Dixon 25-C68-BR 2-1/2" (65 mm) Brass Camlock 68 Degree Bend Coupler x Hose Tail

This Dixon camlock coupler has its hose tail bent through 68 degrees: Dixon lists it as a 68 degree bend, coupler x hose tail, in brass (manufacturer-stated). The coupler end takes a Type A, E or F adaptor of the same size, and the angled tail turns the hose away from the connection. The store lists 3 sizes, from 2-1/2" (65 mm) to 4" (100 mm).

Dixon lists the brass bend in its main camlock range, in sizes 65, 75 and 100 mm; the 50 mm size is aluminium only (manufacturer-stated).

Dixon rates the sizes in the store at 150 PSI for 65 mm; 125 PSI for 75 mm; 100 PSI for 100 mm (manufacturer-stated). Dixon bases its pressure ratings on mating Dixon fittings at an ambient temperature of 21 degrees C with the standard seal, and asks you to consult Dixon for higher temperatures or other unusual conditions (manufacturer-stated).

Dixon states that camlock couplings are designed for use with liquids and must not be used in compressed air or steam applications (manufacturer-stated).

Where this product is used

• Taking a hose away from a camlock connection at an angle, where a straight hose tail would kink or foul a nearby fitting.
• Quick-connect transfer of liquids such as cooling water, fuels, chemicals, adhesives and dyes (manufacturer-stated).
• Tank, pump and truck connections where the hose has to leave the coupler at an angle.

Features

• Bend 68 degrees, coupler x hose tail (manufacturer-stated)
• Working pressure: 150 PSI for 65 mm; 125 PSI for 75 mm; 100 PSI for 100 mm (manufacturer-stated)
• Material: brass (manufacturer-stated)
• Interchanges with products made to commercial item description A-A-59326D (manufacturer-stated)

Common specifications

Key specifications

Pressure ratings are the figures Dixon prints for each size (manufacturer-stated).

Selecting the right option

Pick the size to match your hose and the adaptor it connects to. The hose tail is bent through 68 degrees, so check the hose has room to turn and that the hose and clamp suit the working pressure. Check your media against the brass body before ordering. The coupler end connects to a Type A, E or F adaptor of the same size.

Related products

Related Dixon products: Dixon Aluminium Cam & Groove 68° Type C Coupler x Hose Shank, Dixon Brass Standard BSP Cam & Groove Type E Adaptor x Hose Shank and Dixon Brass Standard BSP Cam & Groove Type C Coupler x Hose Shank.
