ClayTech CLA PITBULL 15 Pitbull 15 High Head Waste Water Pump, 170 L/min
Available
The ClayTech Pitbull 15 is a high-head waste water drainage pump, rated at 550 W (P2) with a maximum flow of 170 L/min and a maximum head of 15 m (manufacturer-stated). It is made for above-ground irrigation from Australian waste water treatment systems (manufacturer-stated).
The data sheet says the pump is designed to operate in the middle of its curve, delivering 80 L/min at 10 m of head, and that it is built for Australian conditions such as voltage fluctuations and waste water (manufacturer-stated). The outlet is 1-1/4 inch.
Where this product is used
- Above-ground irrigation from waste water treatment systems. (manufacturer-stated)
- Pumping waste water where a high head is needed. (manufacturer-stated)
Features
- 15 m maximum head (manufacturer-stated)
- 80 L/min at 10 m head (manufacturer-stated)
- 8 m power cable (manufacturer-stated)
- Compact 150 mm diameter body (manufacturer-stated)
Key specifications
| Specification | Detail |
|---|---|
| Power (P2) | 550 W (manufacturer-stated) |
| Maximum flow | 170 L/min (manufacturer-stated) |
| Maximum head | 15 m (manufacturer-stated) |
| Flow at 10 m head | 80 L/min (manufacturer-stated) |
| Outlet | 1-1/4 inch (manufacturer-stated) |
| Pump diameter | 150 mm (manufacturer-stated) |
| Pump height | 325 mm (manufacturer-stated) |
| Power cable | 8 m (manufacturer-stated) |
| Weight | 5 kg (manufacturer-stated) |
Selecting the right option
Choose the Pitbull 15 where a high head matters more than flow. For more flow at a lower head see the BlueVort 9 drainage pump (200 L/min, 8.5 m head) or the BVP C11 drainage pump (320 L/min, 11 m head).
Related products
Related ClayTech drainage pumps: BlueVort 9 drainage pump, BVP C11 drainage pump, BlueDiver C30 and C40 submersible pumps and ProSub C6 and C9 drainage pumps.
