Seagull Oil Seal Single Lip 1/4 x 5/8 x 3/16"
Available
Seagull single lip oil seal, 1/4 x 5/8 x 3/16 in, model 250-625-187SC. It seals a 1/4 in shaft in a 5/8 in housing bore and is 3/16 in wide.
A rotary shaft seal in Nitrile Rubber (NBR) that keeps lubricant in and contamination out where a shaft leaves a housing.
Where this product is used
- Gearboxes, speed reducers and differentials, sealing input and output shafts
- Electric motors, pumps, compressors and fans where a rotating shaft leaves a housing
- Wheel hubs, axles and drive shafts on vehicles, trailers and agricultural machinery
- Hydraulic pumps and motors, conveyor and idler drives, and general workshop repairs
Features
- Single lip (SC): a compact single sealing lip for clean, lightly contaminated shafts
- Nitrile rubber (NBR) lip that suits mineral oils and greases in general machinery
- Model code 250-625-187SC gives the shaft, bore and width at a glance
Key specifications
| Specification | Detail |
|---|---|
| Brand | Seagull |
| Product type | Rotary shaft oil seal |
| Lip type | Single Lip (SC) |
| Material | Nitrile Rubber (NBR) |
| Shaft diameter (ID) | 1/4 in (6.3 mm) |
| Housing bore (OD) | 5/8 in (15.9 mm) |
| Width | 3/16 in (4.8 mm) |
| Model code | 250-625-187SC |
| SKU | A0124667 |
Selecting the right option
Match the shaft diameter, the housing bore and the width. Go by the shaft and bore rather than the lip of the old seal, as the lip sits slightly smaller than the shaft it seals on. Width is usually the least critical of the three, provided the housing has the depth.
Type SC is the single lip version, suited to cleaner conditions where a second lip is not needed.
For a size not shown, request a quote with the shaft diameter, housing bore and width.
Fitting and use
Fit the seal with the main lip facing the fluid you are keeping in, press it in square using a tool that bears on the outer face of the seal, and avoid hammering directly on the seal.
Lubricate the lip with the system oil or grease before assembly, and cover keyways, splines, threads or sharp shoulders with a sleeve or tape so they cannot cut the lip as it passes over.
Run the seal on a clean, smooth shaft with a lead-in chamfer and no burrs. A shaft finished to ISO h11 is the usual guide for rotary shaft seals.
Related products
See the full Seagull range in Oil Seals & O-Rings.
