Austlift Eye Nut DIN582 Zinc Plated M6
Available
Used across wire rope and chain tensioning, lifting eye attachments, structural and marine rigging, and crane accessory attachment. The Austlift rigging screw, turnbuckle and eye bolt range delivers standard end configurations (jaw-jaw, eye-eye, jaw-eye, hook-hook) and finishes (galvanised, stainless). Engineering-grade construction and standard sizing suit common rigging assemblies. Designed for safe tensioning and load attachment in trade and industrial service. This page covers the Austlift Eye Nut DIN582 Zinc Plated, available in 13 size (mm) options: M6, M8, M10, M12, M16, M20, M22, M24 and 5 more.
Where this product is used
- Eye nut lifting attachment on machinery covers and equipment using existing bolt holes.
- Gearbox, motor, and pump assembly lifting using eye nut hardware.
- Plant maintenance and overhaul lifting with eye nut attachment.
- Structural lifting attachment using eye nuts on bolted connections.
- Bridge, civil, and structural maintenance lifting eye nut use.
- Precast and structural element crane attachment using eye nuts.
Key specifications
| Product Type | Rigging Hardware |
| Standard(s) | DIN 582 |
Working Load Limit by size
| Size / Variant | WLL (t) |
|---|---|
| M6 | 0.07 |
| M8 | 0.14 |
| M10 | 0.23 |
| M12 | 0.34 |
| M16 | 0.7 |
| M20 | 1.2 |
| M22 | 1.5 |
| M24 | 1.8 |
| M27 | 2.5 |
| M30 | 3.6 |
| M36 | 5.1 |
| M42 | 7 |
| M48 | 8.6 |
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Austlift Eye Nut DIN582 Zinc Plated: M6
SKU: A0168861 | Model: 602006
Size (mm) M6. Austlift Eye Nut DIN582 Zinc Plated
Eye Nut DIN 582 is generally used as a removable lifting point where a rated nut can be utilised. Also can be used as a termination for the chain, wire rope, and other assemblies where required. Made from C15 carbon steel with zinc plated finish, manufactured with a standard larger eye. Only available in metric thread sizes. Conforms to DIN 582, marked with working load limit in tonne, nominal size in millimetre, quality grade, batch numbered, and supplier identification. Proof tested to 2 x working load limit and minimum breaking force of 6 x working load limit. Test certificates are available upon request.
