KCM Self-Lube ASA Connecting Link Simplex 40NL

KCM connecting links join the ends of a length of ASA self-lube simplex roller chain into a continuous loop. Match the link to the KCM chain with the same chain number, strand count and series. Oil-impregnated bushing gives self-lubrication, so no relubrication is needed.

Where this product is used

• Drives where no lubrication is allowed
• Drives where lubricating in the process is difficult
• Hard-to-reach chain drives

Features

• Matched to the KCM chain of the same number and series
• Joins the chain ends into a continuous loop
• Oil-impregnated bushing gives self-lubrication, so no relubrication is needed
• Use chain speeds of 150 m/min or slower
• Operating temperature range -10 to +150°C

Key specifications

Choosing the right option

For ASA chain the number is the pitch in eighths of an inch: 40 is 4/8" (1/2"), 60 is 6/8" (3/4"), 100 is 10/8" (1-1/4"). The figure after the dash is the number of strands.

Choose self-lube chain where lubrication is not required or is hard to carry out. Select it from its chain power transmission table, not by the low-speed selection method. Single strand chain runs on standard sprockets; multiple-strand chain needs an exclusive sprocket.
