Bumax Hex Set Screw, 20mm

The Bumax hex set screw is a hex head screw with a metric thread, fitted into a tapped hole or through a clearance hole with a nut. There are 6 items in M6, in lengths of 14 to 35mm.

ISO 4017 is named for this product. The pitch shown for each size is the coarse pitch from the thread table. Every item is supplied as a single item. The size choice in the variant selector for this product is the length in mm; the thread diameter (M6) is shown in each item name and in the specifications.

Where this product is used

• Fitted into a tapped hole, or through a clearance hole with a nut and washer, to clamp parts together
• Replacing a hex head screw of the same thread form, diameter, pitch and length
• Equipment and fabrication work where a hex head screw is called for

Features

• 6 items: M6, lengths 14 to 35mm
• Metric thread, pitch shown for each size
• Stainless steel, high tensile, grade 10.9
• Hex head
• ISO 4017 named for this product
• Supplied as a single item

Key specifications

Choosing the right option

Choose the thread form first: the screw and the nut or tapped hole must match in thread form, diameter and pitch. Metric sizes are the nominal diameter in millimetres; compare the pitch with your nut or tapped hole. Length is measured from under the head to the end of the screw. All items carry the same grade. For the other grade see Bumax Hex Set Screw, High Tensile Stainless Steel, Grade 8.8, M4 to M36, 6 to 160mm long.
