Pferd hand file 1112, Bastard Cut / 150mm

The Pferd hand file (series 1112) is a tanged machinist's file with a rectangular section, cut on three sides with one side left uncut. The range has 17 options from 100 to 350mm in bastard (cut 1), second (cut 2) and smooth (cut 3) cuts, all supplied without a handle.

The series are shape A in accordance with DIN 7261, suited to work on rectangular geometries. Suitable materials: aluminium, bronze, copper, brass, zinc, grey cast iron, steels up to 1,200 N/mm² and cast steel. Matching handle by length: FH 3 for 100 and 150mm; FH 4/1 for 200 and 250mm; FH 5/1 for 300 and 350mm. Handles are not included; the ergonomic file handles are sold separately.

Where this product is used

• Coarse stock removal and roughing with cut 1
• Universal roughing and finishing with cut 2
• Precision processing and finishing with cut 3
• Work on rectangular geometries
• Work on aluminium, bronze, copper, brass, zinc, grey cast iron, steels up to 1,200 N/mm² and cast steel

Features

• Tanged design for fitting a file handle
• Uniformly high stock removal rate
• Long tool life
• Lengths 100, 150, 200, 250, 300 and 350mm, each in three cuts
• Matching handle: FH 3 for 100 and 150mm, FH 4/1 for 200 and 250mm, FH 5/1 for 300 and 350mm

Key specifications

Choosing the right option

Cut 1 (bastard) is for coarse stock removal and roughing, cut 2 (second) for universal roughing and finishing and cut 3 (smooth) for precision processing and finishing. A higher cut number is a finer file.

Same series with a fitted handle: Pferd Hand File With Handle.

Separate handles: Pferd Ergonomic File Handles FH 3 to FH 5/1.
