25 mm Storz x 25 mm BSP Male Adaptor | SA25M

This AAP Storz BSP male adaptor is a forged aluminium fitting. It is supplied in 5 sizes, 25 mm Storz x 25 mm to 65 mm Storz x 65 mm.

A Storz coupling is a quick connect hose coupling in which both halves are the same, so there is no male and female half. Two couplings join by pushing together and twisting. This adaptor puts a Storz coupling on a male (external) BSP thread, so it screws into a female threaded port. Sizes are the Storz size first, then the thread size.

AAP lists its Storz fittings as forged aluminium, 1600 kPa, ISO 228 threads and NBR, for suction and delivery use (manufacturer-stated). AAP does not say whether 1600 kPa is a working pressure or a test pressure, and does not say which part is NBR, so confirm the pressure, temperature and fluid for your application with AIMS before you order.

Where this product is used

• Fitting a Storz coupling to a female BSP threaded port
• Water transfer and delivery connections with Storz hose
• Suction and delivery lines within AAP's stated rating

Features

• Forged aluminium (manufacturer-stated)
• 5 sizes, 25 mm Storz x 25 mm to 65 mm Storz x 65 mm
• 1600 kPa listed by AAP (manufacturer-stated)
• Suction and delivery duty (manufacturer-stated)

Key specifications

Options and part numbers

Outside diameter, length and weight are the figures AIMS holds for each size; the AAP flyer does not list dimensions, so AIMS is confirming them with AAP. Weights are in grams.

Selecting the right option

Choose the Storz size to match the hose coupling, then the thread size to match your port. The thread size is listed by AAP in millimetres. It corresponds to 1 in BSP for 25 mm, 1-1/2 in for 38 mm, 2 in for 50 mm and 2-1/2 in for 65 mm. ISO 228 is a parallel (non-taper) thread, so the joint is normally sealed with a washer or seal rather than on the thread. AAP does not say whether one is supplied, so confirm this with AIMS before you order. AAP also lists this adaptor as 25 x 20 mm (SA2520M), 75 x 65 mm (SA7565M), 75 x 75 mm (SA75M), 100 x 100 mm (SA100M) and 150 x 150 mm (SA150M), and 65 x 65 mm in NSW FBT and QLD FBT versions (SA65M-NSWFBT, SA65M-QLDFBT), which AIMS does not currently list. Ask if you need one.
