Dixon FWG-OST-114-88 4" x 4" x 3" (100 x 100 x 80 mm) Roll Grooved Reducing Offset Tee

This Dixon reducing offset tee is a galvanised grooved tee with the outlet set at an angle, so a landing valve can connect directly with an offset instead of straight out of the side. It has a 100 NB run and an 80 NB outlet (manufacturer-stated).

The fitting is 100 x 80 NB (pipe OD 114.3 x 88.9 mm), rated at 500 PSI, with a centre-to-end dimension of 158.4 mm. Dixon compares it with Victaulic No. 30 and gives the model number GT-614. It appears in Dixon's Roll Groove and Shouldered Fittings brochure (manufacturer-stated).

Where this product is used

• Direct connection of a landing valve with an offset angle on a hydrant line, using one fitting (manufacturer-stated).
• Hydrant risers where a straight outlet would foul a wall or other pipework.

Features

• Offset reducing tee with 100 NB run and 80 NB outlet (manufacturer-stated)
• Size: 100 x 80 NB (pipe OD 114.3 x 88.9 mm) (manufacturer-stated)
• Working pressure: 500 PSI (manufacturer-stated)
• Centre-to-end: 158.4 mm (manufacturer-stated)
• Comparable to Victaulic No. 30; model number GT-614 (manufacturer-stated)

Common specifications

Key specifications

Dixon's brochure says a full range of hydrant fabricated fittings is also available and asks customers to contact Dixon for details.

Selecting the right option

Use the offset tee when the landing valve has to sit at an angle to the main. For a straight outlet, use the stack tee or the end run tee listed under Related products. Each end needs a grooved coupling and a gasket suited to the fluid.
