150 mm Gate Valve Stem Extension | VRSSE150
Available
This AAP stem extension fits AAP resilient seat gate valves. It is supplied in 3 lengths: 150 mm, 300 mm and 375 mm.
A stem extension carries the valve operator up from a buried valve to a convenient height, so the valve can be worked from ground level. AAP lists the extension with a length and an approximate weight and does not state the material or the size of valve each length suits, so check the fit against your valve before you order.
Where this product is used
- Operating buried resilient seat gate valves from ground level
- Valve pits and chambers where the operating nut is deep
- Fitting out water main isolation valves
Features
- 3 lengths: 150 mm, 300 mm and 375 mm
- For AAP resilient seat gate valves
- Raises the operating point of a buried valve
Key specifications
| Specification | Detail |
|---|---|
| Brand | AAP |
| Product | Stem extension for resilient seat gate valves |
| Sizes | 3 lengths: 150 mm, 300 mm and 375 mm |
Options and part numbers
| Size | Part number | Length (mm) | Weight (kg) |
|---|---|---|---|
| 150 mm | VRSSE150 | 150 | 2.5 |
| 300 mm | VRSSE300 | 300 | 3.7 |
| 375 mm | VRSSE375 | 375 | 4.2 |
Selecting the right option
Choose the length to reach from the valve stem to the operating point. Check the fit against your valve with AIMS, because AAP does not state which valve sizes each length suits.
Related products
See also AAP Operating Key for Resilient Seat Gate Valves, AAP Anticlockwise Handle for Resilient Seat Gate Valves, AAP Resilient Seat Gate Valve, Clockwise, Spindle Cap, Table C and AAP Resilient Seat Gate Valve, Anticlockwise, Spindle Cap, Table C.
