14G-10 x 50 mm Bugle Head T17 Batten Screw, 316 Stainless Steel - BBSA414GX50
The price shown is for the box.
Available
The Imperial Bugle Head T17 Batten Screw, 316 Stainless Steel is available in 6 sizes (14G-10) and is a bugle head screw with a Type 17 (T17) point, used to fix timber battens and framing. The bugle head sits flush with the timber surface without crushing the fibres.
The range runs to 6 variants, covering sizes 14G-10 and lengths 50 mm to 150 mm. Pack quantities depend on size: packs of 100 to 250.
A4 (316) stainless steel contains molybdenum (about 2 to 3 per cent), which improves its resistance to chlorides. It is the grade normally chosen for coastal, pool, marine and food-processing settings, and it costs more than A2 (304).
Austenitic stainless steel is generally non-magnetic, although cold-worked parts can show weak magnetism. In wet conditions, keep stainless steel apart from aluminium and galvanised steel with a washer or sleeve, to reduce the risk of galvanic corrosion.
Where this product is used
- Timber-to-timber connections
- Fixing timber battens, roof battens and framing
- Coastal and marine installations
- Outdoor fittings exposed to salt air
- Outdoor and coastal timber construction
- Bulk jobs and trade or maintenance stores buying in larger packs
Features
- Lengths from 50 mm to 150 mm
- Choice of 6 sizes, 14G-10
- A4 (316) stainless steel with molybdenum, for coastal and chloride-exposed settings
- Bugle head sits flush without tearing timber fibres
- T17 cutting point starts in timber
- Pack quantities to suit trade and bulk buying: packs of 100 to 250
Key specifications
| Specification | Detail |
|---|---|
| Product | Imperial Bugle Head T17 Batten Screw |
| Type | Bugle head screw with a Type 17 (T17) point |
| Material | A4 (316) stainless steel |
| Key features | Bugle head sits flush without tearing timber fibres; T17 cutting point starts in timber |
| Typical environment | Coastal, marine, pool and food-processing use |
| Drive | See variant |
| Thread system | Imperial gauge sizes |
| Magnetic response | Generally non-magnetic (austenitic); cold-worked parts can show weak magnetism |
| Variants | 6 |
| Fitting tip | Use anti-seize on the thread to reduce galling |
| Lengths | 50 mm to 150 mm |
| Head type | Bugle |
| Pack quantity | 100 to 250, by size |
| Sizes | 14G-10 |
Selecting the right option
Gauge sizes are shown as a number followed by G, for example 14G. Pre-drilling is still advised in dense hardwood or close to the end of a board. Where chlorides are not a concern, the A2 (304) version costs less: Imperial Bugle Head T17 Batten Screw - 304 Stainless Steel.
Resources
Couldn't load pickup availability
Secure Checkout. We do not store credit card details
Imperial Bugle Head T17 Batten Screw - 316 Stainless Steel: 14G-10 / 50 mm
SKU: A0072071 | Model: BBSA414GX50
BBSA414GX50: 14G-10 x 50 mm bugle head T17 batten screw, 316 Stainless Steel. Sold in a box of 250. Suits fixing timber battens, roof battens and framing.
