Bordo No.1 Screw Extractor and Left Hand Stub Drill
Available
The Bordo Screw Extractor and Left Hand Stub Drill is part of Bordo's Australian range of hand tools, built for reliable performance in trade and industrial applications.
Key Specifications
| Size Number | 1 |
|---|---|
| For Bolt (mm) | 4 - 4.5 |
| Pilot Drill (inch) | 5/64 |
| Pilot Drill (mm) | 2 |
| For Bolt (inch) | 5/32 - 3/16 |
Product Features
- Chrome alloy spiral screw extractor
Resources
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Bordo Screw Extractor and Left Hand Stub Drill: 1
SKU: A0159765 | Model: 9900-1W
Size Number 1. Bordo Screw Extractor and Left Hand Stub Drill
Screw Extractor and Left Hand Stub Drill.
About Bordo Chrome Alloy Screw Extractor with Premium HSS-Co5 (Cobalt) Left-Hand Drill
Spiral flute screw extractors are ideally suited for removing broken bolts, studs & socket screws from medium to hard metals.
Typically the required screw extractor will be approx.
2/3 the diameter of the fixing you are extracting.
Guidelines For Use
Use a centre punch to mark the centre of the fixing before drilling to prevent the drill bit from wandering.
Select a drill bit that is suitable for drilling into the specific material - typically HSS or HSS-Co5.
Ideally, the drill should be "Left Hand" which will prevent further tightening of the fixing during drilling.
When using left-hand drills ensure the drill is set to reverse.
Drill pilot hole in the centre of broken bolt, screw or stud.
Lightly tap screw extractor into the hole and turn anti-clockwise with a tap wrench or spanner.
A damaged bolt, screw or stud will unwind out of the hole.
Avoid excessive lateral loads - breakage could result.
Wear eye and hearing protection.
