Bordo Screw Extractor - Clam Chrome Alloy: 1

SKU: A0159760 | Model: 9900-1S

Size Number 1. Bordo Screw Extractor - Clam Chrome Alloy

Screw Extractor - Clam.

About Bordo Chrome Alloy Screw Extractor

Spiral flute screw extractors are ideally suited for removing broken bolts, studs & socket screws from medium to hard metals.

Typically the required screw extractor will be approximately

2/3 the diameter of the fixing you are extracting.

Guidelines For Use

Use a centre punch to mark the centre of the fixing before drilling to prevent the drill bit from wandering.

Select a drill bit that is suitable for drilling into the specific material - typically HSS or HSS-Co5.

Ideally, the drill should be "Left Hand" which will prevent further tightening of the fixing during drilling.

When using left-hand drills ensure the drill is set to reverse.

Drill pilot hole in centre of broken bolt, screw or stud.

Lightly tap screw extractor into the hole and turn anti-clockwise with a tap wrench or spanner.

A damaged bolt, screw or stud will unwind out of the hole.

Avoid excessive lateral loads - breakage could result.

Wear eye and hearing protection.
