Maxigear Certified Lapped Straight Edge, 1000-2000mm

Maxigear certified carbon steel straight edges are lapped on 4 sides and ungraduated, in lengths from 1000mm (SE1000GR0) to 2000mm (SE2000GR1).

It is a precision straight edge lapped on all 4 square sides, with no size markings, supplied with certification to DIN 874/0 or 874/1. Each part number has its own width and thickness, from 50mm to 80mm wide and 10mm to 15mm thick.

Where this product is used

• Use as a precision straight edge, supplied with certification

Features

• Lapped on all 4 square sides
• Ungraduated, no size markings
• Supplied with certification to DIN 874/0 or 874/1
• Width and thickness given for each part number, from 50 x 10mm to 80 x 15mm

Key specifications

Choosing the right option

Pick the part number by length, width and standard: SE1000GR0 is 1000mm long and 60mm wide, SE1000GR1 is 1000mm long and 50mm wide, SE1500GR1 is 1500mm long and 60mm wide, SE2000GR0 is 2000mm long and 80mm wide and SE2000GR1 is 2000mm long and 70mm wide. Parts ending GR0 are in DIN 874/0 and parts ending GR1 to DIN 874/1. For bevelled straight edges with no certification see the ungraduated carbon steel straight edge.
