Bordo 3mm M2 HSS Bright Finish Extra Long Jobber Drill Bit
Available
The Bordo M2 HSS Bright Finish Extra Long Jobber Drill Bit is part of Bordo's Australian range of jobber drill bits, built for reliable performance in trade and industrial applications.
Key Specifications
| Diameter (mm) | 3 |
|---|---|
| Spindle Speed Free Cutting Stl RPM | 4565 |
| Flute Type | 30° Helix |
| Flute Length (inch) | 250 |
| Overall Length (OAL) mm | 315 |
| Feed per Revolution (mm) | 0.08 |
| Spindle Speed Aluminium/Brass RPM | 6476 |
| Spindle Speed Stainless Steel RPM | 1274 |
| Spindle Speed Wood/Plastic RPM | 9661 |
| Spindle Speed Malleable Iron RPM | 2867 |
| Spindle Speed Med. Carbon Steel RPM | 3185 |
| Spindle Speed Cast Iron RPM | 2548 |
| Spindle Speed Tool Steel RPM | 1911 |
| Type of Point | 135° Split Point |
Product Features
- HSS Extra Long Twist Drill
Resources
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Bordo M2 HSS Bright Finish Extra Long Jobber Drill Bit: 3
SKU: A0199132 | Model: 2504-3.00
This is the 3mm diameter option of the Bordo M2 HSS Bright Finish Extra Long Jobber Drill Bit. Key details for this option: flute type 30° Helix, type of point 135° Split Point.
Bordo HSS Bright Finish Extra Long Jobber Drill Bit
HSS Bright Finish Extra Long Twist Drill.
HSS Extra Long Twist Drill.
135° Split Point (crankshaft point).
Split point is self centering and the short distance from the drill axis to the outer corners results in faster penetration, reducing the need for end thrust.
Bright Finish Twist Drills have no surface treatment and are supplied in the as-ground condition.
These tools are suitable for general purpose use, particularly for non-ferrous applications.
About 135° Split Point (crankshaft point)
Split point is self centering and the short distance from the drill axis to the outer corners results in faster penetration, reducing the need for end thrust.
The 135° point should be used to cut harder steel materials especially in deep hole applications.
In these situations it will produce thicker chips minimising work hardening of the cavity.
Faster penetration reduces abrasion and friction along the cutting edges.
