Dixon GKCH150V 1-1/2" hose ID Crimp Cup Seal FKM
Out of stock
This Dixon crimp cup seal is made from FKM (fluoroelastomer). Dixon lists it in the Composite Hose & Fittings section, next to the scroll tail crimp stems and crimp ferrules, in five sizes for hose from 1-1/2" (GKCH150V, 40 mm) to 4" (GKCH400V, 100 mm) (manufacturer-stated).
The same cup seal is also listed in nitrile Buna, as GKCH150NBR to GKCH800NBR for 40 to 200 mm (up to 8"). Dixon's catalogue gives no pressure or temperature rating for the seal, so choose the material for your media and confirm any limits with us.
Where this product is used
- Crimped composite hose assemblies, as listed with Dixon's scroll tail crimp stems and crimp ferrules (manufacturer-stated).
- Hose assemblies where the media calls for an FKM seal; check the compatibility for your media.
Features
- FKM crimp cup seal (manufacturer-stated)
- Five sizes from 1-1/2" to 4" hose ID (40 to 100 mm) (manufacturer-stated)
- Listed with the scroll tail crimp stems and crimp ferrules (manufacturer-stated)
Common specifications
| Specification | Detail |
|---|---|
| Material | FKM |
| Sizes | 1-1/2" to 4" hose ID (40 to 100 mm) |
| Nitrile Buna version | GKCH150NBR to GKCH800NBR |
Key specifications
| Dixon part number | Hose ID | Catalogue size (mm) |
|---|---|---|
| GKCH150V | 1-1/2" | 40 |
| GKCH200V | 2" | 50 |
| GKCH250V | 2-1/2" | 65 |
| GKCH300V | 3" | 80 |
| GKCH400V | 4" | 100 |
Selecting the right option
Choose the seal by hose ID and then by seal material for your media. FKM is listed only up to 4"; for 6" and 8" Dixon lists the nitrile Buna seal (linked below).
Related products
Related Dixon products: Dixon Crimp Cup Seal Buna N and Dixon Aluminium Scroll Tail Camlock Type C Coupler x Hose Shank W/ Ferrule.
