Dasqua precision machine level, Size 100mm

Dasqua precision machine levels come in five sizes from 100mm to 300mm, with an accuracy of 0.02mm on every size except one 200mm level at 0.05mm.

They are used to measure the straightness and parallelism of machine tool guideways and other equipment, and to check the horizontal or perpendicular position after equipment is installed. The part number carries the size and the accuracy figure.

Where this product is used

• Measuring straightness and parallelism of the guideways of machine tools and other equipment
• Checking the horizontal or perpendicular position after installing equipment

Features

• Five sizes: 100mm, 150mm, 200mm, 250mm and 300mm
• Accuracy of 0.02mm, or 0.05mm on the PL200x0.05
• Two 200mm levels: PL200x0.02 and PL200x0.05
• Sizes: 100mm, 150mm, 200mm, 250mm and 300mm

Key specifications

Choosing the right option

Choose the size that suits the length of the surface you are checking. The 200mm size comes in two accuracy figures: the PL200x0.02 at 0.02mm and the PL200x0.05 at 0.05mm. Every other size is 0.02mm, so choose the PL200x0.02 if you want the finer figure at 200mm.
