Alemlube Underground Diaphragm Pump | AIMS Industrial

***Special Order. Contact AIMS for further assistance***

Alemlube Automatic Nozzle Diesel Drum Pump

• Manufactured in the US
• GPI heavy duty diesel pump kit w/ manual nozzle & 3.7m x 3/4" diesel hose
• Nozzle can be padlocked
• Up to 56LPM free flow
• Duty Cycle: 30 minutes on, 30 minutes off
• Self priming, direct drive gear pump w/ piston type bypass valve
• Outlet / Inlet: 3/4" nptf / 1" nptf
• Weight: 10.5kg
• Cables: 4.6m of 12 gauge
• Telescopic adjustable suction tube 58-102cm long
• Suction Lift: 1.7m minimum; Discharge Lift: 5.9m minimum; Total Lift: 7.6m
• Temperature: -29 to +52c
• Current Draw: 18 amp
• Motor: 1900 RPM Permanent Magnet
• Motor Protection: 20 amps
• Convenient spin collar for easy installation
