Schnorr preload disc K-spring washer, Size 9.8 / 6.2 / 0.2mm

A preload washer is a spring washer fitted beside a bearing ring to apply a light axial load and take up axial play.

The Schnorr K-spring washer can be used in singles or multiples, depending on the design. The item names call these preload disc K-spring washers. Size (mm), Internal Diameter Di (mm) and Thickness T (mm) are the option names, and the item names print the same three figures together dimensions, for example 9.8 x 6.2 x 0.2mm. Items are supplied as packs of 2 to 100. Schnorr makes safety washers and disc springs for the automotive or aerospace industry and machine construction.

Where this product is used

• Taking up axial play beside a bearing ring
• Setting a light axial preload on a bearing
• Used in singles or multiples, depending on the design

Features

• 51 items: size 9.8 to 248mm
• Internal diameter Di and thickness T shown for every item
• Plain finish
• Supplied as packs of 2 to 100
• Schnorr makes safety washers and disc springs

Key specifications

Choosing the right option

Choose by internal diameter Di first: it has to suit the bolt or shaft the washer sits on. Then match size (mm) and thickness T to the space you have and the spring force you need. Stacking disc springs in series adds deflection and stacking them in parallel adds force. Check the internal diameter Di against the shaft or housing you are fitting it to.
