 TPI skip Big gullets to clear gummy swarf Brass / bronze Any 10-14 TPI Standard bi-metal handles it well Cast iron Any 10-14 TPI Dry — fluid mixes with dust to form abrasive paste Tool steel (hardened) Any 10-14 TPI Carbide-tipped, slow feed Plastic / acrylic Any 6-10 TPI skip Skip tooth prevents melting Hardwood (resaw) 50 mm+ 3-4 TPI hook Wide blade (19-25 mm), hook tooth Softwood / general timber Up to 75 mm 6-10 TPI Regular or skip tooth These are starting points. Manufacturer charts (Bahco, Lenox, Sutton, Excision) should be consulted for production work. Browse our full saw blades range. Band Saw Blade Types — Construction Materials Blade construction sets the cost-per-cut and the materials you can sensibly cut. Four mainstream options. Carbon steel (high-carbon) Single-piece hardened carbon steel. Cheap, flexible, works well on softwoods, plastics, non-ferrous metals up to medium thickness. Loses temper around 200°C — not for hot work or hardened steel. Common on entry-level vertical bandsaws and bench-top hobby machines. Use case: Timber, plastic, aluminium, brass Cost tier: Lowest Lifespan: Short (50-100 hrs typical) Bi-metal (HSS edge welded to spring steel back) The workhorse for metal-cutting bandsaws across Australian fab shops. M2 or M42 high-speed steel tooth edge electron-beam-welded to a flexible spring steel back. Holds an edge at 500-600°C, survives the heat of metal cutting, and the spring back gives fatigue life on the wheels. Use case: Mild steel, stainless, structural sections, general metal Cost tier: Mid Lifespan: Long — 5-10x carbon on metal M42 cobalt HSS bi-metal M42 contains 8% cobalt, lifting hot hardness and red-hardness substantially over standard M2 bi-metal. Worth the upcharge on stainless, tool steel, Inconel, and any work-hardening material. Premium brands Excision, Bahco, and Sutton all offer M42 variants. Use case: Stainless 304/316, tool steel, nickel alloys, hardened material Cost tier: Mid-high Lifespan: Long on tough materials where M2 dulls fast Carbide-tipped Tungsten carbide tooth tips brazed to a steel back. Aggressive cutter on hardened steels, abrasive materials, fibre composites, and exotic alloys. Expensive to buy, expensive to replace if you snap one — but cost per cut on the right material beats bi-metal comfortably. Use case: Hardened tool steel, Inconel, titanium, abrasive composites, production cutting on tough stock Cost tier: Highest Lifespan: Very long on suitable material; intolerant of misuse For deeper material trade-offs across cutting tools, see HSS vs Carbide and Carbide vs HSS End Mill. TPI Selection — The 3-Tooth Rule The cardinal rule for bandsaw TPI: at least 3 teeth must be engaged in the cut at all times, ideally between 6 and 12. Fewer than 3 teeth in contact and the tooth slams into the workpiece edge unsupported — you lose teeth, the blade snags, the cut wanders. More than 24 teeth in contact and you can't clear chips fast enough — the gullet packs, the blade overheats, and you weld swarf onto the tooth face. Working example: cutting 12 mm mild steel with a 14 TPI blade gives you (12 mm ÷ 25.4) × 14 ≈ 6.6 teeth in the cut. Right in the sweet spot. Same 12 mm with a 4 TPI blade: only 1.9 teeth engaged. Tooth strip likely within minutes. Stock thickness Best TPI (constant pitch) Variable pitch alternative Under 3 mm 24 TPI 18-24 variable 3-6 mm 14-18 TPI 14-18 variable 6-12 mm 10-14 TPI 10-14 variable 12-25 mm 8-10 TPI 8-12 variable 25-50 mm 6-8 TPI 5-8 variable 50-100 mm 4-6 TPI 4-6 variable Over 100 mm 3-4 TPI 2-3 variable Warning: tube and thin-wall section breaks both ends of the rule because the saw transitions from thin (single wall) to thick (two walls) to thin again as it cuts through. Always run variable-pitch on tube — the changing tooth pitch smooths the cut and stops the harmonics that crack teeth at the transitions. Tooth Set — How the Teeth Are Bent The "set" is the alternating side-to-side offset on each tooth. It cuts a kerf wider than the blade body, which gives the blade clearance and lets it turn corners without binding. Four patterns dominate. Raker set Pattern: one left, one right, one straight (raker), repeat. The straight raker clears chips from the kerf. Standard set for metal cutting — fast, durable, leaves a clean kerf on solid bar. Found on most general-purpose bi-metal blades. Wavy set Groups of teeth gradually bend left, then gradually bend right, in a wave pattern. Distributes load across more teeth in light cuts — ideal for thin sheet, tube, light wall section where a raker set would catch and chip. The go-to set for cutting RHS, SHS, and thin-wall tube. Straight (no set) All teeth in a straight line — found on some woodworking blades and specialty applications. Cuts a narrow kerf with no swarf clearance, so only works in materials where chips compress (some plastics, soft timber). Alternate set One tooth left, one tooth right, alternating with no raker. Common on woodworking blades. Faster than raker on softer materials, leaves a wider kerf. Tooth Form — Regular, Skip, Hook The tooth face angle and gullet shape control chip formation. Three standard forms. Regular (precision) tooth: 0° rake angle, deep round gullet. General-purpose. Smooth cuts on thin material, medium-thickness metal. Default for bi-metal blades on solids. Skip tooth: Wider spacing, deeper gullet, 0° rake. Designed to clear long stringy chips — aluminium, brass, plastics, soft non-ferrous. Stops gummy swarf packing the gullet. Hook tooth: Positive 10° rake, deep gullet. Aggressive cutter. Used on thick wood, thick aluminium, larger non-ferrous section. Higher feed rate, rougher finish. Pitch terminology: "regular pitch" means all teeth same TPI; "variable pitch" means TPI varies across a short repeating section (e.g. 5/8 = teeth vary between 5 and 8 TPI). Variable pitch reduces resonance and chatter — preferred for production metal cutting. Blade Dimensions — Length, Width, Thickness Three dimensions to match to your saw and your work. Length Set by the wheel diameter and centre distance on your saw. Most production bandsaws use a small range of standard lengths (e.g. 1638 mm, 2080 mm, 2362 mm, 2925 mm are common). Custom welded lengths are available from suppliers like Excision. Always check your saw's spec plate. To measure an existing blade: lay a tape measure on a flat surface, mark a spot on the blade, align the mark to zero, then roll the blade along the tape until the mark returns. The reading is your blade length. Width From tooth tip to back edge. Affects two things: minimum cut radius and beam stiffness. Narrow blades (6-13 mm): Tight radius cuts, intricate work, curve cutting. Less stiff — wanders on heavy feed. Medium blades (13-19 mm): General workshop use, straight cuts on bench bandsaws. Wide blades (19-50 mm): Resaw work, production horizontal bandsaws, heavy section. Stiff, stays straight at high feed. Thickness Typically 0.6 mm to 1.6 mm. Thicker blade survives heavier feed and bigger section but fatigues faster around small wheels. Match thickness to wheel diameter — too thick on a small wheel and the back fatigues and snaps. Rule of thumb: blade thickness should be no more than 1/1000 of the wheel diameter. Material-Specific Guidance Stainless steel — the work-hardening trap Warning: 304 and 316 stainless work-harden in seconds if you let the blade rub instead of cut. Once the surface is hardened (Rc 45+), even a sharp blade glazes over and stops cutting. Two rules: (1) keep constant feed pressure — never let the blade dwell, (2) use M42 cobalt bi-metal minimum, ideally with flood coolant. Production stainless work justifies carbide-tipped blades. Aluminium — gumming and swarf welding Aluminium produces long ductile chips that pack into tooth gullets, then friction-weld onto the tooth face and re-cut as a built-up edge. Three counters: skip-tooth blade with big gullets, lubricant (Excision Alube stick or similar grease-stick lubricant), and slower band speed than you'd guess. Don't use water-based coolant on small-section aluminium — it lifts the lubricating film and makes the swarf stickier. Cast iron — dust, not chips Cast iron breaks into fine abrasive dust rather than chips. Cut dry — cutting fluid mixes with the dust to form a grinding paste that wears the blade prematurely. Wear respiratory protection — cast iron dust contains silica. Tube and structural section — variable pitch every time Tube, RHS, SHS, and channel section all hit the bandsaw teeth at varying depths as the cut progresses. Constant-pitch blades resonate and chip teeth at the wall transitions. Variable pitch (e.g. 8/12, 10/14, 4/6 raker) handles the transitions smoothly. AS 1473.2 covers safety guarding around horizontal bandsaws used for cutting structural section. Hardened tool steel and exotic alloys Above Rc 40, bi-metal struggles. Carbide-tipped is the practical answer. Slow feed, slow band speed (often 40-60 m/min), flood coolant. The carbide tooth needs to peel rather than chip the material. Cutting Fluid Selection Material Fluid Why Mild steel (production) Soluble oil flood Cools and lubricates, cheap to run Stainless steel Heavy soluble or neat cutting oil Carries heat away, prevents work-hardening Aluminium Stick lubricant or kerosene mist Stops swarf welding to tooth face Cast iron None (dry) Fluid + dust = abrasive paste Brass / bronze Light cutting oil or dry Short chips, low heat — fluid optional Plastics Compressed air or none Cools without solvent attack on the plastic Tool steel / exotic Neat cutting oil flood Maximum lubrication for carbide Timber None Sawdust burns, fluid not needed For more on cutting fluid selection across machining, see Tap Magic Cutting Fluids FAQ. Browse the cutting lubricants range at AIMS. Troubleshooting — Common Bandsaw Blade Problems Symptom Likely cause Fix Cut wandering (out of square) Worn blade guides, blade dull on one side, tooth set damaged Replace guides, replace blade, check tension Chatter / vibration Wrong TPI (too coarse), insufficient feed pressure, loose tension Switch to finer or variable pitch, increase feed, re-tension Blade snapping Over-tensioned, fatigue from small wheel, weld failure, twist in blade Reduce tension to manufacturer spec, check wheel alignment, replace blade Premature tooth wear Wrong material grade, no coolant, band speed too high Upgrade to M42 or carbide, add flood coolant, reduce SFM Tooth strip TPI too coarse (less than 3 teeth in cut), entry chip-load too heavy, no run-in on new blade Use 3-tooth rule, reduce feed on entry, run new blades at half feed for first 50-100 cuts Burning material / blue chips Band speed too high, blade dull, no coolant Reduce band speed, replace blade, add coolant Swarf welded to tooth face Lubricant inadequate for material (esp. aluminium), gullets too small Add lube stick or coolant, switch to skip tooth Blade twists / rolls in guides Guide pressure too high, guides worn, blade tension uneven Re-adjust guides, replace guide bearings, re-tension to spec Loud screeching during cut Dull blade, dry cut where fluid needed, glazed tooth tips Replace blade or add coolant — don't push a dull blade The break-in rule: a new bi-metal or carbide blade needs run-in. Cut at half normal feed for the first 50-100 sq.cm of cross-sectional area. This works the fine micro-burr off the tooth tips gradually — skip break-in and tooth tips fracture instead of wearing, halving blade life. Brand Context — Australian and International AIMS stocks the brands Australian fabricators rely on. Quick context on each: Excision — Australian-distributed, broad range of bi-metal and carbide bandsaw blades, welded to length on request. Strong on metal-cutting bandsaw consumables for production shops. Most cost-effective brand for medium-volume Australian metal fab work. Bahco — Swedish heritage, premium bi-metal and M42 ranges. Sandvik-owned. Excellent technical data sheets and material-specific recommendations. Sutton Tools — Australian-made cutting tool brand. Holds bandsaw blade lines alongside their stronger drilling and threading ranges. Worth supporting on a like-for-like spec comparison if buying Australian matters to you. When to pay more: production volume justifies M42 or carbide; one-off jobs and infrequent use rarely do. A workshop cutting 20 mm RHS for general fab work runs bi-metal happily. A stainless food-grade fabrication shop benefits from M42 or carbide on every job. When to Replace a Band Saw Blade Signs your blade is done: Visible chipping or missing teeth — replace immediately, broken teeth cause secondary damage Burnt or blued teeth — temper drawn, blade will never hold an edge again Cut times doubled or more compared to a new blade Cuts wandering off-square (after checking guides and tension) Burning smell or smoke during cuts that previously ran cool Excessive feed pressure required to maintain cut rate Surface rust patches you can't clean off (light surface oxidation is fine) Production rule of thumb: bi-metal blade life is 200-1000 hours depending on duty cycle and material. Carbide can exceed 2000 hours on suitable work. Keep at least one spare blade on the shelf — unplanned downtime costs more than a blade. AIMS' Note on Safe Bandsaw Operation Bandsaws — especially vertical metal-cutting bandsaws and horizontal production bandsaws — are covered by AS 1473.2 (safety of machines: guarding around bandsaws) and AS 4024 (machinery safety series). The work health and safety obligations under the WHS Act 2011 require risk assessment and operator training. Practical points for every operator: Guarding: Adjust the upper blade guard so only the blade depth required for the cut is exposed — typically 5-10 mm above the workpiece. AS 1473.2 mandates guarding above the cutting zone. Eye protection: Safety glasses or goggles minimum on every cut. Side shields essential for cast iron or any material that produces dust or fine chips. Hand protection: Cut-resistant gloves when handling blades — bandsaw teeth strip skin instantly. Never wear gloves while operating the saw — they can be drawn into the blade. Gloves for handling, bare hands (or close-fitting work gloves) for cutting. Hearing protection: Horizontal production bandsaws regularly exceed 85 dB(A) — ear protection required under WHS exposure limits. Respiratory: Dust mask or respirator for cast iron, fibre composite, MDF, treated timber. Cast iron dust contains crystalline silica. Workpiece clamping: Always clamp or vice-hold the workpiece. Hand-holding round stock or tube is the leading cause of bandsaw injuries. Cleaning: Isolate the machine before cleaning. Brush, don't blow — compressed air drives swarf into bearings and eyes. Blade changes: Isolate and lock out before changing blades. New blades arrive sharp — handle from the back edge or wear cut-resistant gloves for the change only. If you're cutting hot work or in proximity to flammables, follow the hot work permit process — see our Hot Work Permit Australia guide for what's required under AS 1674.1. Band Speed (SFM) — Matching to Material Band speed (surface feet per minute, SFM, or metres per minute, m/min) is the linear speed of the blade past the workpiece. Get it right and the chip per tooth, the heat in the cut, and blade life all fall into place. Get it wrong and you'll either burn the blade or accept slow uneconomic cut times. Material Band speed (m/min) Band speed (SFM) Notes Mild steel 60-90 200-300 Standard bi-metal, soluble coolant Medium carbon steel 45-75 150-250 Reduce if blade glows or chips blue Stainless 304/316 40-60 130-200 M42 cobalt, flood coolant essential Tool steel (annealed) 30-50 100-165 M42 minimum, neat cutting oil Tool steel (hardened) 25-40 80-130 Carbide-tipped only Cast iron 40-70 130-230 Dry, brisk feed Aluminium (solid) 200-500 650-1650 Skip tooth, lube stick Brass / bronze 120-200 400-650 Optional light cutting oil Inconel / nickel alloys 20-40 65-130 Carbide, neat oil flood, slow steady feed Titanium 20-30 65-100 Carbide, flood coolant, low feed Hardwood 500-900 1650-3000 Carbon or bi-metal, dry Plastic / acrylic 250-600 800-2000 Skip tooth, compressed air to cool Heat is the enemy of blade life. If the chips come off blue or straw-coloured the band speed is too high or the feed is wrong. Cool, silver chips mean you're cutting; not burning. The relationship between band speed, feed rate and tooth pitch is well covered in our Cutting Speeds & Feeds Chart — the principles transfer directly to bandsaws. Blade Tension — Setting It Correctly Tension keeps the blade straight and stops it deflecting under feed pressure. Too little tension and the cut wanders; too much and the blade fatigues and snaps at the weld or back edge. Manufacturer specs are non-negotiable on a production saw. Bi-metal blades: Typically 25,000-30,000 psi (172-207 MPa) tension across the blade body. Most production bandsaws have a tension gauge or indicator scale referencing these numbers. Carbide-tipped blades: Often 30,000-35,000 psi (207-241 MPa) — they need more tension to keep the wider stiffer body straight under heavier feed. Carbon steel blades: Lower at 15,000-20,000 psi — the back metal is softer, won't take the higher loads. The "pluck test" is a rough field check: tension up, then pluck the blade between the wheels. A correctly tensioned blade rings clearly; a slack blade thuds. It's not a substitute for a tension gauge but it'll catch an obviously slack blade. Warning: back off blade tension when leaving the saw idle overnight or for longer breaks. A blade held under full tension for days will develop fatigue stretches and weld stress that shorten its life. This is one of the easiest production wins — five seconds at shutdown extends blade life noticeably. Blade Guide Setup — Where Most Wandering Cuts Start Guide setup is the most-overlooked maintenance task on bandsaws. Worn guides let the blade twist and deflect under feed pressure, and the symptom shows as a wandering cut that operators blame on the blade. Three guide types in common use: Roller bearing guides: Most common on horizontal production bandsaws. Carbide rollers on the blade sides + thrust bearing on the back. Replace rollers when they show visible flat spots, the bearings have play, or the blade can be pushed sideways with hand pressure. Solid carbide block guides: Older horizontal saws and some vertical bandsaws. Cheaper to replace, but wear shows as a visible groove that mismatches the new blade width. Resurface or replace. Wheel-tyre guides (vertical bandsaws): The blade tracks on rubber-tyred wheels. Tyres wear, harden, and crack. Replace when the blade tracks off centre or you see chunks of tyre coming off. Guide spacing matters too — the guides should be no more than 5-10 mm from the workpiece on either side. Wide guide spacing leaves more unsupported blade between the guides and the cut, which means more deflection. On vertical bandsaws, drop the upper guide down close to the work before every cut. Cost-Per-Cut Thinking — When to Pay for Premium The right blade economically isn't always the cheapest. Cost-per-cut economics for a small fabrication shop running mild steel 5 hours a day: Blade type Price (indicative) Cuts per blade Cost per cut Cheap import bi-metal $45 200 $0.23 Excision M2 bi-metal $75 500 $0.15 Bahco M42 cobalt $110 800 $0.14 Carbide-tipped (mild steel) $280 1500 $0.19 For routine mild steel, the M2 bi-metal sits in the sweet spot. M42 is roughly the same cost-per-cut as M2 on mild steel but pulls way ahead on stainless. Carbide only earns its keep on hardened or exotic materials, or in volume on a production saw where uptime is worth the premium. Real cost driver: blade change time. If your operator spends 15 minutes changing a blade, at $50/hr labour that's $12.50 per change. The cheap blade saving $25 per blade purchase is wiped out if you change twice as often. Track changes not just blade unit cost. Blade Storage and Care Bandsaw blades arrive coiled in three loops. Handle them carelessly and they uncoil violently and slice you, or kink. Two things kill blade life in storage: Rust: Bare bi-metal blades rust if stored in damp or salty environments (coastal sheds, near-coast workshops). Light film of light oil before storage; wipe with WD-40 or an INOX MX2 type protective lubricant. Excessive surface rust is recoverable; pitting is not. Coil set damage: If a blade is uncoiled and re-coiled wrong, it develops a permanent twist or "memory" that makes it run untrue. Watch a YouTube video of the proper three-loop coiling technique before re-coiling a blade. For workshop organisation, hang blades on pegs by length and TPI label. Tool storage solutions at AIMS include peg boards and rack systems suited to blade hanging. Band Saw Blade FAQ What TPI band saw blade should I use for steel? For solid mild steel 3-25 mm thick, run 10-14 TPI bi-metal raker. For 25-75 mm thick, drop to 6-10 TPI. Above 75 mm use 4-6 TPI. For stainless steel of similar thickness, use M42 cobalt bi-metal at the same TPI — the cobalt grade handles the heat from work-hardening. What is the 3-tooth rule for band saw blades? At least 3 teeth must be engaged in the workpiece at all times — ideally between 6 and 12 teeth. Fewer than 3 teeth in contact causes tooth strip; more than 24 teeth packs the gullets with swarf. Match TPI to material thickness using this rule first. What's the difference between bi-metal and carbon steel band saw blades? Carbon steel blades are a single-piece hardened steel — cheap, flexible, fine for timber, plastic, and soft non-ferrous metal up to medium thickness. Bi-metal blades have a high-speed steel (HSS) tooth edge welded to a spring steel back, giving them heat resistance up to 500-600°C and the durability needed for serious metal cutting. Bi-metal lasts 5-10 times longer than carbon on steel. What blade do I need for cutting stainless steel on a bandsaw? M42 cobalt bi-metal at 10-14 TPI for stock 3-25 mm thick. Critical points: maintain constant feed pressure so the blade never dwells (stainless work-hardens in seconds if you let the blade rub), use flood coolant, and reduce band speed compared to mild steel — typically 40-60 m/min for 304/316. Why does my band saw blade keep breaking? Most common causes: over-tensioned (check manufacturer spec — typically 25,000-30,000 psi for bi-metal), wheel diameter too small for blade thickness (rule: blade thickness no more than 1/1000 of wheel diameter), twist in the blade from storage, weld failure on welded-to-length blades, or stress fracture from running with worn guide bearings. What is a variable pitch band saw blade? Variable pitch blades have teeth at irregular spacing across a short repeating pattern (e.g. 5/8 TPI varies from 5 to 8 across a section). The varying pitch breaks up the harmonic resonance that constant-pitch blades produce, reducing chatter, cutting noise, and tooth fracture on tube and structural section. Production metal cutting almost always uses variable pitch. How long should a band saw blade last? Bi-metal blades on production metal cutting: 200-1000 hours depending on duty cycle, material grade, feed rate, and coolant. Carbide-tipped: up to 2000+ hours on suitable material. Carbon steel blades on timber: 50-200 hours. Track blades by hours of cut time, not calendar time — a blade run hard for 8 hours/day wears far faster than one used occasionally. Should I use cutting fluid on a bandsaw? Yes for most metals — flood coolant or soluble oil for production steel and stainless, neat cutting oil for tool steel and exotic alloys, stick lubricant for aluminium. No for cast iron — fluid combines with cast iron dust to form an abrasive paste that wears the blade fast. No for timber and most plastics — dry is fine. What blade do I use for cutting aluminium on a bandsaw? 4-6 TPI skip-tooth blade. The big gullets clear long stringy aluminium chips that would otherwise weld to the tooth face. Add a lube stick (Excision Alube or similar) or kerosene mist to stop the chips welding. Avoid water-based coolant on small-section aluminium — it lifts the lubricating film. What's the difference between raker, wavy, and hook tooth set? Raker: one left, one right, one straight (raker), repeat — standard for solid metal cutting. Wavy: groups of teeth bent gradually left then right in a wave — ideal for thin tube and sheet. Hook: positive-rake aggressive cutter for thick wood or thick non-ferrous. Match set to material: raker for solids, wavy for thin-wall section, hook for heavy timber. How do I measure band saw blade length? Lay a tape measure flat on a bench. Mark a spot on the blade with chalk or marker. Align the mark to the zero on the tape. Slowly roll the blade along the tape, keeping it flat, until your mark returns. Read the tape — that's your blade length. Alternatively, calculate from your saw: blade length is approximately twice the centre distance plus pi times the sum of the two wheel radii. Can I use a wood bandsaw blade for cutting metal? No. Wood blades are typically carbon steel with a hook tooth at 3-6 TPI — both wrong for metal. Carbon steel loses its edge by 200°C (metal cutting easily exceeds this), and the coarse hook tooth violates the 3-tooth rule on most metal stock. Use a bi-metal blade with appropriate TPI for the material. Why is my bandsaw cut not square? Three common causes: (1) worn or misadjusted blade guide bearings letting the blade twist, (2) one side of the blade dull (often from cutting work-hardened stainless without coolant), (3) insufficient blade tension. Check guides first, then tension, then replace the blade. If the cut wanders consistently in one direction, the blade is asymmetrically dull. What band saw blade brands does AIMS stock? AIMS stocks Excision (Australian-distributed, broad bi-metal and carbide range with welded-to-length service), Bahco (Swedish premium, Sandvik-owned), and Sutton Tools (Australian-made cutting tool brand). Browse the full saw blades range or contact our team on +61 2 9773 0122 for help matching blade specs to your saw and your material. When should I replace a bandsaw blade versus sharpening it? For most workshops, bandsaw blades are replaced not sharpened — the time and equipment to grind a band correctly outweighs blade cost. Exceptions: large production blades (over 40 mm wide) on dedicated production saws, where in-house grinding services exist. If you're running consumer or workshop-grade bandsaws, replace when dull. Keep at least one spare on the shelf. For related selection guides, see Hacksaw Blade Guide (hand-cut metal), Cutting Speeds & Feeds Chart, and the Material Density Chart for related material-selection reference data. Browse the AIMS saw blades range or call our team on +61 2 9773 0122 for help matching blade to job. Related AIMS Industrial Engineering References For the engineering context behind band saw blade selection — material identification, cutting speed by material, and tooth geometry troubleshooting — see the AIMS Phase 4 master references. Phase 4 master references (universal engineering data): Workpiece Material Cross-Reference Chart — SAE / AISI / DIN / JIS / AS/NZS equivalents across 20 material groups Cutting Speeds & Feeds Reference — RPM and feed rate by material and tool type — drilling, milling, tapping, reaming Cutting Tool Materials Guide — HSS, HSS-Co, PM-HSS, solid carbide, PCBN and PCD explained Cutting Tool Coatings Guide — TiN, TiCN, TiAlN, AlCrN and premium coatings with application matrix Cutting Tool Troubleshooting Guide — 33 symptoms diagnosed across drills, taps, endmills, reamers and bandsaw blades Metric to Imperial Conversion Chart — mm, inches, drill # and gauge cross-reference Sister selection guides in the AIMS application cluster: AIMS Drill Bit Selection Guide — HSS / cobalt / carbide / masonry / tile selection by material and application AIMS Tap & Die Selection Guide — Hand, spiral point, spiral flute and forming taps — metric and imperial For purchase advice, technical questions or items not currently listed, ring AIMS Industrial on (02) 9773 0122 or use the contact page. Trade accounts and bulk pricing available. People Also Ask — Bandsaw Blades Q: What TPI should I use for cutting metal on a bandsaw? For metal cutting, the TPI selection depends on the wall thickness or cross-section of the material. The general rule is to maintain at least three teeth in contact with the workpiece at all times to prevent tooth stripping and vibration. For thin-walled tube or sheet metal below about 3mm, use 18–24 TPI. For medium sections of 6–25mm, 10–14 TPI is a common range. For solid bar or large structural sections above 25mm, 4–8 TPI provides efficient chip clearance. Bi-metal blades are strongly recommended for metal cutting as they resist the heat and tooth loading that destroys carbon steel blades quickly. Q: What is the difference between a bi-metal and a carbide-tipped bandsaw blade? Bi-metal blades have HSS teeth welded to a flexible spring-steel back. They outperform carbon steel blades significantly and are the standard choice for cutting most metals, hard plastics and composites. Carbide-tipped blades have tungsten carbide tooth tips brazed to the body, providing much greater hardness and heat resistance. They are used for cutting very hard materials such as hardened steel, cast iron, exotic alloys and abrasive materials that would quickly dull HSS teeth. Carbide-tipped blades are substantially more expensive but last many times longer on suitable materials. Q: Why does my bandsaw blade wander and cut crooked? Blade wander is most often caused by a blade that has become dull — a sharp blade tracks straight, a dull blade deflects sideways under feed pressure. Other causes include insufficient blade tension, guides that are set too far from the workpiece or worn, excessive feed rate forcing the blade sideways, or a blade that is too narrow for the radius being cut. Check blade condition first and replace if teeth appear rounded or chipped. Increase blade tension to the specification for that blade width. Re-set the blade guides to within a few millimetres of the workpiece on both sides. Q: How do I tension a bandsaw blade correctly? Most bandsaws have a built-in tension scale for different blade widths — use this as a starting point. A correctly tensioned blade should deflect only a few millimetres when pressed sideways with a finger near the guide. A blade that is under-tensioned will wander and may slip from the wheels; one that is over-tensioned risks cracking the back of the blade through fatigue. After fitting a new blade, run the saw briefly and re-check tension, as new blades settle and may need re-tensioning. Many manufacturers recommend releasing tension on the blade when the saw is not in use for extended periods to extend blade and machine life. Q: Can bandsaw blades be welded and reused after breaking? Yes — bandsaw blades are commonly welded using a blade welding machine that flash-welds and anneals the blade back joint. This is standard practice in production workshops where blade lengths are custom-cut from coil stock and where broken blades are routinely repaired rather than replaced. A properly welded joint, when cleaned, annealed and ground flush, should be nearly as strong as the original blade. Welded blade joints should be checked after welding by flexing the blade through 90 degrees before fitting — a brittle or mis-welded joint will break immediately. Consumer-grade bandsaws may not justify the cost of welding equipment, but industrial workshops typically find it cost-effective.
Read moreQuick Guide to Cleaning Agents
The pandemic has emphasised the value of keeping everything clean and sanitised. Let’s start with some basics. In this article, we discuss: The difference between cleaning vs disinfecting vs sanitising The difference between detergent vs disinfectant vs sanitiser Safety precautions when handling cleaning agents What commercial cleaning chemical to use (for the job) Cleaning vs disinfecting vs sanitising We’ve seen many people use these terms interchangeably, but they’re not the same thing. Here are the basic differences between the three, according to MedlinePlus.gov: Cleaning is basically the physical removal of debris, dirt, dust, grime, pathogens and other visible impurities -- usually using detergents and water -- by scrubbing the surface. This may not be enough to kill all the germs, but even so, should always be the first step in any sanitation routine. Disinfecting is basically the eradication of the germs by immersing the surface in chemicals called disinfectants for a certain amount of time (which varies). It is best done after cleaning. Sanitising is essentially reducing the number of germs possibly present in the surface to a “safe level”, either by cleaning, disinfecting or doing both. The “safe level” standard may vary, depending on the public health standards and requirements that apply to a certain scenario. Important: The surface must first be thoroughly cleaned before sanitising. Clean and sanitise food contact surfaces only with food safe chemicals. Do this after every use of the surface, utensils and equipment. Here’s a snapshot of a fact sheet by the Gladstone Regional Council: Detergent vs disinfectant vs sanitiser Detergent is a surfactant (or a mixture of it), usually in the form of liquid soap, and is sometimes intended to be diluted in water. It is formulated to wash away debris, dirt, dust, grime, pathogens, and other visible impurities from the surface. They are not necessarily designed to kill bacteria. Disinfectant is an antimicrobial chemical formulated to eradicate and significantly reduce the presence of microorganisms and pathogens (eg. bacteria, fungi, and viruses) on hard surfaces and in the water. It is not intended for use on food contact surfaces. Sanitiser is a chemical that is used “after detergents” to eliminate bacteria and spores on the surface. For food preparation and storage, be sure to use “food-grade” sanitisers, marked accordingly. Safety precautions when handling cleaning agents Train your staff / users in safe chemical handling: Make sure they know how to properly prepare, use and store all the various cleaning agents in your inventory. They should be aware that those substances must be handled with care, keeping in mind that cleaning agents generally: May be irritants, so it’s best to avoid direct skin contact May be poisonous, so avoid ingesting them May be flammable, so keep them away from potential sources of combustion Must be labelled appropriately, according to safety standards In addition, they should know what to do in cases of an emergency related to using cleaning agents. For instance, they should have read (and know where to locate) the safety data sheets (SDS) in case they need safety information. Know your (cleaning) chemicals: Don’t automatically assume that the detergent, disinfectant and sanitiser are safe for skin contact. According to Comcare, in general, if you are not sure if a chemical is safe: Treat any unknown substance as a hazardous chemical, until it is proven not to be hazardous. Notify your manager if you encounter an unknown and unlabeled chemical or substance. The person conducting a business or undertaking (PCBU), who is usually the employer, is responsible for identifying the chemical and (1) obtaining appropriate safety information for it, or (2) safely disposing of the unknown chemical. It is even cited as an example in the Work Health and Safety (Managing Risks of Hazardous Chemicals in the Workplace) Code of Practice 2015 under the section “Consulting, co-operating and co-ordinating activities with other duty holders”: “For example, if you engage a contractor to carry out cleaning at your workplace that involves the use of chemicals, you should find out what is being used, whether there are any hazards associated with the chemicals and how the risks will be controlled. This might, for example, include jointly preparing a risk assessment for the chemicals being used, how they will be handled and measures that should be taken to eliminate or minimise exposure. After the risk assessment has been prepared, it is important for all duty holders to co-operate and co-ordinate activities with each other to implement the control measures.” Of course, this also applies to your business if it’s your staff handling the cleaning agents themselves. Important: Be more cautious when cleaning surfaces and equipment related to food processing. Make sure the cleaning agents that you use are “food safe”. You don’t want residues coming in contact with ingredients and raw materials. Be aware of existing health issues amongst your workforce: As you know, cleaning agents may contain strong formulations which could be harmful to users with pre-existing conditions, such as asthma. Read and understand the SDS: As defined by Safe Work Australia (SWA), this document contains information about a hazardous chemical, its health and environmental risks, incompatibilities (with other chemicals), exposure standards (for airborne contaminants), what to do in case of accidental spills, first-aid information and how to safely handle, transport and storage the product in question. As a PCBU, you are required by the SWA to refer to SDSs to keep your workers safe.All relevant cleaning products listed on our website should have links to current Safety Data Sheets, as provided by the manufacturer. Shown is a CRC bio-degreaser, where the link to the product's SDS is highlighted Read the label: Always read the instructions on the chemical container and packaging before using the product. Although this is not a replacement to the SDS, the information provided here usually cites, in layman’s terms, the practical guidelines for the user. Also shown on labels are (1) ingredients (eg. allergens) that may be harmful to some people with pre-existing health conditions, and (2) what to do when the product has made direct skin contact or was accidentally ingested. Obviously, if there is no label on the product, then you will have no basis for knowing if it’s safe to use or not. This often happens when the chemicals are stored in a different container to the original. Store chemicals appropriately: Speaking of which, it’s important to keep the cleaning agents in the original container they came in. A lot of them will come in hard plastic bottles and metal cans. What you put in those bottles is not necessarily interchangeable. Aside from the fact that some chemicals are strong enough to melt plastic, you also don’t want to top up a container with a different chemical. You never know if you’re in for a bad surprise when the incompatible chemicals react. In addition, put “Dangerous Good” signs on the cabinets where you store cleaning agents. Here’s more information from the SWA on why it is important to safely store hazardous chemicals. Don’t mix and match chemicals: Chemical experiments are best left with chemists who know what they’re doing. Unless you’re one, don’t play with chemicals. In a household setting, here are some known bad combinations of chemicals you should not mix, according to Reader’s Digest: Bleach and alcohol Bleach and ammonia Bleach and multi-purpose cleaners Bleach and mold, mildew and stain removers Bleach and oven cleaners Bleach and vinegar Different drain cleaners Hydrogen peroxide and vinegar As you may have noticed, bleach doesn’t get along very well with other substances, aside from water. In a commercial setting, you may be working with even stronger chemicals that are formulated to deal with tougher, heavy-duty applications. Therefore, take extra precautions by using the correct personal protective equipment (PPE). Wear PPE as appropriate: Not all cleaning agents are safe for skin contact. At the very least, wear disposable gloves and some basic eye protection, as the liquid may splash all over and into the eyes. Trust your nose and throat when they feel irritated; that usually tells you it’s time to wear a mask to avoid (or at least significantly limit the amount of) chemicals and fumes from being directly inhaled. As with all safety related issues, always err on the side of caution. “Too much” PPE is better than too little, so long as it does not inhibit your movement excessively. Make sure there is proper ventilation where you’re cleaning: Most disinfectants and aerosol cleaners should be left to air-dry. Some are meant to be soaked into the surface for quite some time before rinsing. Consequently, fumes may accumulate in the room, so you should have an easy way to ventilate them out into open air. Don't smoke while cleaning: Speaking of fumes, you never know exactly what’s combustible, so save the cigarette for later. (As if it’s not hard enough to puff one with the wet gloves on.) Wash your hands after cleaning: If you think soap and water are enough, think again. Even when you’ve worked with gloves on, your hands probably still made some contact with chemicals and surfaces. Clean them properly with hand cleaners specially formulated for the job. What commercial cleaning chemical to use? While some household cleaning best practices are universally applicable, there are other precautions that a business should take, depending on their industry. For instance, if you’re in food processing and it’s time to clean your equipment, make sure to use only food grade products, such as this bio-degreaser by CRC. Here’s a short list: Detergents and surface cleaners: Used in light duty applications to remove visible dirt, grime and stains from most surfaces. Some are even specially formulated to remove lime, rust and oil stains Disinfectants and sanitisers: Used in light and medium duty applications to provide residual protection on most surfaces, equipment and tools Wood furniture polishes and waxes: Formulated to be applied to clean and restore wood finishes Contact cleaners: Formulated to get rid of contaminants from sensitive electrical and electronic parts Degreasers: Formulated to clean the dirt, grease, oil and grime build-ups off surfaces and equipment Other cleaning chemicals, equipment and supplies Aside from the cleaning agents mentioned above, you may also want to check other related cleaning products. For general cleaning routines: Brooms, dustpans, brushes, scrubs and other accessories Dispensers, sprayers and pumps Vacuum cleaners Rags and wipes For components and automotive applications: Engine degreasers, brake cleaners and sensor cleaners Parts washers and cleaners (Here's a quick guide to spring-cleaning your car.) In a nutshell Train your staff / users in safe chemical handling. Know which chemicals you’re dealing with. Read the safety data sheets. Read the label. Don’t experiment, mix and match or ‘play’ with cleaning chemicals. Wear PPE as appropriate. Use the right cleaning agents for the job. Wash your hands after cleaning. Put simply, use your common sense and always err on the side of caution. AIMS' Note on Safe Use of Parts Washers and Parts Cleaning Chemicals Protective gear: Protect your skin and eyes! Wear chemical-resistant gloves to prevent skin irritation or absorption of chemicals. Safety glasses or goggles provide essential eye protection. Additionally, consider using a respirator if fumes are particularly strong or you are working for an extended period. Labels and instructions: Before using any product, carefully read the instructions and safety warnings on the label. Follow the specific guidelines for usage, proper handling and disposal. Check for ‘use by’ dates. Fire hazards: Many parts cleaners and lubricants are flammable. Keep them away from open flames, heat sources, and anything that could cause a spark. Store these products in a cool, dry location in their original containers, out of the reach of children and pets. Environment: Choose less toxic and environmentally friendly options whenever possible. Make sure there are no open flames or anything that can ignite flammable substances. Dispose of used products and empty containers responsibly according to the instructions or your local hazardous waste guidelines. Ventilation: When working with chemicals that release strong fumes, always work in a well-ventilated area, preferably outdoors or in an open area. If you are working indoors, make sure that the windows are open and consider using fans to increase airflow and disperse / vent out the fumes. Share: Share on Facebook Share on X Pin on Pinterest Previous Post How To Use Your WD40 To The Last Drop Next Post Choosing The Right Band Saw Blade Related Posts bordo Reciprocating Saw Blade Guide: TPI Selection, Bi-Metal vs Carbide, Wood/Metal/Demolition Blade Choice May 11, 2026 AIMS Industrial bsp Grease Nipple & Zerk Fitting Guide: Thread Sizes, Types, BSP vs UNF & How to Identify May 11, 2026 AIMS Industrial bolt-extractor Bolt Extractor Guide: Easy-Outs, Spiral Flute, Multi-Spline & Bolt Extractor Sockets May 11, 2026 AIMS Industrial People Also Ask — Quick Guide to Cleaning Agents Q: What is the difference between a cleaner and a degreaser? A cleaner removes general soiling — dirt, dust, and water-soluble contaminants — typically using surfactants and water. A degreaser removes oils, greases, fuels, and hydrocarbon contamination using stronger solvents or high-alkalinity chemistry. In many industrial applications you need both: degrease first, then clean. Using a mild cleaner on heavy grease is ineffective; using a harsh degreaser on light soiling wastes product and increases hazard exposure. Q: What is the best product for cleaning concrete workshop floors? For concrete floors with oil and grease contamination, an alkaline degreaser (pH 11–13) diluted in warm water is most effective — apply, agitate with a stiff brush or floor scrubber, allow dwell time (5–15 minutes), then rinse thoroughly. Heavy contamination may require a solvent-based degreaser first. Avoid acid cleaners on bare concrete as they etch the surface and accelerate wear. Q: How do I safely use solvent-based cleaners in a workshop? Ensure adequate ventilation — natural airflow or forced extraction to keep vapour concentrations below the TLV (threshold limit value, found on the SDS). Use nitrile gloves and chemical splash goggles; solvent contact with skin removes protective oils and can cause dermatitis. Store solvents in approved flammable-liquids cabinets away from ignition sources. Never use in enclosed spaces without respiratory protection. Q: Can I mix cleaning chemicals to make them more effective? Never mix cleaning chemicals unless the product label specifically states they are compatible. Mixing bleach (sodium hypochlorite) with acid-based cleaners releases chlorine gas — toxic, even at low concentrations. Mixing bleach with ammonia produces chloramine vapours. Mixing different brands of the same product type (e.g., two degreasers) can cause unpredictable reactions. Always read the SDS for incompatibility warnings before combining any products.
Read more
WD-40 Straw Hack: Use Every Last Drop From the Can
(Taken from this post by WD-40. Republished with permission. Edited for point of view, recency and relevance.) WD-40® Multi-Use Product can be used upright or upside-down only. When the can is upright, the product will flow through the dip tube. When upside down, the product will dispense directly from the valve at the top of the can. If a WD-40® Multi-Use Product is sprayed at a horizontal angle, or any angle that lifts the dip tube out of the liquid, then propellent can escape within seconds. This results in “out of gas”, or liquid left in the can that cannot be sprayed out. Once a can is out of gas, there is no way to get the rest of the liquid out. To maximise the use of all liquid from your WD-40 Multi-Use Product aerosol, follow the steps below. In this article, we discuss three steps to remove all product from a WD-40 can: Shake can Spray upright or upside down Orientate the dip tube using the classic spray or smart straw Step 1: Shake can Shake the can well. This will quickly mix the additives and solvent together so that you get an even mixture and the best results. Pro tip: This is standard practice and a good habit to get into as most aerosol products require this step. Step 2: Spray upright or upside down If you want to get the most out of your can, you need to hold it correctly. Many people make the mistake of spraying horizontally, but this can cause the gas to escape. For best results, the can should be held in an upright or upside-down position, as this ensures the liquid will readily flow out when the nozzle is pressed. You will need to orientate the dip tube by following Step 3. Illustration courtesy of WD-40 Step 3: Orientate the dip tube using the classic spray or smart straw Before spraying an aerosol, you need to make sure that the dip tube is correctly aligned to reach the lowest point of the can when spraying. Classic Spray: The dip tube is curved so that it will always be seated at the bottom edge of the aerosol can. This, combined with the domed shape at the bottom of the aerosol can, allows you to extract all the liquid from the can if positioned correctly. Pro tip: Some aerosols display a blue dot on the top of the valve which indicates the curvature of the dip tube (for example, the WD-40 Multi-Use Product without the Smart Straw). Smart Straw: To check that the position of the dip tube of the smart straw is correct, lightly press the nozzle to ensure product comes out. If no product or small amounts of product come out, stop spraying immediately and turn the nozzle to the right by a quarter (¼) and try again. Repeat the quarter (¼) turn until product comes out. There you have it -- the simple way to get all the product from the can! Disclaimer: The uses shown and described for WD-40 Multi-Use Product were provided to WD-40 Company by the users themselves. These uses haven’t been tested by WD-40 Company and do not constitute a recommendation of suggestion for use by WD-40 Company. Common sense should be exercised whenever using WD-40 Company products. Always follow the instructions and take heed of any warnings printed on the packaging. This blog's sub-topics
Read more
Easy Greasing with the Macnaught K29 Flexigun
Here are more reasons why this grease gun is a best-seller and what actual users say about it.
Read more
How to Remove Stuck Bolts & Nuts: 11-Step Escalation
A stuck bolt or seized nut is one of the most frustrating problems on a workbench, vehicle, or piece of plant. Brute force usually makes it worse — snapped bolts, stripped heads, and damaged threads cost more time than the original job. The right approach is a calm escalation ladder: start with the gentlest method that has any chance of working, and only step up when the previous step fails. This guide walks through 11 steps from penetrating oil to weld-nut-on cut-out, with material-specific notes, stripped-head recovery, and how to stop it happening again. Quick Reference: The Stuck-Bolt Escalation Ladder Step Method Tool / Product When to use 1 Penetrating oil CRC 5-56, CRC Brakleen, PB B'laster, Plus Gas First move on any rusted or seized fastener. 2 Vibration / shock Hammer + punch (centre or pin) Tap the head to break the rust bond before applying torque. 3 Heat LPG/MAP/oxy torch, heat gun Expand the nut to break the seize. Avoid near fuel, brake lines, polymer. 4 Cold contraction Freeze release spray (Loctite LB 8040, CRC Freeze) Shrinks the bolt relative to the nut. Good where heat is unsafe. 5 Impact Manual impact driver, air or electric impact wrench Loosens by shock, not pure torque. Use impact-rated sockets only. 6 Leverage Breaker bar, long-handle ratchet, cheater pipe When torque is the only thing missing — within bolt grade limits. 7 Bolt extractor Spiral extractor, screw extractor, locking pliers Head is rounded, stripped, or partly sheared. 8 Drill out Cobalt or carbide drill bits, progressive sizing Extractor failed, or bolt has snapped flush. 9 Re-thread Hand tap matching original thread Clean and recut the threads once the broken stud is out. 10 Thread insert Helicoil or solid thread insert kit Original threads beyond saving — restore to nominal size. 11 Cut & weld Cut-off wheel, MIG welder, replacement nut Last resort — weld a new nut onto the stub and unwind. Work top to bottom. Most stuck bolts are released somewhere between Step 1 and Step 5. Drilling and inserts are not failure — they are repair operations once the fastener can't be saved. Why Bolts Seize Understanding the cause narrows the right move. Rust and corrosion — moisture between threads forms iron oxide, which has greater volume than steel. The threads physically lock. Penetrating oil and time are the answer. Galvanic corrosion — dissimilar metals (steel bolt in aluminium housing, stainless in mild steel) plus moisture form an electrochemical cell. Aluminium engine fittings, marine hardware, and rooftop installations are common sites. Galling — stainless on stainless, especially A2/304 and A4/316. Surface oxide layers cold-weld together under load. Once galled, heat won't release it; the fastener has to be cut or drilled. Thread locker — anaerobic adhesive (Loctite blue 243, red 271, green 290) hardens between threads. Blue 243 releases at roughly 250°C; red 271 needs around 300°C. Cross-threading — the bolt was started off-axis on assembly. Spins free initially, then locks. Backs out the way it went in if caught early. Mechanical lock — bent shaft, damaged head, distorted nut. Extraction or cutting is the only path. Over-torque on assembly — bolt yielded, threads partially stripped from new. Same removal problem as rust without the time component. Step 1: Penetrating Oil The first move on any stuck fastener. A good penetrant uses capillary action to wick between thread surfaces, displace moisture, and loosen the rust bond. Don't confuse general-purpose lubricants like WD-40 with proper penetrants — WD-40 is mainly a water displacer with light oil, not optimised for capillary penetration. Modern dedicated penetrants are dramatically more effective on rusted fasteners. What AIMS stocks (CRC range, 218 products): CRC 5-56 — flagship penetrant, works on rust, displaces moisture, lubricates threads as it frees them. CRC Brakleen — solvent cleaner that washes rust scale before penetrant goes on. CRC Inox — corrosion inhibitor; good for prevention and as a finishing wipe after the bolt is out. Loctite LB 8040 Freeze & Release — penetrating oil with built-in cold-shock chemistry. Useful when heat is unsafe. PB B'laster, Plus Gas, Kroil — specialist penetrants well-regarded in trades. AIMS can source on request. Technique: Wire-brush off loose rust and debris around the fastener. Penetrant can't reach what's blocked by scale. Apply a generous shot. You want it sitting on the joint where capillary action can pull it in. Tap the head firmly with a brass or steel hammer (steady taps, not crushing blows). Vibration helps the oil migrate into the threads. Wait. Light surface rust: 5–15 minutes. Moderate rust: 1–2 hours. Severe rust: 24 hours, with several re-applications and tapping cycles. Try to undo gently. If it doesn't move, repeat — don't escalate prematurely. Most fasteners that come free with penetrant alone need TIME more than chemistry. The trades habit of "spray, walk away, come back tomorrow" exists for a reason. Step 2: Vibration and Shock A few firm hammer taps directly on the head of the bolt (or on a punch placed in the centre of the head) "convinces" the corroded threads to relax. The shock breaks micro-bonds in the rust layer. Combined with penetrating oil, this is one of the highest-yield steps before any tool change. Use a heavy hammer and a hardened punch — short, controlled strikes. For seized exhaust manifold bolts (a common Australian ute job), a few taps with a bolster hammer often beats reaching for the impact gun. Tap, then re-apply penetrant, then wait. The micro-cracks open new capillary paths. Don't pound a thin-walled casting. Use a softer hammer or back the work with a bolster. For a more aggressive variant: place a hardened punch (centre or pin) into the head of the bolt at a counter-clockwise angle and strike firmly with a hammer. The combined impact plus rotational bias often jars the bolt loose where pure torque has failed. Effective on Phillips-head and slotted bolts that have cammed out. Find punches in the AIMS marking tools and punches range. Step 3: Heat Heat expands the nut faster than it heats the bolt (the nut is exposed; the bolt is shielded inside it). The expansion breaks the rust bond. Used correctly, heat is dramatic — used carelessly, it sets the workshop on fire. Target the nut, not the bolt — you want the nut to grow while the bolt stays close to its starting size. Temperature guidance: Bright red on mild steel ≈ 700–800°C. Effective for breaking rust bonds but the bolt is now annealed and weak. Cherry red ≈ 600°C. Enough for most stuck fasteners; bolt usually needs replacing afterwards. Dull red ≈ 500°C. Marginal for very seized fasteners; lower risk of damaging surrounding parts. Heat gun (~300–550°C): useful for thread-locker breakdown without going incandescent. Loctite breakdown temperatures (manufacturer guidance — ): Loctite 243 (blue, medium strength) — softens around 250°C. Loctite 271 (red, high strength) — needs roughly 250–300°C to release. Loctite 290 (green, wicking) — similar to 271. Aluminium hesitates around 200°C; nylon-insert nuts melt at 100–120°C. SAFETY: Never heat a fastener near: brake or hydraulic fluid (vapour ignition), fuel lines or tanks, plastic or rubber hoses, painted panels you want to keep, sealed grease bearings, or pneumatic tyres. On vehicles, identify what's behind the bolt before lighting the torch. Have a fire extinguisher within arm's reach. AIMS related ranges: gas welding equipment covers oxy/LPG torch kits suitable for stuck-bolt work. Step 4: Cold Contraction The opposite play to heat. A blast of freeze release spray cools the bolt below the surrounding material's temperature — the bolt shrinks slightly while the nut and casing stay at ambient. Combined with a built-in penetrant, the brief moment of shrinkage is often enough to release the seize when you turn the spanner straight away. Loctite LB 8040 Freeze & Release — dual-chemistry: cools to around −40°C while delivering penetrating oil. Stocked in the AIMS Loctite range. Apply directly to the bolt head/shaft for several seconds. Turn the fastener while the cold is still on it — the window is short (seconds, not minutes). Excellent option near fuel systems, brake lines, polymer bushings, painted panels — anywhere heat would cause damage. Wear cold-resistant gloves: the can and the bolt will frostbite skin. Step 5: Impact An impact tool delivers many short rotational hammer blows rather than a single steady torque. The shock dislodges the rust bond and lets the bolt move in tiny increments. This is often the breakthrough step on rusted automotive and machinery bolts. Manual impact driver — a hand tool you strike with a hammer; the internal cam converts axial blow into rotational impulse. Cheap, simple, and surprisingly effective on stripped Phillips and stuck cross-head fasteners. Pneumatic and electric impact wrench — what most workshops reach for. Stocked at AIMS under impact drivers and within the broader power tools range. CRITICAL — impact sockets only: Chrome vanadium sockets are designed for steady hand-tool torque. Under impact loading they can shatter explosively, sending steel fragments at face level. Always use impact-rated sockets (typically matte black finish, marked "Impact" or "IMP") on impact wrenches. Standard chrome sockets on an impact wrench is the single most common shop injury cause with these tools. Ko-Ken impact sockets (468 products) are a workshop standard. Eye protection is non-negotiable. Bolt grade limit: If you bury an impact wrench at full torque on a Grade 4.6 or 8.8 bolt with a high-power gun (1,000+ Nm), you can twist the bolt off. Modulate the trigger — short bursts, not held wide open. Even after penetrant and time, a heavily corroded bolt may still snap under impact. Have a replacement bolt ready and accept the risk before squeezing the trigger. Step 6: Increased Leverage Sometimes you just need more torque. A breaker bar is the right answer; a "cheater pipe" extension over a ratchet handle is the wrong one — ratchets are designed for a defined torque ceiling, and over-leveraging them blows the internal pawls. Breaker bar (1/2" or 3/4" drive) — solid steel handle, no ratchet mechanism. Designed exactly for this. Stocked at AIMS under ratchets & sockets. Long-handle spanner — for stuck fasteners with limited access. AIMS' Stahlwille, Bahco, Wiha, Trax and Maxigear ranges include long-pattern spanners for tight torque. Bolt grade limits torque ceiling. A Grade 8.8 M16 bolt yields at ~210 Nm. Push past that and the bolt yields elastically, then plastically, then snaps. Use a metric bolt torque chart for the bolt grade rating. Apply steady increasing force, not jerks. Sudden shock here moves you back to Step 5 territory without the impact-tool design margin. Step 7: Bolt Extractor When the head is rounded, broken, or sheared and conventional tools no longer engage, bolt extractors take over. There are two main families: External extractors (grip socket / twist-grip): spiralled inner geometry, hammered down over a damaged head — the spirals bite as you turn counter-clockwise. Faster and less invasive than internal extractors. Internal extractors (screw extractors / spiral extractors / "Easy-Outs"): reverse-spiral tools driven into a drilled pilot hole. As you turn counter-clockwise, the spiral bites the bolt walls and torques the broken stud out. Stocked at AIMS in the extraction & removal tools range (41 products) — Bordo extractor sets are common in our customer base. Technique for internal extractors: Centre-punch the broken bolt to start the drill bit cleanly on-axis. Drill a pilot hole sized to the extractor's specification — typically 1/3 to 1/2 the bolt diameter. Sizing matters; too small and the extractor breaks, too large and there's no metal left to bite. Apply penetrant; let it sit. Insert the extractor, hammer lightly to seat the spirals, then turn counter-clockwise with steady torque using a tap handle (not a ratchet — extractors are brittle and break under sudden torque). If you feel the extractor flexing or hear cracking, stop. A broken extractor inside a broken bolt is the worst-case scenario and may need EDM (spark erosion) to remove. For a deeper walkthrough including bit-size charts and which extractor to use when, see the AIMS bolt extractor guide. Step 8: Drill Out When extractors fail or aren't suitable, drilling out is the structural fallback. The aim is to remove the bolt body, ideally leaving the threads in the parent material intact for re-tapping at Step 9. Drill bit selection: HSS works on Grade 4.6/8.8 mild and medium-strength bolts. Cobalt (M35/M42) for Grade 10.9/12.9 hardened bolts and stainless. Heat-resistant, holds an edge in tough material. Stocked at AIMS as cobalt drill bits; the cobalt drill bit guide covers grade selection. Carbide-tipped for hardened or work-hardened stainless that even cobalt struggles with. Brittle — needs rigid setup. Technique: Centre-punch dead-centre on the broken bolt. Off-centre = damaged parent threads. Start with a small pilot (3 or 4 mm) drilled perpendicular. A drill press or magnetic base is far better than freehand. Use cutting fluid generously — heat kills drill bits. AIMS stocks Tap Magic and other cutting fluids in the cutting fluid range. Progress through sizes (3 → 5 → 7 → 9 mm for an M10 bolt, for example). Stop one size under the bolt's minor thread diameter — the last shell of bolt material will chase out with a tap, leaving the parent threads usable. If you go too large or wander off-axis, the parent threads are damaged and you move to Step 10. Step 9: Tap and Re-thread Once the bolt material is drilled clear, run a hand tap of the same thread spec (e.g. M10 x 1.5) through the hole to clean and recut any partially damaged threads. Use a tap wrench, not a powered driver — feel matters. Apply cutting fluid; back the tap off every half turn to clear chips. Use the AIMS tap drill size chart to confirm pilot drill vs final thread size. AIMS stocks 599 tap products under taps, including Sutton (Australian-made), Bordo and OSG. If the recut tap pulls clean threads through, you're back in service with a fresh bolt at original spec. If the tap snags or strips, threads are beyond saving — proceed to Step 10. Step 10: Thread Insert (Helicoil) When parent threads are damaged beyond repair, a thread insert restores nominal size. Two main systems: Wire coil inserts (Helicoil / Recoil) — a stainless wire coil installed into an oversized tapped hole. Re-establishes the original thread size with a stronger thread engagement than the parent material. Solid bushed inserts (Time-Sert, Keensert) — solid sleeves threaded externally and internally. Stronger and reusable; standard fix for spark plug holes, head bolt holes, and high-load applications. AIMS stocks thread inserts (36 products). Installation kits include the step drill, oversize tap, and insertion tool sized for the specific insert system. Worked properly, a thread insert restores the joint to original or better than original strength. This is a routine repair in alloy engine work and high-cycle assembly. For a full decision tree on choosing between re-tap, oversize, Helicoil, TimeSert or Keensert repairs — and the prevention habits that stop stripped threads happening again — see our Stripped Threads: Repair Options & Prevention Guide. Step 11: Cut and Weld (Last Resort) For broken studs that are too short to grip, too damaged to extract, and in positions where drilling-out isn't safe: Cut the bolt flush or just proud using an angle grinder with a thin cut-off wheel. Place a fresh nut (sized to fit OVER the broken stud, larger than the original) on top of the cut-off stub. MIG-weld through the centre of the nut, filling it onto the broken stud. Weld penetration through the nut gives a solid bond plus heat that breaks the rust bond simultaneously. Let it cool briefly (a minute or two — not fully cold), then turn the welded-on nut counter-clockwise with a spanner. The heat-soaked threads usually break free. This is a workshop fallback, not a first-line method. Adjacent paint, fuel and brake-line clearances must be checked. AIMS stocks MIG and stick welders, consumables, and PPE in the welding range. Material-Specific Notes Brass and Copper Fittings Heat very carefully — brass anneals soft above ~400°C and threads strip easily. Penetrant + gentle leverage + manual impact driver is the safer escalation path. Plumbing brass commonly seizes via dezincification corrosion; the threads can be lace-thin under the surface. Aluminium Steel bolts in aluminium housings (engine blocks, gearbox covers, marine fittings) are the classic galvanic-corrosion case. Hot-cold cycling alone — gentle heat to ~150–200°C then cool — often releases without escalation. Don't go above ~200°C — aluminium loses temper around 250°C and the parent threads can fail. Anti-seize compound (Loctite Nickel or C5-A) on reassembly is mandatory for this combination. Stainless on Stainless (Galled) Once stainless has galled, heat does not release it — the surfaces are cold-welded. Penetrant rarely helps. Direct path is to cut the fastener with a thin cut-off wheel, drill out the remainder, and rethread. Prevention is the better answer: anti-seize on every stainless-on-stainless thread, hand-tightening only, no power tools. Cast Iron Brittle — watch for cracking under impact loads. Heat works well (cast iron handles 700°C+ comfortably) but localised heat plus cold can crack the casting. Heat the whole boss evenly with a soft flame, not a focused jet. Stripped Head Recovery Rounded Hex / Stripped Allen Key Socket Try one size SMALLER imperial socket (e.g. 9/16" on a rounded 15 mm hex) — the slight undersize bites into the rounded corners. Hammer a Torx bit one size larger than the original socket size into the stripped recess; the points cut a fresh purchase. If neither works, switch to an external bolt extractor socket — grip-style with internal spirals that bite as torque is applied. Failing that, drill and extract. Blown Torx or Cammed Phillips Pack the recess with valve-grinding paste or a thin smear of cyanoacrylate (super glue) on the driver tip; sometimes that's enough to torque it free. Try a left-hand drill bit — half the time, the act of drilling counter-clockwise alone unwinds the bolt. Internal extractor as above. Snapped Flush with Surface Centre-punch dead-centre on the broken stub. Pilot drill, then extractor. If geometry allows, weld-nut-on (Step 11) usually beats drilling for fully seized snapped bolts. Snapped Below Surface Drilling and extractor only. Welding access is gone. For deep seized fragments, professional EDM (spark erosion) removal is sometimes faster and cheaper than risking damage to the parent threads. Preventing Recurrence Most stuck-bolt jobs come back. Prevention takes 30 seconds at reassembly and saves an hour next time. Anti-seize compound on every fastener exposed to weather, dissimilar metals, heat cycling, or stainless-on-stainless contact. Loctite C5-A (copper-based) for general work; Loctite Nickel anti-seize for stainless and high-temperature joints up to ~1,100°C. Stocked at AIMS within the Loctite range. Correct torque — over-torque deforms threads and accelerates corrosion. Use a torque wrench against a metric bolt torque chart for the grade. Clean threads before assembly — wire-brush old paint, scale and corrosion off both bolt and parent threads. A chase tap through a tapped hole takes seconds. Don't lubricate under the head unless the torque value calls for it — head-friction lubrication changes the torque-to-tension relationship, causing over-tension and silent yielding. Thread locker correctly — Loctite 243 (blue) for fasteners that need to come out occasionally with hand tools. Reserve Loctite 271 (red) for permanent assemblies — see the Loctite 243 application guide for selection. Galvanised or stainless hardware on outdoor work — initial cost is higher; rust-jobs in three years are far more expensive. Common Stuck-Fastener Jobs — Worked Examples Exhaust Manifold Bolts (Automotive) Symptoms: rusted Grade 8.8 bolts, often with snapped heads on previous removal attempts. Heat cycling from engine operation accelerates corrosion. The bolt closest to the head is usually the worst. Penetrant 24 hours before the job — Loctite LB 8040 Freeze & Release or CRC 5-56. Two applications, 12 hours apart, with light tapping between each. Heat with oxy or LPG torch directly on the nut to dull red. The bolt is shielded inside the manifold flange; the nut takes the expansion. Manual impact driver or low-torque air impact with short bursts. Don't bury the trigger. Replace with new bolts on reassembly — heated bolts are softened and shouldn't be reused. Apply Loctite Nickel anti-seize on the new bolts for next time. Wheel Lug Nuts (Stuck on Studs) Symptoms: wheel won't come off after years of road service. Galvanic corrosion between alloy wheel hub and steel stud is the usual culprit. Penetrant on the stud-to-wheel interface; let sit while you do other work. Loosen all nuts with the car on the ground, then jack up. If the wheel won't come off, refit the nuts finger-tight, drive 10–20 metres in a straight line, then forwards-and-back. The forces usually break the corrosion bond. Never beat the wheel face with a hammer — alloy wheels crack. Kicking the inside of the tyre tread is safer. Anti-seize on the hub face (not the threads) on reassembly. Sump Plug Frozen in Aluminium Pan Symptoms: oversized hex from previous over-torque, surrounded by aluminium sump that you cannot afford to damage. Anti-seize was missing. Place a hardened external socket extractor (grip-style) over the rounded plug. Light tap with a hammer to seat the spirals, then steady torque on a breaker bar — no impact. Don't heat — the aluminium loses temper around 250°C and the parent threads will fail. Anti-seize on the new plug to spec torque (typically 25–30 Nm for M14 plugs; ). Rusted Outdoor Bolts (Trailer, Fence, Roof) Symptoms: galvanised or zinc-plated bolts that have rusted through the coating, often with seized nuts and visible scale. Wire-brush off scale to expose threads. Penetrant — generous, with vigorous tapping. Leave overnight. If access allows, heat the nut with an LPG torch (away from any flammable cladding). Spanner with a sleeve extension for leverage if the bolt grade is sufficient. Otherwise, grinder. Replace with stainless or hot-dip galvanised hardware. Anti-seize the threads on assembly. Snapped Stud in Engine Block Symptoms: head bolt or accessory mounting bolt snapped flush with the deck. Drilling on-axis is critical or the parent threads die. If a stub protrudes: weld a nut on (Step 11). Often beats drilling. If snapped flush: centre-punch dead-centre, pilot drill, then internal extractor on a tap handle. If extractor breaks: stop. A broken hardened extractor inside a stud is the worst-case scenario — needs EDM (spark erosion) at a specialist shop. Drilling further with a HSS or cobalt bit just damages the bit on hardened extractor remnants. Have a Helicoil kit on hand before you start. If the threads need restoration, you'll need it then and there. Stainless Bolt Galled in Stainless Nut (Marine) Symptoms: deck hardware, mast fittings, anchor brackets. The fastener spun in, then locked partway out. Heat and penetrant both ineffective. Accept the bolt is sacrificial. Cut with a thin cut-off wheel — most stainless deck bolts can be sliced flush in seconds. Drill out the remaining stub, rethread. Future-proof: always anti-seize stainless threads (Loctite Nickel), hand-tighten only, no power drivers on stainless. Tool Kit for Stuck-Fastener Work If you're regularly fighting seized bolts, build a dedicated kit. Adding pieces as you hit each problem is slower than just starting with the lot. Three penetrants: CRC 5-56 (general), Loctite LB 8040 Freeze & Release (where heat is unsafe), and one specialist (PB B'laster or Plus Gas) for the worst jobs. Centre punches, pin punches, brass and steel hammers in 16 oz and 32 oz. LPG hand torch for moderate jobs; oxy/MAP for the worst. Manual impact driver plus 1/2" air or electric impact wrench. Full impact-rated socket set (metric + imperial) — Ko-Ken is the workshop standard. Breaker bar in 1/2" drive, 18" minimum length. Bolt extractor set (external grip + internal spiral) — Bordo and similar from the extraction & removal tools range. Cobalt drill bit set in incremental sizes from 2–13 mm for drill-out work — cobalt drill bits. Hand tap set (metric coarse and fine, imperial UNC/UNF) — taps range. Helicoil kit in common thread sizes (M6, M8, M10, M12) — thread inserts. Anti-seize: Loctite C5-A (copper) for general; Loctite Nickel for stainless and high-temp. Cutting fluid (Tap Magic or similar) for drilling and tapping. PPE: safety glasses to AS/NZS 1337.1, face shield, nitrile gloves, cold-resistant gloves for freeze spray. AIMS' Note on Stuck Fastener Safety Eye protection always. Snapped bolts and shattering chrome sockets fly at face height. Safety glasses to AS/NZS 1337.1 minimum; a full face shield for impact work near the face. Brace the work-piece — bolts under high torque release suddenly. A knuckle into a sharp edge is a typical injury. Controlled escalation — don't jump straight to the drill press. The ladder above is in order for a reason. Each step costs more time to recover from if it goes wrong. Fire safety with heat — extinguisher within arm's reach, rags away from the torch, fuel and brake fluid identified before lighting up. Anti-seize gloves — copper-based compounds stain and irritate skin. Nitrile or neoprene disposable gloves keep hands clean. Impact sockets only on impact tools. Worth repeating. Chrome shrapnel under impact loading is a hospital trip. FAQ What is the best penetrating oil for stuck bolts? CRC 5-56 is AIMS' best-selling general-purpose penetrant and works on the vast majority of seized fasteners. For heavy industrial corrosion, PB B'laster and Plus Gas are respected specialist options. For cold-shock release where heat isn't safe, Loctite LB 8040 Freeze & Release combines a penetrant with chilling chemistry. How long should I leave penetrating oil to soak? Light surface rust: 5–15 minutes. Moderate corrosion: 1–2 hours. Severe seized bolts: 24 hours with multiple applications and tapping cycles. Most "the penetrant didn't work" cases are actually "the penetrant wasn't given long enough". Should I heat the bolt or the nut? The nut. Heating the nut expands it faster than it heats the bolt, breaking the rust bond. Heating the bolt while the nut stays cool tightens the seize. If only the bolt is accessible (e.g. a stud in a casting), heat-then-cool cycles still help by expanding and contracting the bolt against the parent threads. Can I use WD-40 to free a stuck bolt? WD-40 is a water displacer with light lubricating oil — it isn't optimised for capillary penetration into rusted threads. A dedicated penetrant such as CRC 5-56, PB B'laster, or Plus Gas will outperform it on seized fasteners. WD-40 is fine for general lubrication and corrosion protection, but it's not the right tool here. Why do my bolts always seize on stainless steel work? Galling. Stainless oxide layers cold-weld together under load, especially at high torque or under vibration. Always use a stainless-rated anti-seize (Loctite Nickel is the workshop standard) and never run stainless fasteners with a powered driver — hand-tightening at moderate speed prevents galling. What's the difference between impact sockets and regular sockets? Regular (chrome vanadium) sockets are heat-treated for steady torque from a hand spanner or ratchet. Impact sockets (typically matte black or oxide finish, marked "Impact" or "IMP") are heat-treated tougher to absorb the cyclic shock from impact wrenches. Using a chrome socket on an impact wrench can shatter the socket, sending steel fragments at face level. The colour rule isn't universal — check the marking. The bolt head has rounded off — what now? Try a slightly undersize imperial socket first; the corners often re-engage. If that fails, hammer a Torx bit one size larger than the original socket into the recess. If both fail, switch to an external bolt extractor socket (grip-style with internal spirals). Last resort: drill the head off, deal with the remaining stud separately. How do I remove a bolt that's snapped flush with the surface? Centre-punch dead-centre, pilot drill, then either internal extractor or weld-nut-on. For high-value assemblies, professional EDM removal is sometimes faster than risking the parent threads. Don't try to chisel or grind — both will damage the parent material around the bolt. What does Loctite breakdown look like with heat? Blue Loctite 243 softens at approximately 250°C and the bolt will come free with a hand spanner. Red Loctite 271 needs 250–300°C — usually a heat gun won't get there; you'll need a small torch. The fastener gives off a slight smell as the adhesive degrades; that's the cue to try the spanner. Can a thread insert make a hole stronger than the original? Yes. Helicoil wire inserts in aluminium often produce a stronger thread than the original parent threads because the stainless coil distributes load across more parent material than the original cut threads. Used routinely in alloy engine work and high-cycle aerospace assembly. I drilled the bolt off-centre and damaged the threads — is the part ruined? Not necessarily. If the damage is one or two thread peaks, a thread chase or recutting tap may clean it up. If half the thread profile is gone, an oversize insert (Helicoil or Time-Sert) restores nominal size. If the parent material is cracked or completely opened up, then yes — that's a replacement part. How do I prevent bolts seizing on outdoor equipment? Anti-seize on every threaded joint exposed to weather. Galvanised or stainless hardware where the budget allows. Wash salt-water and road salt off promptly. Cover threaded joints (e.g. with grease-impregnated tape) where serviceability matters. Is it ever safe to use a cheater pipe over a ratchet handle? No — ratchets have a defined torque ceiling and over-leveraging blows the internal pawls (sudden release = injury). Use a breaker bar instead; they're solid steel with no internal mechanism and designed exactly for this. AIMS stocks breaker bars in 1/2" and 3/4" drive within the ratchets and sockets range. When should I just cut and replace versus persisting with extraction? If 30+ minutes of penetrant, heat, impact and leverage hasn't moved a fastener that you can replace cheaply, switch strategy. Persistence costs labour hours; a new bolt is minutes of work. Save extractor and drill-out time for fasteners where the parent material is high-value and the bolt simply has to come out cleanly. Does freeze release spray work better than heat? Each works on a different principle. Heat expands the nut to break the rust bond; freeze release shrinks the bolt while penetrant migrates into the freshly-opened gap. Freeze is the better option near fuel systems, brake lines, polymer parts, painted panels, or sealed grease bearings — anywhere heat creates a hazard. Heat usually has the edge on long-term, heavily-corroded fasteners where you need to convince a thick rust scale to release. Need a specific product or unsure which step to start with for an awkward job? Call AIMS on (02) 9773 0122 or email marketing@aimsindustrial.com.au. Our team has the experience to point you at the right penetrant, extractor set, or impact tool for the job at hand. For the full AIMS welding fume capture range, browse our fume extractors collection. Need long drill bits? Browse the AIMS range at long drill bits.
Read more
