Descriptions

• Due to its double and directly opposite teeth, Twin Power® synchronous belts ensure high loading capacity on contra-rotating drives and ensure smooth running and high flexibility
• Gates Twin Power® GT2 belt has at least twice the offer rating of Gates Twin Power® HTD® belts. It is characterised by extraordinary load-carrying offer and high tooth jump resistance, thus ensuring a positive non-slip drive. In addition, it runs at very low noise.

Construction

• Notch depth is in proportion to the cross-section to ensure perfect stability
• GT® (Gates Tooth) modified curvilinear tooth profile
• Neoprene body provide protection against grime, grease, oil and moisture
• Fibreglass tensile cords
• Tough nylon facing protects and reinfonces the tooth surface.

Advantages

• Twin Power® can transmit up to 100% of its maximum rated load from either side of the belt; alternatively, it can transmit a load on both sides – provided the sum of the loads does not exceed the maximum capacity
• Non-slip positive drive
• Runs at low noise
• Compact, light-weight, and cost e?ective drives
• High tooth jump resistance
• High efficiency positive drive
• Maintenance free
• No lubrication.

Temperature Range

• Range: -30¬∞C to +100¬∞C

Dimensions

• Section: 8MGT
• Pitch Length: 1120 mm
• Pitch: 8 mm
• Belt Width: 330 mm
• T: 3.4 mm
• W: 2 mm
• Teeth: 140
