Euroboor MT3 Arbor to 19.05mm (3/4") Weldon with Lubrication Ring
Available
The Euroboor IMC.3019-N is a Morse taper arbor with an MT3 taper as the outside connection and a 19.05mm (3/4") Weldon connection inside, including a lubrication ring. It under the order code IMC.30/19-N.
It is an arbor with a Morse taper MT3 and a Weldon 19.05mm connection, including a lubrication ring, for drilling, countersinking and tapping. Pick the arbor with the Morse taper that fits your drilling machine spindle.
Where this product is used
- Mounting Weldon shank annular cutters in a drilling machine with an MT3 spindle
- Mounting Weldon shank twist drills in an MT3 spindle
Features
- MT3 Morse taper as the outside connection
- Inside connection: 19.05mm (3/4") Weldon
- Includes a lubrication ring
- Part of the part number IMC.30/19-N
Key specifications
| Specification | Detail |
|---|---|
| Brand | Euroboor |
| Outside connection | MT3 Morse taper |
| Inside connection | 19.05mm (3/4") Weldon |
| Lubrication ring | Included |
| Application | Drilling, countersinking and tapping |
| Order code | IMC.30/19-N |
Choosing the right option
Match the taper to the spindle of your drilling machine: this is the MT3 arbor, and the MT2 arbor has an MT2 taper. The inside 19.05mm (3/4") Weldon connection takes Weldon shank tools, for example the Euroboor TCT 55mm depth of cut cutters and Weldon shank twist drills.
See also: Euroboor MT2 arbor with lubrication ring, Euroboor HSS 30mm depth of cut cutters, Nitto One Touch adaptor.
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Euroboor MT3 Arbor to 19.05mm (3/4") Weldon with Lubrication Ring
SKU: A0147229 | Model: IMC.3019-N
Euroboor A0147229 is a MT3 arbor. Taper (outside connection): MT3 Morse taper. Cutter connection (inside): 3/4" Weldon.
