Bossweld bernard Style Steel Liner 400/500, 0.9 - 1.2mm

Bossweld Bernard Style Steel Liner 400/500, 4.6 m fit Bernard 400/500 style MIG torches. Two bore ranges are available, 0.9 to 1.2mm and 1.2 to 1.6mm, both in a 4.6 m length for mild steel and stainless steel wire.

The liner guides the welding wire from the drive rollers to the contact tip. A clean liner of the right bore feeds wire smoothly, while a worn, dirty or wrongly sized liner causes erratic feeding, bird-nesting and burn-back. Steel liners suit steel and stainless steel wire.

Where this product is used

• MIG welding with mild steel and stainless steel wire
• Replacing a worn, kinked or dirty liner that is causing feed problems
• Fitting a liner of a different bore or length to suit a change of wire

Features

• Steel liner for Bernard 400/500 style MIG torches
• Wire sizes: 0.9 to 1.2mm and 1.2 to 1.6mm
• Length: 4.6 m
• Product type: Torch Liner

Key specifications

Choosing the right option

Pick the liner to match your wire: the bore range has to include your wire diameter, and the material has to suit the wire (steel for steel and stainless, Teflon for aluminium and soft wires). Check the length against your torch cable, and cut the liner square and deburr the end when you fit it. Replace the liner whenever feeding becomes erratic, and change it along with the contact tip if you have been burning back.

Matching parts for the same torch style: Bossweld Bernard Style Contact Tip 0.9mm (Pack of 10), Bossweld Bernard Style Conical Insulated Gas Nozzle 13mm, 200/300 (Pack of 2), Bossweld Bernard Style Gas Diffuser 300 Amp (Pack of 2), Bossweld Bernard Style Insulator, 200/300 and 400/500 (Pack of 2).
