Bordo 1/2" HSS Bright Jobber Drill Bit - 2006 Series
Available
The Bordo HSS Bright Jobber Drill Bit - 2006 Series is part of Bordo's Australian range of jobber drill bits, built for reliable performance in trade and industrial applications.
Key Specifications
| Diameter in (mm) | 12.7 |
|---|---|
| Diameter (inch) | 1/2 |
| Spindle Speed Free Cutting Stl RPM | 1078 |
| Flute Type | 30° Helix |
| Flute Length (mm) | 114 |
| Overall Length (OAL) mm | 152 |
| Feed per Revolution (mm) | 0.25 |
| Spindle Speed Aluminium/Brass RPM | 1530 |
| Spindle Speed Stainless Steel RPM | 301 |
| Spindle Speed Wood/Plastic RPM | 2282 |
| Spindle Speed Malleable Iron RPM | 677 |
| Spindle Speed Med. Carbon Steel RPM | 752 |
| Spindle Speed Cast Iron RPM | 602 |
| Spindle Speed Tool Steel RPM | 451 |
| Type of Point | 118° Split Point |
Product Features
- ANSI B94-11
- Bordo Fractional Quick Silver M2-HSS Twist Drills
- Bright Finish Twist Drills have no surface treatment and are supplied in the as-ground condition
Resources
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Bordo HSS Bright Jobber Drill Bit - 2006 Series: 1/2
SKU: A0200647 | Model: 2006-1/2S
Diameter (inch) 1/2. Bordo HSS Bright Jobber Drill Bit - 2006 Series
Bordo Fractional Quick Silver M2-HSS Twist Drills.
ANSI B94-11
118° Split Point (crankshaft point).
Split point is self centering and reduces the need for end thrust. Friction at workpiece is reduced.
118° point angles are ideal for use in materials such as mild steel and cast iron.
The 118° point creates easily controlled chips which are wide and thin.
Bright Finish Twist Drills have no surface treatment and are supplied in the as-ground condition.
These tools are suitable for general purpose use, particularly for non-ferrous applications.
About 118° Split Point
118° Split Point (crankshaft point) Split point is self centering and reduces the need for end thrust. Friction at workpiece is reduced.
118° point angles are ideal for use in materials such as mild steel and cast iron.
The 118° point creates easily controlled chips which are wide and thin.
