KCM AL Series Leaf Chain AL544-AL1266, AL544
Available
Leaf chain from KCM. Leaf chain, also called balance chain, is made of plates and pins and is used for load lifting and balancing (A0067047).
Where this product is used
- Load lifting and balancing
- Counterbalance arrangements with smooth loads
Features
- AL type is KCM leaf chain for light loading
- Used where there is no impact and up to 100 repetitions a day
- Simple construction of plates and pins
- Series: AL Leaf Chain
Key specifications
| Specification | Detail |
|---|---|
| Brand | KCM |
| Product type | Leaf Chain |
| Series | AL Leaf Chain |
| Component | Leaf chain |
| Chain sizes | AL544-AL1266 (7) |
| Pitch | 15.875 to 38.1mm |
| Minimum tensile strength | 54.9 to 423.6 kN |
| Supplied as | 10 ft (3.05 m) box |
Choosing the right option
AL leaf chain suits applications without impact and with daily repetition of 100 times or less. Use the BL type for heavier loading. Use roller chain where chain speed is over 30 m/min or daily repetitions exceed 1000.
Related KCM products: KCM AL Series Leaf Chain Connecting Link AL544-AL1266.
| Option | SKU |
|---|---|
| AL544 | A0067047 |
| AL566 | A0067048 |
| AL644 | A0067049 |
| AL666 | A0067050 |
| AL844 | A0067052 |
| AL866 | A0067053 |
| AL1266 | A0159139 |
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
KCM AL Series Leaf Chain AL544-AL1266, 10 ft Box: AL544
SKU: A0067047 | Model: AL544/KCM
KCM AL544 leaf chain, 5/8" pitch, 54.9 kN minimum tensile strength, 10 ft box.
