Alemlube Automotive Premium 6CCD Commercial Vehicle Wheel Aligner

The Alemlube Automotive Premium 6CCD Commercial Vehicle Wheel Aligner uses 6 CCD sensors with 3-point self-centering wheel clamps to handle the larger wheels found on trucks and commercial vehicles, with infra-red transmission from the measuring heads and Bluetooth between the heads and the mobile compact console.

A 30° fast compensation reading is taken without lifting the vehicle, and the Windows-based software carries a database of over 90,000 vehicle data sheets plus storage for up to 20,000 completed jobs, searchable by record, customer name or vehicle registration.

Where this product is used

• Commercial vehicle wheel alignment in truck and fleet workshops
• Workshops wanting job history and vehicle-spec lookup built into the aligner

Key specifications

• 6 CCD sensor system; 3-point self-centering wheel clamps
• 4 mounted measuring heads; 24" LCD console display
• Infra-red (heads) and Bluetooth (head-to-console) data transmission
• 30° fast compensation without lifting the vehicle
• 90,000+ vehicle data sheet database; stores up to 20,000 jobs
• Full kit: console, display, keyboard, battery charger, printer, measuring heads, clamps, turntables, brake depressor, steering wheel holder
• 18 Month warranty
