Dixon Brass lever nozzle
Available
This Dixon nozzle is a brass and stainless steel ball valve with a lever handle and a 20mm (3/4") hose tail inlet, used for washdown work. It is rated at 232 PSI (16 bar) with an operating temperature of -10 to 110°C, and lists it for washdown in mining, construction, industrial and process industries.
Where this product is used
- Washdown in mining, construction, industrial and process industries
- Hose-end shut-off on 20mm (3/4") washdown hose
Features
- Lever tap operation
- Brass and stainless steel construction
- Inlet: 20mm (3/4") hose tail
- Working pressure: 232 PSI (16 bar)
- Operating temperature: -10 to 110°C
Key specifications
| Specification | Detail |
|---|---|
| Brand | Dixon |
| Dixon part number | FFS-HRN-BALL |
| Construction | Brass and stainless steel |
| Operation | Lever tap |
| Inlet | 20mm (3/4") hose tail |
| Working pressure | 232 PSI (16 bar) |
| Operating temperature | -10 to 110°C |
Choosing the right option
Match the hose tail to your hose: this nozzle takes 20mm (3/4") hose. Use a suitable hose clamp or crimp fitting on the tail, and check the hose pressure and temperature rating is at least equal to the figures above.
Related Dixon products: Dixon General Purpose Brass Ball Valve With Stainless Steel Handle and Dixon Brass Mini Ball Valve Female BSP x Female BSP.
