Gates NP-10-IDLR-BRACKET (7720-1011) Idler Bracket

This Gates idler bracket is a precision drive component for maintaining correct belt tension and wrap angle in Gates belt drive systems. Using genuine Gates idler components ensures the drive geometry matches the published Gates drive design, maintaining belt life and power transmission efficiency.

Where this product is used

Gates idler brackets provide secure mounting for idler pulleys in enclosed and open belt drive systems. Common applications include:

• Belt drive systems requiring a fixed or adjustable idler mounting point for correct belt wrap
• Gates Draftguard and enclosed belt drive assemblies where idler positioning is critical to performance
• Custom and retrofit drive configurations where OE mounting provisions are not available

Key specifications

Selecting the right option

Select the idler bracket by the Gates drive series and idler size it is designed to support. NP-10, 10-IDL and 20-IDL designations indicate the drive series — confirm compatibility with your Gates drive assembly before ordering. Contact AIMS for assistance matching idler brackets to your existing Gates drive configuration.
