Dixon SS16B1510 1/2" x 3/8" (15 x 10 mm) Reducing Hex Bush M x F 316 SS BSP
Out of stock
This Dixon reducing hex bush has a larger male BSP thread on the outside and a smaller female BSP thread on the inside, so it reduces a female port to a smaller size. It is made from 316 stainless steel (CF8M) with a hex for the spanner. This page lists 16 size combinations, from 3/8" x 1/4" to 4" x 3" (male x female).
Dixon describes its 316 stainless steel BSP fittings as CF8M (316) stainless steel to ASTM A351, Class 150 lbs, with ISO 7-1 pipe threads, rated at 300 PSI (about 21 bar) for low-pressure service that includes chemical and corrosive environments as well as standard air and water (manufacturer-stated). In the size column, the first figure is the male thread and the second is the female thread.
Where this product is used
- Reducing a female port to take a smaller pipe, gauge or instrument in stainless pipework, in chemical, corrosive, air and water service (manufacturer-stated).
- Fitting a smaller branch into a tee or elbow port without a separate reducing fitting.
Features
- Reducing hex bush, male x female BSP (manufacturer-stated)
- End connection: Male x female BSP, reducing (manufacturer-stated)
- Body: CF8M (316 stainless steel) to ASTM A351, Class 150 lbs (manufacturer-stated)
- Working pressure: 300 PSI (about 21 bar), for low-pressure service including chemical and corrosive environments (manufacturer-stated)
- Sizes on this page: 3/8" x 1/4" to 4" x 3" (16 combinations)
Common specifications
| Specification | Detail |
|---|---|
| End connection | Male x female BSP, reducing |
| Body material | CF8M (316 stainless steel), ASTM A351 (manufacturer-stated) |
| Thread standard | ISO 7-1 pipe threads (BSP) (manufacturer-stated) |
| Design | Class 150 lbs; generally in accordance with AS3673 (manufacturer-stated), with slight variations where the manufacturer's dimensions are used |
| Working pressure | 300 PSI (about 21 bar) |
| Application | Low-pressure service, including chemical and corrosive environments, and standard air and water |
Key specifications
| Dixon part number | Male x female thread (inch) | Nominal size (catalogue) | Same size in galvanised malleable iron (catalogue) |
|---|---|---|---|
| SS16B1008 | 3/8" x 1/4" | 10 x 8 mm | FMG-BUS-10-8 |
| SS16B1510 | 1/2" x 3/8" | 15 x 10 mm | FMG-BUS-15-10 |
| SS16B2015 | 3/4" x 1/2" | 20 x 15 mm | FMG-BUS-20-15 |
| SS16B2515 | 1" x 1/2" | 25 x 15 mm | FMG-BUS-25-15 |
| SS16B2520 | 1" x 3/4" | 25 x 20 mm | FMG-BUS-25-20 |
| SS16B3220 | 1-1/4" x 3/4" | 32 x 20 mm | FMG-BUS-32-20 |
| SS16B3225 | 1-1/4" x 1" | 32 x 25 mm | FMG-BUS-32-25 |
| SS16B4025 | 1-1/2" x 1" | 40 x 25 mm | FMG-BUS-40-25 |
| SS16B4032 | 1-1/2" x 1-1/4" | 40 x 32 mm | FMG-BUS-40-32 |
| SS16B5025 | 2" x 1" | 50 x 25 mm | FMG-BUS-50-25 |
| SS16B5032 | 2" x 1-1/4" | 50 x 32 mm | FMG-BUS-50-32 |
| SS16B5040 | 2" x 1-1/2" | 50 x 40 mm | FMG-BUS-50-40 |
| SS16B6550 | 2-1/2" x 2" | 65 x 50 mm | FMG-BUS-65-50 |
| SS16B8050 | 3" x 2" | 80 x 50 mm | FMG-BUS-80-50 |
| SS16B8065 | 3" x 2-1/2" | 80 x 65 mm | FMG-BUS-80-65 |
| SS16B10080 | 4" x 3" | 100 x 80 mm | FMG-BUS-100-80 |
Selecting the right option
Read the size as male x female: 1/2" x 3/8" has a 1/2" male thread that screws into a 1/2" female port, and a 3/8" female thread that takes a 3/8" male fitting. A bush keeps the overall length short; for a longer reduction, use a reducing nipple. BSP threads do not mate with NPT or metric threads, so confirm the thread on every mating part before you order. Dixon also lists 1/2" x 1/4" as SS16B1508, which is sold on a separate ANFO loader spare-part page; ask us if you need it.
Related products
Related Dixon fittings: Dixon Screwed Reducing Hex Bush Male x Female BSP Galvanised Malleable Iron, Dixon Screwed Reducing Hex Nipple BSP 316 Stainless Steel and Dixon Equal Tee BSP Female 316 Stainless Steel.
