Pferd Universal Shank-Mounted Cup Brush TBU, Steel Wire 0.30 mm, 50 x 15 mm, 6.35 mm Shank (43740003)
Available
The Pferd TBU is a universal shank-mounted crimped cup brush. It has a 6.35mm shank and steel wire filament. Item 43740003 is 50 x 15mm (brush diameter and face width).
Filament diameter is 0.30mm. Optimum speed is 6,500 to 13,000rpm and maximum speed is 13,000rpm. Steel wire: high tensile and bending fatigue strength, temperature resistance up to 300°C.
Where this product is used
- Steel wire is highly suitable for steel and cast iron, and suitable for plastics
Features
- Brush diameter and face width: 50 x 15mm
- 6.35mm shank
- Steel wire (ST), filament diameter 0.30mm
- Optimum speed 6,500 to 13,000rpm, maximum speed 13,000rpm
Key specifications
| Specification | Detail |
|---|---|
| Brand | Pferd |
| Brush diameter (D) | 50mm |
| Face width (WF) | 15mm |
| Shank diameter (DS) | 6.35mm |
| Filament length (LT) | 19mm |
| Filament diameter (DF) | 0.30mm |
| Filament material | Steel wire (ST) |
| Optimum speed | 6,500 to 13,000rpm |
| Maximum speed | 13,000rpm |
Choosing the right option
Match the 6.35mm shank to your chuck or collet. Steel wire is rated not suitable for stainless steel, aluminium or non-ferrous metals. Never exceed the maximum permitted speed marked on the brush or its label.
Other shank-mounted cup brushes: Pferd Shank-Mounted Cup Brush TBU, Steel Wire 0.30mm, 6mm Shank, 50 x 10 and 60 x 15mm, Pferd Shank-Mounted Cup Brush TBU, Stainless Steel Wire 0.30mm, 50 x 10mm - Pack of 10.
Resources
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Pferd Universal Shank-Mounted Cup Brush TBU, Steel Wire 0.30 mm, 50 x 15 mm, 6.35 mm Shank (43740003)
SKU: A0155689 | Model: 43740003
Pferd 43740003: universal Shank-Mounted Cup Brush TBU. Designation: POS TBU 5015/6,35 ST 0,30 Universal. Brush diameter (D): 50mm.
