Dixon Nitrile gasket for roll grooved couplings, 3" (80 NB)
Available
This Dixon nitrile (Buna) gasket fits roll grooved couplings. The nitrile rubber gasket is suited to petroleum products, vegetable oils, mineral oils and air contaminated with petroleum oils, with a temperature range of -31 to 80°C. It is not for use with hot water.
Where this product is used
- Roll grooved coupling gaskets for petroleum products, vegetable oils, mineral oils and air contaminated with petroleum oils
- Replacement gasket for Dixon roll grooved couplings in the matching pipe size
Features
- Material: nitrile rubber (Buna)
- For petroleum products, vegetable oils, mineral oils and air contaminated with petroleum oils
- Temperature range: -31 to 80°C
- Not for use with hot water
- Pipe outside diameter for each size
Key specifications
| Specification | Detail |
|---|---|
| Brand | Dixon |
| Material | Nitrile rubber (Buna) |
| Temperature range | -31 to 80°C |
| Not suited to | Hot water |
| Sizes | 1-1/2" (40 NB), 2" (50 NB), 2-1/2" (65 NB), 3" (80 NB), 4" (100 NB), 6" (150 NB) |
Choosing the right option
Use a gasket lubricant made for rubber gaskets: incorrect lubricants such as grease can shorten gasket life and stop the gasket seating correctly.
Related Dixon products: Dixon EPDM Gasket For Roll Grooved Coupling, Dixon Gasket Lube For All Rubber Gasket Roll Grooved Coupling - 500g and Dixon Roll Grooved Rigid Coupling - Galvanised.
| Option | Part number | SKU |
|---|---|---|
| 1-1/2 | GAS-RG-N40 | A0070223 |
| 2 | GAS-RG-N50 | A0070224 |
| 2-1/2 | GAS-RG-N65 | A0070225 |
| 3 | GAS-RG-N80 | A0070226 |
| 4 | GAS-RG-N100 | A0070221 |
| 6 | GAS-RG-N150 | A0070222 |
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Dixon Nitrile Gasket For Roll Grooved Coupling: 3
SKU: A0070226 | Model: GAS-RG-N80
Dixon GAS-RG-N80: Nitrile gasket for roll grooved couplings, 3" (80 NB).
