AAP Nyglass Camlock Type B, 1"

This AAP nyglass camlock coupler is a Type B: a female camlock end and a male BSP thread. It is supplied in 6 sizes from 3/4" (20mm) to 3" (80mm). Camlocks, also known as cam and groove fittings, give a quick connection and disconnection of hose and piping. The female camlock end locks onto a male camlock end of the same size, and the male BSP thread screws into a female threaded port.

It is nyglass (yellow), a 30% glass-filled nylon offered as an alternative to polypropylene for agricultural spraying equipment and the chemical industry. The camlocks are made to interchange with products made to Mil Spec A-A 59326. The threads are cut to ISO 228.

Where this product is used

• Agricultural spraying equipment
• Chemical transfer hose connections
• Irrigation and farm water hose lines
• Hose distributor and general industry connections

Features

• 6 sizes from 3/4" (20mm) to 3" (80mm)
• Type B: Female Camlock x Male BSP
• Nyglass, 30% glass-filled nylon
• Working pressure 517 kPa (5.17 bar) to 862 kPa (8.62 bar) by size
• Interchanges with Mil Spec A-A 59326 products
• Maximum temperature 100°C with an NBR (Buna) gasket

Key specifications

Choosing the right option

Choose the size to match the hose or pipe thread you are connecting, and pair it with a male camlock of the same size (Types A, E or F). Check the mating thread is BSP, because these threads are cut to ISO 228. It suits water, oil, powders and some hydrocarbons and chemicals, so check chemical compatibility before use. Spare parts for these camlocks: brass handles (code CBH), handle pins (code CP) and NBR gaskets (code CGN).
